ABB 1SBN010018R1001 Auxiliary Contact Block - IP67
Part Number: 1SBN010018R1001
Quick Summary
Auxiliary Contact Block from ABB provides a compact 1-pole front-mounted auxiliary contact for control circuits in heavy industrial machinery. In harsh environments, wiring errors and mis-matched terminals can delay commissioning and drive costly downtime. It adheres to IEC 60947-5-1 and offers IP67 protection on auxiliary terminals, with CE and UKCA conformity for global compliance. Designed for seamless integration with ABB AF/NF/NX contactor families, it supports scalable control architectures while delivering reliable signaling and easy installation in panel environments.
Product Information
Extended Description
1SBN010018R1001 ABB: CE5-01W2 is a 1-pole front mounted auxiliary contact block equipped with screw terminals and can be fitted on AF09(Z)...96, A9…75, AFC09…38, AL9…AE75, AX9…AX80 contactors and NF(C)(Z), N, NL, NX contactor relays. CE5-01W2 is used for the operation of auxiliary circuits and control circuits for severe industrial environments. CE5-01W2 is available with 1 N.C. including a built-in microswitch IP67, degree of protection (IP20 on terminals), defined for a 2 A AC-15 24-240 V 50/60 Hz / DC-12 24 V DC.
Minimum Order Quantity
1 piece
Customs Tariff Number
85389099
Data Sheet, Technical Information
1SBC100214C0202 - Main catalog Motor protection and control Manual motor starters, contactors and overload relays (PDF) - Edition 2024
Instructions and Manuals
Operating Instruction CE5-.. 1-pole aux. contact block
Instructions and Manuals (Part 2)
Contactors and Overload relays guide
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
9.8 mm
Product Net Depth / Length
32.5 mm
Product Net Height
46.8 mm
Product Net Weight
0.02 kg
Number of Auxiliary Contacts NO
0
Number of Auxiliary Contacts NC
1
Number of Poles
1P
Standards
IEC/EN 60947-5-1
Rated Operational Voltage
Auxiliary Circuit 250 V
Rated Frequency (f)
Auxiliary Circuit 50 / 60 Hz
Rated Operational Current AC-15 (Ie)
(24 / 127 V) 2 A | (220 / 240 V) 2 A
Rated Insulation Voltage (Ui)
acc. to IEC 60947-5-1 250 V
Connecting Capacity Auxiliary Circuit
Flexible with Ferrule 1/2x 0.75 ... 2.5 mm² | Rigid Solid 1/2x 1 ... 4 mm² | Rigid Stranded 1/2x 1 ... 4 mm²
Degree of Protection
acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP67
Tightening Torque
Auxiliary Circuit 1 N·m
Terminal Type
Screw Terminals
Suitable For
AF09 | AF09Z | AF12 | AF12Z | AF16 | AF16Z | AF26 | AF26Z | AF30 | AF30Z | AF38 | AF38Z | AF40 | AF52 | AF65 | AF80 | AF96 | AFC09 | AFC12 | AFC16 | AFC26 | AFC30 | AFC38 | NF22E | NFZ22E | NF31E | NFZ31E | NF40E | NFZ40E | NFC22E | NFC31E | NFC40E | A9 | A12 | A16 | A26 | A30 | A40 | A50 | A63 | A75 | A95 | A110 | AL9 | AL9Z | AL12 | AL12Z | AL16 | AL16Z | AL26 | AL30 | AL40 | AE45 | AE50 | AE63 | AE75 | N22E | N31E | N40E | NL31E | NLZ31E | NL40E | NLZ40E | AX06 | AX09 | AX12 | AX18 | AX25 | AX32 | AX40 | AX50 | AX65 | AX80 | NX22E | NX31E | NX40E
Product Name
Auxiliary Contact Block
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
REACH Declaration
REACH - Letter of Confirmation for block contactors, contactor relays, installation contactors, mini contactors, mini contactor relays, thermal overload relays, electronic overload relays and related accessories
RoHS Information
RoHS II declaration for block contactors, installation contactors, mini contactors, mini contactor relays, thermal overload relays, electronic overload relays and related accessories
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
WEEE B2C / B2B
Business To Business
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
CB Certificate
CB Certificate CE5 auxiliary contact blocks for AF09...AF96 contactors and NF contactor relays
CQC Certificate
CQC Certificate, Auxiliary contacts, CE5-10W0,1,CE5-01W0,1, CE5-10D0,1, CE5-01D0,1,CE5-10W2, CE5-01W2, CE5-10D2, CE5-01D2, Made in Czech Republic
