Eaton JGX3200FAGC Molded Case Breaker - UL Listed
Part Number: JGX3200FAGC
Quick Summary
The Eaton JGX3200FAGC complete molded case circuit breaker protects electrical feeders in industrial and commercial panels. This 3-pole unit delivers reliable overcurrent protection for demanding 200 A circuits at up to 600 Vac. The challenge many engineers face is balancing fast fault interruption with selective coordination across multiple devices without nuisance trips. The JGX3200FAGC addresses this with fixed thermal and adjustable magnetic trip (T185), delivering precise response to short circuits while preserving downstream equipment. Backed by UL Listed, IEC rated, and CSA Certified compliance, it also meets CE marking requirements, supporting global installations. With Series G compatibility, metric mounting hardware, and line/load terminals, you gain streamlined installation and consistent performance across Eaton MCCB accessories and service centers, improving uptime and total cost of ownership.
Product Information
Extended Description
JGX3200FAGC Eaton: Eaton Series G molded case circuit breaker, JG-frame, JG, Fixed thermal, adjustable magnetic trip, Three-pole, 200A, 600 Vac, 200 kAIC at 240 Vac, 200 kAIC at 480 Vac, 50 kAIC at 600 Vac, Line and load, Metric, 50/60 Hz, 100% rated
Product Name
Eaton Series G complete molded case circuit breaker
Catalog Number
JGX3200FAGC
UPC
786685581705
Product Length/Depth
3.57 in
Product Height
4.13 in
Product Width
4.13 in
Product Weight
6 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
CE Marked
Certifications
IEC Rated UL Listed CSA Certified
Type
Complete breaker
Amperage Rating
200 A
Voltage rating
600 Vac
Trip Type
T185
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Rating
100% rated
Series
Series G
Terminals
Line and load
Frame
JG
Frequency rating
50 to 60 Hz
Mounting hardware
Metric
Interrupt rating
200 kAIC at 480 Vac 50 kAIC at 600 Vac 200 kAIC at 240 Vac
Number of poles
Three-pole
