ABB 1SDA067327R1 Accessory for Tmax XT2 - IEC60947-2
Part Number: 1SDA067327R1
Quick Summary
ABB 1SDA067327R1 is a solid-state three-pole release for AC motor protection in Tmax XT2 systems. Engineers often face nuisance trips and wear with mechanical releases, leading to downtime and increased maintenance costs. It carries IEC 60947-2 certification along with RoHS and REACH declarations, plus CMRT and TSCA compliance to support global sourcing and risk management. This accessory integrates smoothly with XT2 ecosystems, simplifying procurement and installation for panel builders and OEMs. With a minimum order quantity of 1 piece, it enables lean stocking and predictable project delivery while maintaining high protection standards.
Product Information
Extended Description
1SDA067327R1 ABB: SOLID-STATE RELEASE THREE-POLE IN AC EKIP-M-I R 100 XT2
Environmental Product Declaration - EPD
NoDecNee
REACH Declaration
REACh Declaration ABB Sace circuit breakers
RoHS Information
RoHS Declaration ABB Sace circuit breakers
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration
Environmental Information
Breakers - Packaging disposal information
E-Number (Finland)
3640892
E-Number (Norway)
4379555
EAN
8015644695170
Minimum Order Quantity
1 piece
Customs Tariff Number
85389099
Product Net Weight
1 kg
Package Level 1 Units
box 1 piece
Package Level 1 Width
110 mm
Package Level 1 Height
100 mm
Package Level 1 Depth / Length
150 mm
Package Level 1 Gross Weight
1.1 kg
Package Level 1 EAN
8015644695170
Circuit Breaker Type to be Associated
Motor Protection
Product Main Type
Accessories for Tmax XT
Product Name
Accessory
Product Type
Accessory
Suitable For
XT2
Suitable for Product Class
SACE Tmax XT
Configuration Type
Loose or configurable
Current Type
AC
Number of Poles
3P
Order Multiple
1 piece
Rated Current (In)
100 A
Release
Ekip M-I
Release Type
EL
Standards
IEC60947-2
Data Sheet, Technical Information
1SDC210100D0205 | 1SDC210099D0205
Declaration of Conformity - CE
Refer to the EU Declaration of the relative Circuit Breaker
Instructions and Manuals
Release Ekip G-LS/I, Ekip N-LS/I, Ekip M-LIU, Ekip M-I XT2-XT4 | Release assembly XT2-XT4
ETIM 8
EC001023 - Shunt release (for power circuit breaker)
ETIM 9
EC001023 - Shunt release (for power circuit breaker)
Object Classification Code
Q
UNSPSC
39120000
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
eClass
V11.1 : 27370418
Three-pole solid-state release for AC circuits provides precise trip timing and eliminates mechanical wear, reducing maintenance cycles and unplanned downtime. This translates to higher line uptime in Tmax XT series installations and smoother motor protection in demanding environments. Rated at 100 A per pole, the device handles heavy motor loads reliably while maintaining consistent performance across cycling conditions. In practice, panel builders see fewer nuisance trips and easier fuse coordination when protecting large inductive loads in XT2-driven lines. Flexible installation options—loose or configurable configurations—simplify field wiring and retrofit projects. The 3P release aligns with SACE Tmax XT architectures, enabling quick integration with existing XT2 panels and reducing engineering time. Compliance and documentation streamline procurement, with IEC60947-2, RoHS, REACH declarations, CMRT and TSCA alignment reducing regulatory risk. Data sheets 1SDC210100D0205 and 1SDC210099D0205, plus installation instructions, ensure correct wiring and safe commissioning for automotive, energy, and general industrial sectors. Logistics-friendly packaging supports lean stocking: weight 1 kg net, box 1 piece, with 110 mm width, 100 mm height and 150 mm depth, EAN 8015644695170, MOQ 1 piece.
Get a Quick Quote for a ABB 1SDA067327R1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SDA067327R1?
Enquire Now
FAQs
Yes. The ABB 1SDA067327R1 is a 3P solid-state release designed as an accessory for Tmax XT2 systems. It supports loose or configurable configurations, is suitable for 100 A per pole AC motor protection, and integrates with XT2 panels without requiring major redesigns. Use this accessory to upgrade protection schemes and simplify panel wiring while maintaining platform consistency.
The device carries IEC 60947-2 compliance, RoHS and REACH declarations, CMRT (Conflict Minerals Reporting Template), TSCA declaration, and a CE-related conformity reference. It also aligns with WEEE categorization and eClass 27370418, supporting regulatory audits and multinational procurement across manufacturing, energy, and process industries.
Solid-state releases provide fast, repeatable trip responses with no mechanical wear, reducing nuisance trips and downtime. For XT2 installations, this translates to higher availability of motor-driven equipment, improved protection coordination, and longer service intervals in high-cycle or vibration-prone environments.
Minimum order quantity is 1 piece, and packaging is unitary per box with a net weight of 1 kg. Each package lists dimensions of 110 mm width, 100 mm height, and 150 mm depth, and bears EAN 8015644695170. This supports straightforward stocking for spares in manufacturing lines and service fleets, reducing ordering lead times.
Datasheets are referenced as 1SDC210100D0205 and 1SDC210099D0205, with additional installation notes covering Release Ekip M-I XT2-XT4 and XT2-XT4 assembly. These documents provide wiring diagrams, mounting guidance, and compliance details to ensure correct and safe commissioning in XT2-based protection schemes.