Declaration of Conformity - CCC
CCC Declaration of Conformity, Auxiliary contacts, CE5-10W0,1,CE5-01W0,1, CE5-10D0,1, CE5-01D0,1,CE5-10W2, CE5-01W2, CE5-10D2, CE5-01D2, Made in Czech Republic
Declaration of Conformity - CE
EU Declaration of Conformity CE5 auxiliary contacts
Declaration of Conformity - UKCA
UK Declaration of Conformity CE5 auxiliary contacts
GOST Certificate
GOST_POCCFRME77B07175
RINA Certificate
RINA Certificate for A9...A75 contactors
Package Level 1 Units
blister 1 piece
Package Level 1 Width
100 mm
Package Level 1 Depth / Length
100 mm
Package Level 1 Height
10 mm
Package Level 1 Gross Weight
0.02 kg
Package Level 1 EAN
3471522199515
Package Level 2 Units
box 126 piece
Package Level 2 Width
245 mm
Package Level 2 Depth / Length
75 mm
Package Level 2 Height
153 mm
Package Level 2 Gross Weight
2.52 kg
Package Level 3 Units
4536 piece
Object Classification Code
K
ETIM 7
EC000041 - Auxiliary contact block
ETIM 8
EC000041 - Auxiliary contact block
ETIM 9
EC000041 - Auxiliary contact block
eClass
V11.0 : 27371302
UNSPSC
39121522
IDEA Granular Category Code (IGCC)
4743 >> Auxiliary contact block
The 1P 1NC Auxiliary Contact Block delivers reliable auxiliary signaling with a compact footprint, reducing panel depth while preserving wiring simplicity. This translates to faster wiring, lower installation labor, and improved machine availability. Its 9.8 mm net width and front-mount design enable clean panel layouts, especially in tight control cabinets. The screw-terminal connections accommodate ferrule and solid conductors up to 4 mm², supporting quick field wiring and robust torque retention at 1 N·m. compatibility with AF09 to AF96 and NF/NX series contactors ensures scalable integration for motor control and protection schemes. The device meets IEC 60947-5-1 requirements and IP67 protection on auxiliary terminals, providing reliable operation in wet or dusty environments. These attributes collectively reduce maintenance cycles and extend asset life in automation systems.
Get a Quick Quote for a ABB 1SBN010018R1001
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SBN010018R1001?
Enquire Now
FAQs
The block fits a wide range of ABB contactors including AF09 through AF96, AFC09 through AFC38, and AX/NX/NF/NL/N relays. It is designed for front-mounting on these families and delivers a single NC auxiliary contact for signaling auxiliary circuits, enabling seamless integration into existing motor control and control-circuit architectures.
It provides a 250 V auxiliary circuit, with 50/60 Hz operation and a rated operational current of 2 A AC-15 at 24/127 V and 2 A at 220/240 V. The terminals are screw-connected and rated for flexible ferrule 0.75–2.5 mm² or rigid solid 1–4 mm² or rigid stranded 1–4 mm² wiring. This supports reliable signaling under typical industrial loads.
The auxiliary terminals are IP67 protected, ensuring integrity in challenging environments, while the terminals themselves are IP20 for basic protection. The front-mounted 1P1NC design is tailored for compact installations alongside ABB AF/NF/NX contactors, enabling straightforward panel integration and quick field wiring without adding depth to the control cabinet.
Net width is 9.8 mm, depth 32.5 mm, and height 46.8 mm, with a net weight of 0.02 kg. Wiring accepts ferrule 0.75–2.5 mm² and solid 1–4 mm² or stranded 1–4 mm² conductors, all secured with a tightening torque of 1 N·m for robust connections in industrial environments.
The block supports IEC/EN 60947-5-1 standards, CE and UKCA conformity, and RoHS/REACH declarations. Additional certifications include CB and CCC declarations, plus GOST/RINA references for global product acceptance. Documentation includes data sheets and operating instructions to facilitate regulatory compliance and safe installation.
