Rittal SV 9342.100 Base Tray 3-pole - UL 94-V0
Part Number: 9342100
Manufacturer
Rittal
Part number
9342100
Category
Alt Part Number
SV 9342.100
Quick Summary
Rittal SV 9342.100 Base Tray is designed to provide rear contact hazard protection for busbar assemblies in switchgear. Maintenance teams often struggle with exposed conductors, increasing the risk of accidental contact during servicing. Made from thermally modified hard PVC and rated UL 94-V0, it combines safety with durable, easy-to-clean surfaces in RAL 7035. With a 500 mm length for 3-pole PLS 1600 systems, it can be cut to length to reduce waste and installation time. This accessory is expressly compatible with Rittal enclosures and can be supplied as 2-piece packs to streamline stocking and reduce downtime. Its simple mounting and removal support fast maintenance workflows without compromising the integrity of the busbar system.
Product Information
Extended Description
9342100 Rittal: SV Base tray, L: 500 mm (PLS 1600)
Article number
SV 9342.100
Product description
For rear contact hazard protection of the busbar assembly.
Material
Thermally modified hard PVC. | Fire protection corresponding to UL 94-V0
Colour
RAL 7035
For number of poles
3
Length
500 mm
Note
May be cut individually to required length
To fit busbar system
PLS 1600, 3-pole
Dimensions
Length: 500 mm
Packs of
2 pc(s).
Weight/pack
1.22 kg
Customs tariff number
85472000
EAN
4028177503526
ETIM 9
EC002270
ECLASS 8.0
27409221
Product description
SV Base tray, L: 500 mm (PLS 1600)
Feature: Rear contact hazard protection for the busbar assembly → Business Impact: Improves operator safety and reduces risk of injury during maintenance → Application: Ideal for switchgear and control cabinets requiring safe busbar access. Feature: Thermally modified hard PVC with UL 94-V0 fire rating → Business Impact: Enhances fire safety and long-term enclosure integrity → Application: Suitable for harsh industrial environments where flame retardancy is mandatory. Feature: 500 mm length, 3-pole compatibility with PLS 1600 → Business Impact: Fits standard 3-pole busbar configurations, minimizing custom parts and procurement time → Application: Quick deployment in modular switchgear. Feature: May be cut to required length → Business Impact: Reduces material waste and inventory complexity → Application: Tailor the tray to exact installation needs on site. Feature: Pack of 2, weight 1.22 kg per pack → Business Impact: Easy handling, lower shipping costs, and streamlined stocking → Application: Efficient for maintenance teams managing multiple chasses. Feature: Color and finish (RAL 7035) → Business Impact: Visual compatibility with common enclosures improves traceability and aesthetics → Application: Maintains consistent appearance across Rittal installations. Feature: Clear documentation and classifications (ETIM 9 EC002270, ECLASS 8.0 27409221) → Business Impact: Simplifies procurement data and ERP integrations → Application: Supports accurate SKU tagging and cataloging for engineers and buyers.
Get a Quick Quote for a Rittal 9342100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9342100?
Enquire Now
FAQs
Yes. The SV 9342.100 is designed to fit 3-pole PLS 1600 busbar configurations, with a 500 mm length that aligns to standard switchgear footprints. It also supports on-site cutting to match exact enclosure dimensions, reducing waste and simplifying installation.
Key specs include article number SV 9342.100, 500 mm length, 3-pole capacity, material thermally modified hard PVC, UL 94-V0 fire rating, color RAL 7035, packed as 2 pieces per pack, and weight 1.22 kg per pack. EAN is 4028177503526 and customs tariff 85472000.
The primary purpose is rear contact hazard protection for busbar assemblies, reducing the risk of accidental contact during maintenance and servicing while preserving the integrity of the busbar system.
Yes. The product note states that it may be cut individually to the required length, enabling a precise fit and minimizing material waste during installation.
The tray uses UL 94-V0 fire-rated material. It is catalogued with ETIM 9 EC002270 and ECLASS 8.0 27409221 classifications, which helps with procurement data, ERP integrations, and cross-reference in engineering catalogs.
