ABB 1SCA103098R1001 OSS800T1S/4 Terminal Shroud - CMRT
Part Number: 1SCA103098R1001
Quick Summary
ABB 1SCA103098R1001 OSS800T1S/4 Terminal Shroud is a compact protective cover that safeguards low‑voltage terminal connections in switchgear and motor control panels. Engineers frequently struggle with loose terminations, heat buildup, and clutter that slow maintenance and compromise safety. This product is CMRT, Reach Declaration, and RoHS compliant, providing clear supply-chain visibility and regulatory assurance. Its compatibility with ABB OS and fusegear families streamlines installation and reduces total panel assembly time, while delivering durable, reliable wiring protection for industrial environments.
Product Information
Extended Description
1SCA103098R1001 ABB: OSS800T1S/4 TERMINAL SHROUD
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
REACH Declaration
Reach Declaration / AC Switches and Fusegear
RoHS Information
RoHs Declaration / AC Switches and Fusegear
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Data Sheet, Technical Information
Switches, Switch fuses OS and OSM, OS1GB Catalog PDF
Instructions and Manuals
No Instructions and Manuals needed
Minimum Order Quantity
1 piece
Customs Tariff Number
85389099
Country of Origin
Finland (FI)
Product Net Width
88 mm
Product Net Height
62.4 mm
Product Net Depth / Length
95.5 mm
Product Net Weight
0.01 kg
Package Level 1 Units
bag 1 piece
Package Level 1 Width
90 mm
Package Level 1 Depth / Length
105 mm
Package Level 1 Height
280 mm
Package Level 1 Gross Weight
0.012 kg
Package Level 1 EAN
6417019375977
Handle Type
Handle and shaft included
Special Functions
S/4
Object Classification Code
N/A
ETIM 8
EC002498 - Accessories/spare parts for low-voltage switch technology
ETIM 9
EC002498 - Accessories/spare parts for low-voltage switch technology
eClass
V11.1 : 27371392
WEEE Category
Product Not in WEEE Scope
CMRT and RoHS compliance reduce sourcing risk and support regulatory audits, helping procurement teams meet sustainability and conflict minerals requirements while avoiding non-compliant components. The shroud’s compact footprint (88 mm width, 62.4 mm height, 95.5 mm depth) and light 0.01 kg weight enable lean panel layouts, improving installation density and minimizing space constraints in control cabinets. Handle and shaft are included along with the S/4 function, which simplifies activation during maintenance and field servicing, reducing tool time and human error in critical ABB OS/OS1 configurations. Origin information and customs data (Finland FI, tariff 85389099) support compliance documentation and traceability for global supply chains, enhancing audit readiness and customer confidence. Comprehensive product references (CMRT, RoHS, REACH) and available data sheets enable engineers to validate compatibility with OS switches and fusegear, accelerating design reviews and commissioning.
Get a Quick Quote for a ABB 1SCA103098R1001
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SCA103098R1001?
Enquire Now
FAQs
Yes. The OSS800T1S/4 Terminal Shroud is designed to fit ABB OS and fusegear families, providing a protective enclosure for terminations and simplifying panel wiring in low-voltage applications. Verify mounting clearances in your enclosure and ensure standard 88 mm width fits your cabinet layout.
The product carries CMRT (Conflict Minerals Reporting Template), Reach Declaration, and RoHS compliance. These certifications support supply-chain transparency, regulatory adherence, and sustainability goals, helping you meet procurement and environmental requirements for electrical components used in regulated industries.
The shielded cover protects terminations from dust and incidental contact, reducing wiring errors and electrical noise. With a compact form factor and a handle included, installation and servicing are faster, improving first-pass wiring quality and operator safety in busy control panels.
Plan for the 88 mm wide by 62.4 mm high footprint and 95.5 mm depth, ensuring mounting surfaces and clearance around adjacent components. Use the included handle for convenient access, and confirm compatibility with the OS/OS1 switchgear footprint to avoid interferences during assembly.
Beyond safety and reliability, the shroud supports faster commissioning and easier maintenance, reducing downtime and labor costs. The CMRT, Reach, and RoHS certifications help with regulatory audits and supplier due diligence, delivering measurable ROI through improved uptime and streamlined procurement.
