ABB 1SDA101996R1 Accessory - 400A XT5 UL489 Rating Plug
Part Number: 1SDA101996R1
Quick Summary
ABB 1SDA101996R1 Accessory rating plug provides a 400 A XT5 interface for Tmax XT circuit breakers in industrial switchgear. This practical accessory simplifies high-current connections while preserving protective integrity in demanding environments. With field installations in control panels, it minimizes wiring complexity and reduces commissioning time without compromising safety. The solution adheres to UL489 for low-voltage molded-case breakers, alongside RoHS and CMRT declarations, and includes a CE compliance reference for European installations. For manufacturers and integrators, the combination of regulatory alignment and dimensional compatibility translates to faster time-to-value, lower risk, and scalable panel builds. In short, it enables dependable, compliant, and efficient XT5 network integration.
Product Information
Extended Description
1SDA101996R1 ABB: RATING PLUG In=400A XT5 UL
Environmental Product Declaration - EPD
NoDecNee
REACH Declaration
REACh Declaration ABB Sace circuit breakers
RoHS Information
RoHS Declaration ABB Sace circuit breakers
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration
Environmental Information
Breakers - Packaging disposal information
Order Code US and Canada
KXT5RP400UL
EAN
8056221020404
Minimum Order Quantity
1 piece
Customs Tariff Number
85389099
Product Net Weight
1.6 kg
Package Level 1 Units
box 1 piece
Package Level 1 Width
120 mm
Package Level 1 Height
160 mm
Package Level 1 Depth / Length
190 mm
Package Level 1 Gross Weight
1.7 kg
Package Level 1 EAN
8056221020404
Product Main Type
Accessories for Tmax XT
Product Name
Accessory
Product Type
Accessory
Suitable For
XT5
Suitable for Product Class
SACE Tamx XT
Configuration Type
Loose or configurable
Order Multiple
1 piece
Rated Current (In)
400 A
Standards
UL489
Data Sheet, Technical Information
SACE Tmax XT UL/CSA Low voltage molded case circuit-breakers UL489 and CSA CS22.2 Standards Catalog | SACE Tmax XT UL/CSA TECHNICAL CHARACTERISTICS Low voltage molded case circuit-breakers for UL489 and CSA CS22.2 Standards
Declaration of Conformity - CE
Refer to the EU Declaration of the relative Circuit Breaker
Instructions and Manuals
Rating Plug - XT5
ETIM 8
EC002498 - Accessories/spare parts for low-voltage switch technology
ETIM 9
EC002498 - Accessories/spare parts for low-voltage switch technology
IDEA Granular Category Code (IGCC)
5219 >> Switch part or accessory
UNSPSC
39122221
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
eClass
V11.1 : 27371390
