003N3104

Part Number: 003N3104
003N3104
Manufacturer
Danfoss
Part number
003N3104
Category

Product Information

Extended Description

003N3104 Danfoss: Connection type: G, Connection size [in]: 3/4, Kv value [m=C2=B3/h]: 3.400, Opening configuration: Opens on rising cond. pressure, Control pressure range [bar]: 4.00 - 23.00, Connection size (refrigerant): 1/4 in - 6 mm, Connection type (refrigerant): SAE flare
Gross weight
1.344 Kilogram
Net weight
1.12 Kilogram
Volume
4.082 Liter
EAN
5702423203291
Approval
C UL US LISTED,EAC,LLC CDC TYSK,PED,RoHS,RoHS China
Approval file name
REFRIGERANT VALVE 53R0
Body material
Stainless steel
China RoHS compliance
Yes
Connection Internal/External
Internal
Connection size (refrigerant)
1/4 in - 6 mm
Connection size [in]
3/4
Connection standard
ISO 228-1
Connection type
G
Connection type (refrigerant)
SAE flare
Contain batteries
No
Control pressure range [bar] [max]
23 bar
Control pressure range [bar] [min]
4 bar
Cv value [gal/min]
3.9 gal/min
Differential pressure [bar]
10 bar
Differential pressure [psi]
145 psi
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(b),6(c)
Kv value [m=C2=B3/h]
3.4 m=C2=B3/h
Lubricants compatibility
Oilfree applications
Max. test pressure [bar] Pe
24 bar
Max. test pressure [psig]
348 psig
Max. Working Pressure [bar]
16 bar
Max. Working Pressure [psig]
232 psig
Max.test press.(refrig.)[bar]
29 bar
Max.test press.(refrig.)[psig]
420.6 psig
Media
Fresh water,Neutral brine,Sea water
Medium temperature range [=C2=B0C] [max]
130 =C2=B0C
Medium temperature range [=C2=B0C] [min]
-25 =C2=B0C
Medium temperature range [=C2=B0F] [max]
266 =C2=B0F
Medium temperature range [=C2=B0F] [min]
-13 =C2=B0F
MWP (refrigerant) [bar]
26.4 bar
Oil free refrigerants
R513A
Opening configuration
Opens on rising cond. pressure
Orifice size [mm]
20 mm
Orifice size fraction [in]
4/5 in
Packing format
Multi pack
Product accessories
Generic accessories,Water valves accessories
Product group
Water regulating valves
Product Name Description
Pressure operated water valve
Quantity per packing format
10 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R1234yf,R134a,R22,R404A,R407A,R407C,R407F,R407H,R422B,R422D,R448A,R449A,R449B,R450A,R452A,R454A,R454C,R455A,R507A,R513A,R515B,R516A
SCIP dossier no.
f7d782f1-04df-4c40-bfe2-ea3a06dce79f
SCIP dossier product name
WVS/WVTS
Serviceable
Water valve spare parts
Type
WVFX 20
UK RoHS compliance
Out of scope
UL approved refrigerants
R134a,R22,R404A,R407A,R407C,R407F,R407H,R422B,R422D,R448A,R449A,R449B,R450A,R452A,R507A,R513A,R515B,R516A
UL evaluated
Yes
