ABB 1SCD014094R1 CGSE OT 600A 3P 240V - UL 1008
Part Number: 1SCD014094R1
Quick Summary
ABB 1SCD014094R1 CGSE OT 600A 3P 240V contactor is a high-current switching device designed for motor control in industrial power distributions. Operators and design engineers often struggle with nuisance trips and undersized protection that halt production and drive maintenance costs. This model carries UL 1008 certification and cULus approval, plus ETIM classification, helping you meet safety, compliance, and interchangeability requirements. Its 3P 240V operation with a solid neutral bar simplifies wiring inside control panels, while the CG (Level 3) controller type supports reliable control in mixed-signal environments. Choosing this ABB solution can reduce downtime, shorten commissioning, and simplify spares management through standardized documentation and open-transition functionality.
Product Information
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
Instructions and Manuals
ZTGSE and ZTSSE Operation & Maintenance Manual
Wiring Diagram
77A-2005 ZTGSE 30-1200A Electrical Schematic
Minimum Order Quantity
1 piece
Customs Tariff Number
853710
Country of Origin
United States (US)
Package Level 1 Units
crate 1 piece
Controller Type
CG (Level 3)
Neutral Type
Solid Neutral Bar
Number of Poles
3P
Rated Frequency (f)
Main Circuit 50/60 Hz
Rated Operational Voltage
220 ... 240 V AC
Standards
UL1008
Transition Type
Open Transition
Ampere Rating
600 A
UL Certificate
cULus - CERTIFICATE OF COMPLIANCE - E35022-Vol1-Sec1-20230616
ETIM 8
EC000066 - Power contactor, AC switching
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
Feature → Business Impact → Application: 600 A ampere rating with 3P, 240V operation enables reliable control of large motors and pumps, reducing overload incidents and operational downtime in conveyors and processing lines. This directly improves production uptime and lowers energy-related inefficiencies when starting heavy loads. Feature → Business Impact → Application: Open Transition switching minimizes arcing during make-and-break cycles, improving switch longevity and reducing maintenance costs, especially in high-cycle environments like packaging and material handling. Feature → Business Impact → Application: Solid Neutral Bar provides stable, low-impedance return paths for balanced phase voltage, enhancing protection reliability in diverse power environments and simplifying panel wiring during retrofit projects. Feature → Business Impact → Application: UL 1008 and cULus certifications deliver compliance confidence for safety-critical installations, speeding procurement decisions and easing regulatory audits across manufacturing facilities. Feature → Business Impact → Application: 3P configuration with 220–240 V AC mains compatibility supports standard industrial power distributions, reducing the need for custom wiring and enabling straightforward integration with existing ABB and legacy equipment.
Get a Quick Quote for a ABB 1SCD014094R1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SCD014094R1?
Enquire Now
FAQs
Check the device ratings: 600 A ampere rating, 3P poles, and 220–240 V AC across the main circuit. Confirm your motor full-load current, short-circuit current, and duty cycle align with UL 1008 requirements. Review the wiring diagram 77A-2005 and ensure the control circuit matches your starter configuration. This approach minimizes retrofit risks and ensures compliant protection.
Key specs to verify include ampere rating (600 A), number of poles (3P), rated operating voltage (220–240 V AC), and transition type (Open Transition). Also confirm the presence of a solid neutral bar and that the device aligns with UL 1008 and cULus approvals. Ensuring these match your panel design reduces nuisance trips and improves protection reliability.
Yes. The 3P 240V configuration supports three-phase equipment like conveyors and pumps, with an open-transition design that helps manage switching transients. UL 1008 compliance and solid-neutral construction provide enhanced safety and reliability in industrial floors, while ETIM EC000066 classification supports compatibility with standard power contactors in control panels.
The model carries UL 1008 certification and cULus recognition, ensuring compliance for critical power switching. It is classified under ETIM EC000066 for power contactors, AC switching, and falls under WEEE category 4. These certifications help with regulatory audits, supplier qualification, and safe integration into multi-vendor electrical systems.
Schedule periodic visual inspections and contact resistance tests during planned maintenance, focusing on the solid neutral bar and terminals. Replace worn components promptly to prevent unplanned downtime. Leveraging standardized documentation and open-transition operation reduces commissioning time and lowers total cost of ownership by streamlining spare parts management and cross-compatibility.
