ABB 1SDA101997R1 Rating Plug - 500A XT5 IEC60947-2
Part Number: 1SDA101997R1
Quick Summary
ABB 1SDA101997R1 Rating Plug is a reliable current termination accessory for Tmax XT5 molded case circuit breakers, enabling precise plug-in configuration in industrial control and power distribution environments. Engineers often confront space constraints, accessory compatibility gaps, and the risk of non-compliant labeling in fast-paced projects. This rating plug supports IEC60947-2 with RoHS and REACH declarations, plus CMRT and TSCA visibility, ensuring regulatory compliance across global supply chains. By standardizing on the XT5-rated plug, teams gain installation efficiency, predictable lifecycle costs, and reduced downtime in critical applications such as data centers, manufacturing lines, and energy infrastructure.
Product Information
Extended Description
1SDA101997R1 ABB: RATING PLUG In=500 A XT5 IEC
Environmental Product Declaration - EPD
NoDecNee
REACH Declaration
REACh Declaration ABB Sace circuit breakers
RoHS Information
RoHS Declaration ABB Sace circuit breakers
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration
Environmental Information
Breakers - Packaging disposal information
Order Code US and Canada
KXT5TRP500IEC
E-Number (Norway)
4381584
EAN
8056221020411
Minimum Order Quantity
1 piece
Customs Tariff Number
85389099
Product Net Weight
1.6 kg
Package Level 1 Units
box 1 piece
Package Level 1 Width
120 mm
Package Level 1 Height
160 mm
Package Level 1 Depth / Length
190 mm
Package Level 1 Gross Weight
1.7 kg
Package Level 1 EAN
8056221020411
Product Main Type
Accessories for Tmax XT
Product Name
Accessory
Product Type
Accessory
Suitable For
XT5
Suitable for Product Class
SACE Tamx XT
Configuration Type
Loose or configurable
Order Multiple
1 piece
Rated Current (In)
500 A
Standards
IEC60947-2
Data Sheet, Technical Information
SACE Tmax XT IEC Low voltage molded case circuit-breakers Catalog | SACE Tmax XT IEC TECHNICAL CHARACTERISTICS Low voltage molded case circuit-breakers
Declaration of Conformity - CE
Refer to the EU Declaration of the relative Circuit Breaker
Instructions and Manuals
Rating Plug - XT5
ETIM 8
EC002498 - Accessories/spare parts for low-voltage switch technology
ETIM 9
EC002498 - Accessories/spare parts for low-voltage switch technology
IDEA Granular Category Code (IGCC)
5219 >> Switch part or accessory
UNSPSC
39122221
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
eClass
V11.1 : 27371390
Feature: 500 A rated current capability → Business Impact: Handles high-load scenarios with margin, reducing overload risk and downstream equipment stress; Application: Heavy-duty Tmax XT5 panels in manufacturing lines. Feature: Loose or configurable configuration → Business Impact: Flexibility in field retrofits and varying panel layouts, lowering stocking complexity and change-out time; Application: OEM assemblies and retrofit projects. Feature: IEC60947-2 compliance, RoHS, REACH → Business Impact: Regulatory alignment and material compliance streamline approvals and audits; Application: Global industrial installations including data centers and process plants. Feature: Accurate packaging and weight (1.6 kg net, 1.7 kg gross) → Business Impact: Simplified logistics, predictable shipping costs, and safer on-site handling; Application: Warehouse and distribution of spare parts. Feature: Clear documentation and order code (KXT5TRP500IEC) → Business Impact: Procurement accuracy reduces order errors and lead times; Application: US/Canada procurement workflows and electrical distributors. Feature: Comprehensive data sheet and manuals included → Business Impact: Faster commissioning, reduced training time, and lower commissioning risk; Application: Field service teams and maintenance programs.
