ABB 1SDA065800R1 Moulded Case Circuit Breaker - CE
Part Number: 1SDA065800R1
Quick Summary
ABB 1SDA065800R1 Moulded Case Circuit Breaker protects large low-voltage feeders in industrial plants. Engineers often struggle with protection mis-sizing and downtime from nuisance trips during line upgrades. It carries CE conformity with IEC standards and RoHS/REACH declarations, plus CMRT and TSCA readiness. Designed for reliability in modern switchgear and automation rigs, it aligns with SACE Tmax T family and 4P protection to streamline procurement and installation. In practice, this means faster integration with existing racks, fewer field adjustments, and improved uptime across continuous production lines. By documenting RoHS and REACH compliance, procurement teams reduce regulatory risk when sourcing globally.
Product Information
Extended Description
1SDA065800R1 ABB: C.BREAKER TMAX T8V 3200 FIXED FOUR-POLE WITH TERMINALS REAR VERTICAL AND SOLID-STATE RELEASE IN AC PR332/P-LSIG R 3200
Environmental Product Declaration - EPD
NoDecNee
REACH Declaration
REACh Declaration ABB Sace circuit breakers
RoHS Information
RoHS Declaration ABB Sace circuit breakers
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration
Environmental Information
Product Environmental Information Tmax T8 | Breakers - Packaging disposal information
EAN
8015644687113
Minimum Order Quantity
1 piece
Customs Tariff Number
85362090
Product Net Width
553 mm
Product Net Height
382 mm
Product Net Depth / Length
282 mm
Product Net Weight
15 kg
Package Level 1 Units
1 piece
Package Level 1 Width
650 mm
Package Level 1 Height
665 mm
Package Level 1 Depth / Length
695 mm
Package Level 1 Gross Weight
16.5 kg
Package Level 1 EAN
8015644687113
Product Main Type
SACE Tmax T
Product Name
Moulded Case Circuit Breaker
Product Type
Automatic Circuit Breaker
Version
F
Electrical Durability
3000 cycle | 20 cycles per hour
Mechanical Durability
15000 cycle | 60 cycles per hour
Number of Poles
4P
Power Loss
at Rated Operating Conditions per Pole 117 W
Rated Current (In)
3200 A
Rated Impulse Withstand Voltage (Uimp)
8 kV
Rated Insulation Voltage (Ui)
1000 V
Rated Operational Voltage
690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics)
(220 V AC) 100 kA | (230 V AC) 100 kA | (380 V AC) 100 kA | (400 V AC) 100 kA | (415 V AC) 100 kA | (440 V AC) 100 kA | (500 V AC) 75 kA | (690 V AC) 60 kA
Rated Short-time Withstand Current Low Voltage (Icw)
for 1 s 40 A
Rated Ultimate Short-Circuit Breaking Capacity (Icu)
(220 V AC) 1.3 kA | (230 V AC) 1.3 kA | (380 V AC) 130 kA | (400 V AC) 130 kA | (415 V AC) 130 kA | (440 V AC) 130 kA | (500 V AC) 100 kA | (690 V AC) 80 kA
Rated Uninterrupted Current (Iu)
3200 A
Release
PR332/P LSIG
Release Type
EL
Short-Circuit Performance Level
V
Standards
IEC
Sub-type
T8
Terminal Connection Type
Fixed Circuit-Breakers | Rear flat Vertical
Data Sheet, Technical Information
Tmax. T Generation - Low voltage molded case circuit breakers up to 1200 A - UL 489 and CSA C22.2 Standard
Declaration of Conformity - CE
EC Declaration of Conformity Tmax T8
Wiring Diagram
Wiring diagram T8
Instructions and Manuals
1SDC210033D0202
ETIM 8
EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 9
EC000228 - Power circuit-breaker for trafo/generator/installation protection
Object Classification Code
Q
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
eClass
V11.1 : 27370409
Paragraph 1: Feature: 4P construction delivers robust main protection for high-load feeders. Business Impact: It enables compact switchgear designs by consolidating protection into a single device, reducing panel footprint and wiring complexity. Application: Ideal for factory mains and large distribution boards in manufacturing plants. Paragraph 2: Feature: PR332/P LSIG solid-state release offers fast, reliable tripping with precise coordination. Business Impact: Improves fault isolation, lowers nuisance trips, and reduces unnecessary downtime. Application: Motor control centers and automated production lines where dependable protection at scale is essential. Paragraph 3: Feature: Ics up to 100 kA across voltage ranges ensures strong fault clearance. Business Impact: Keeps feeders and transformers safe during severe faults, minimizing equipment damage and downtime. Application: Critical protection for feeders in switchgear layouts in harsh industrial environments. Paragraph 4: Feature: Rated operational voltage 690 V AC and rated insulation 1000 V streamline system design. Business Impact: Reduces component counts, simplifies engineering, and accelerates commissioning. Application: LV distribution cabinets and machine power circuits in factories and data centers. Paragraph 5: Feature: Electrical durability of 3000 cycles and mechanical durability of 15000 cycles extend service life under frequent switching. Business Impact: Lowers maintenance costs and improves reliability for continuous production lines. Application: High-usage lines such as conveyors, presses, and process lines. Paragraph 6: Feature: RoHS, REACH, CMRT, TSCA declarations, and CE conformity ensure regulatory compliance across regions. Business Impact: Supports global procurement and reduces regulatory risk during rollout. Application: Multi-region automation projects and OEM-supplier integration. Paragraph 7: Feature: Rear vertical terminal connections for fixed mounting enable tidy panel layouts. Business Impact: Simplifies retrofits and reduces installation time. Application: Upgrades in existing switchgear and new builds alike.
Get a Quick Quote for a ABB 1SDA065800R1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SDA065800R1?
Enquire Now
FAQs
Ensure compatibility with rear vertical terminal connections and fixed mounting. Verify clearance for a 4P device, proper busbar alignment, and correct wiring routing to minimize heat buildup. Check cabinet dimensions to accommodate the 553 mm width and confirm mounting within the allowable panel space for reliable operation.
Rated current is 3200 A with rated operational voltage of 690 V AC and insulation voltage of 1000 V. It supports up to 100 kA short-circuit breaking capacity (Ics) across compatible voltages and an 8 kV impulse withstand, making it suitable for high-energy industrial protection scenarios.
Yes. It carries an EC Declaration of Conformity for Tmax T8 and meets RoHS and REACH declarations. Additional regulatory declarations, CMRT and TSCA, support compliance for global procurement and multi-region installs.
The LSIG release provides fast, coordinated tripping with solid-state reliability, reducing nuisance trips and improving fault isolation. This is especially beneficial in motor control centers and automated lines where consistent protection prevents cascade faults.
The device’s 3000 electrical cycles and 15000 mechanical cycles translate to longer service life and fewer maintenance intervals. Coupled with simplified installation and robust fault protection, downtime is reduced and production throughput improves, delivering measurable lifecycle cost savings.
