ABB GNEM3116T General Purpose Motor - IE3 Premium
Part Number: 7BGNEM3116T
Quick Summary
GNEM3116T General Purpose Motor delivers 0.75 kW for 3-phase drives in general industrial equipment. In busy plants, the right motor reduces energy costs and minimizes unplanned downtime. It carries IE3 Premium Efficiency along with CE and UKCA markings, supporting global regulatory compliance. A rugged 143T frame with foot-mounted base and OPSB enclosure ensures dependable installation and long service life. This model is designed for both 60 Hz and 50 Hz operations, enabling streamlined procurement, easy stocking at multiple warehouses, and lower total cost of ownership. Its direct-on-line starting and robust 6205 ball bearings help maintain steady torque and reduce maintenance. Engineers gain predictable performance in conveyors, pumps, and general automation.
Product Information
Extended Description
7BGNEM3116T ABB: General Purpose Motor .75 kW 190 V (GNEM3116T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1/.75KWHP,1770//1470RPM,3PH,60//50H
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
GNEM3116T
Certification Agency
CE | CURUSEEV | IE3 | NEMA_PREMIUM | UKCA | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
OPSB
Frame Material
Steel
Frame Size
Undefined
Global Commercial Alias
GNEM3116T
Gross Weight
37 lb
Insulation Class
F
Invoice Description
1/.75KWHP,1770//1470RPM,3PH,60//50HZ,143
Made To Order
No
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
143T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
.75 kW | 1 Hp
Power Factor
66 %
Product Name
GP 3PH Enclosed
Product Net Depth / Length
0 in
Product Net Height
0 in
Product Net Weight
37 lb
Product Net Width
0 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.3 A | 3.4 A | 1.7 A | 3.7 A | 1.85 A
Rated Efficiency
85.5 %
Rated Speed
1470 r/min | 1770 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.88 in
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States
Synchronous Speed (vsyn)
1500 r/min | 1800 r/min
Type of Duty
Continuous
Voltage Rating
190 V | 208 V | 230 V | 380 V | 460 V
IE3 Premium Efficiency is a key feature, delivering lower energy use and cooler running in continuous-duty operations. For plants running 190–460 V three-phase supplies, the motor maintains stable performance across voltages, reducing voltage drop and thermal stress. In conveyors and pumps, the efficiency gains translate into lower energy bills and longer motor life. Frame 143T and foot-mounted base provide a sturdy, industry-standard footprint that simplifies installation, alignment, and retrofits with existing bases. The OPSB enclosure paired with a steel frame delivers reliable ingress protection in moderate environments and supports longer service intervals with minimal maintenance. Bearings (6205, Ball) and a 0.88 in shaft diameter are engineered for durability, lower vibration, and easier coupling to belts and pullies. Direct-on-line starting, NEMA Design B configuration, and a 1.15 service factor enable robust startup torque and steady operation in continuous duty. With 3 phases, 4 poles, and a dual-speed compatibility, this motor adapts to both 60 Hz and 50 Hz systems, reducing inventory complexity while maintaining performance. Stocking flexibility is reinforced by multiple warehouse availability and a 0 day lead time in supplier data, supporting fast replacements and minimized downtime for critical lines. This combination is particularly valuable for conveyors, pumps, fans, and general automation across manufacturing settings.
