Eaton JGX4090FAG Complete MCCB - UL Listed, 200 kAIC

Feature → Business Impact → Application: The JGX4090FAG is a four-pole JG frame molded case circuit breaker rated at 90 A, with a 600 Vac and 250 Vdc capability. This combination reduces the risk of nuisance trips while delivering robust protection for medium-sized feeders and panelboards in modern manufacturing lines. Application: ideal for control panels and motor feeders in machine shops and packaging facilities, where stable protection improves uptime and safety. Feature → Business Impact → Application: T185 trip type with fixed thermal and adjustable magnetic trip provides tailored protection against short circuits without compromising normal operation. Application: supports selective coordination in multi-zone panels, minimizing downtime during faults. Feature → Business Impact → Application: Interrupt ratings of up to 200 kAIC at 480 Vac and 240 Vac, plus 50 kAIC at 600 Vac, enable reliable fault clearing under high fault currents. Application: suitable for high-energy distribution systems and critical machinery. Feature → Business Impact → Application: Line and load terminals with a Series G complete breaker design simplify installation and maintenance. Application: streamlines panel upgrades and retrofits in existing control architectures. Feature → Business Impact → Application: UL Listed, CSA Certified, IEC Rated, and CE Marked compliance reduces certification time and supports global deployments. Application: accelerates international projects and cross-border manufacturing initiatives. Feature → Business Impact → Application: Compact 3.44 in depth, 7 in height, 5.34 in width, and 8 lb weight enable efficient space planning in crowded control panels. Application: ideal for retrofit and expansion projects where space is at a premium.
