ABB 1SDA038318R1 Accessory - 60V UVD Time Delay Coil
Part Number: 1SDA038318R1
Quick Summary
ABB 1SDA038318R1 Time Delay Coil provides undervoltage release for Tmax XT and Emax 2 protection. Engineers often face premature trips or delayed isolation caused by inconsistent undervoltage signaling in fast-moving production lines. This accessory carries CE conformity, RoHS compliance, and TSCA declarations to support global regulatory requirements. Compatible with SACE Tmax XT and SACE Emax 2 families, it simplifies installation and reduces spare-part inventories, boosting uptime. By aligning with IEC standards and flexible mounting options, it supports downstream control-system integration and predictive maintenance programs. Its compact footprint and lightweight design enable easy retrofit in crowded MCCs.
Product Information
Extended Description
1SDA038318R1 ABB: UVD 60V E1/6-T7-X1-T8-E1.2/6.2-XT7-XT7M
Environmental Product Declaration - EPD
NoDecNee
REACH Declaration
REACh Declaration ABB Sace circuit breakers
RoHS Information
RoHS Declaration ABB Sace circuit breakers
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration
Environmental Information
Breakers - Packaging disposal information
Order Code US and Canada
KE6TL7
EAN
8015644383183
Minimum Order Quantity
1 piece
Customs Tariff Number
85389099
Product Net Width
150 mm
Product Net Height
60 mm
Product Net Depth / Length
200 mm
Product Net Weight
0.323 kg
Package Level 1 Units
box 1 piece
Package Level 1 Width
150 mm
Package Level 1 Height
60 mm
Package Level 1 Depth / Length
200 mm
Package Level 1 Gross Weight
0.323 kg
Package Level 1 EAN
8015644383183
Product Main Type
Accessories for Emax 2, Accessories for Tmax XT
Product Name
Accessory
Product Type
Accessory
Suitable For
XT7-XT7M, E1.2, E2.2, E4.2, E6.2, E1, E2, E3, E4, E6, X1, T7, T8
Suitable for Product Class
SACE Tmax XT, SACE Emax 2, SACE Emax, SACE Tmax T
Configuration Type
Loose or configurable
Current Type
AC/DC
Order Multiple
1 piece
Rated Voltage (Ur)
60 V
Standards
IEC
Data Sheet, Technical Information
SACE Tmax. T Generation. Low voltage moulded-case circuit-breakers from 250 A up to 1600 A | U.S. Catalog - SACE Tmax for special applications. Adaptability, versatility and complete freedom
Declaration of Conformity - CE
Refer to the EU Declaration of the relative Circuit Breaker
Instructions and Manuals
Time delay device for undervoltage release (D)
ETIM 8
EC002052 - Time delay under voltage coil
ETIM 9
EC002052 - Time delay under voltage coil
IDEA Granular Category Code (IGCC)
4147 >> Time delay under voltage coil
Object Classification Code
Q
UNSPSC
39121010
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
eClass
V11.1 : 27370426
Feature: The 60 V rated UVD time-delay coil delivers accurate undervoltage signaling for motor-protection schemes. Business Impact: Reduces nuisance trips and improves protection coordination between upstream breakers and downstream loads. Application: Ideal for SACE Tmax XT and SACE Emax 2 installations. Feature: Loose or configurable mounting option enhances installation flexibility across panel doors and MCCs. Business Impact: Simplifies retrofits and minimizes wiring errors during field upgrades. Application: Works with XT7-XT7M, E1.2, E2.2, E4.2 and related product families. Feature: RoHS and TSCA compliance ensure regulatory alignment across global plants. Business Impact: Lowers compliance risk and eases supplier audits. Application: Suitable for process automation, energy infrastructure, and manufacturing environments. Feature: Compact footprint (150x60x200 mm) and 0.323 kg weight. Business Impact: Enables easy retrofit in space-constrained MCCs and minimizes rework. Application: Beneficial for new builds and modernization projects. Feature: Documentation and declarations (EPD/REACH/RoHS) provide traceability. Business Impact: Improves sustainability reporting and supplier-validation workflows. Application: Aligns with corporate QMS and IEC-based standards.
