ABB 1SDA102012R1 Accessory - 800 A Rating Plug UL489
Part Number: 1SDA102012R1
Quick Summary
ABB 1SDA102012R1 Accessory is a rating plug for Tmax XT systems, enabling safe, configurable current limiting up to 800 A in high-demand installations. Engineers often face delays when replacement parts don’t match XT7-XT7M modules or regulatory requirements. This rating plug ships with CE declarations and RoHS compliance, plus UL489 certification, giving procurement and maintenance teams confidence in conformity and performance. With XT7-XT7M compatibility, you can perform swift plug exchanges during commissioning or routine servicing, reducing downtime while maintaining protection standards. The solution complements a broader ABB ecosystem for Tmax XT, improving lifecycle cost, spare-parts planning, and field service readiness.
Product Information
Extended Description
1SDA102012R1 ABB: RATING PLUG BASIC In=800A XT7-XT7M UL
Environmental Product Declaration - EPD
NoDecNee
REACH Declaration
REACh Declaration ABB Sace circuit breakers
RoHS Information
RoHS Declaration ABB Sace circuit breakers
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration
Environmental Information
Breakers - Packaging disposal information
Order Code US and Canada
KXT7RP800ULB
EAN
8056221020565
Minimum Order Quantity
1 piece
Customs Tariff Number
85389099
Product Net Weight
0.025 kg
Package Level 1 Units
box 1 piece
Package Level 1 Width
120 mm
Package Level 1 Height
160 mm
Package Level 1 Depth / Length
190 mm
Package Level 1 Gross Weight
1.7 kg
Package Level 1 EAN
8056221020565
Product Main Type
Accessories for Tmax XT
Product Name
Accessory
Product Type
Accessory
Suitable For
XT7-XT7M
Suitable for Product Class
SACE Tmax XT
Configuration Type
Loose or configurable
Order Multiple
1 piece
Rated Current (In)
800 A
Standards
UL489
Data Sheet, Technical Information
SACE Tmax XT UL/CSA Low voltage molded case circuit-breakers UL489 and CSA CS22.2 Standards Catalog | SACE Tmax XT UL/CSA TECHNICAL CHARACTERISTICS Low voltage molded case circuit-breakers for UL489 and CSA CS22.2 Standards
Declaration of Conformity - CE
Refer to the EU Declaration of the relative Circuit Breaker
Instructions and Manuals
Changing the rating plug for Ekip Touch, Ekip Dip LSI, Ekip Dip LSIG - XT7M - XT7
ETIM 8
EC002498 - Accessories/spare parts for low-voltage switch technology
ETIM 9
EC002498 - Accessories/spare parts for low-voltage switch technology
IDEA Granular Category Code (IGCC)
5219 >> Switch part or accessory
UNSPSC
39122221
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
eClass
V11.1 : 27371390
Feature → Business Impact → Application: 800 A rated rating plug enables safe high‑current distribution and quick fault isolation, reducing downtime and improving line productivity in manufacturing and data-center environments. This device is UL489 listed and RoHS/CE compliant, ensuring regulatory alignment while simplifying supplier qualification and reducing audit findings during procurement. The XT7-XT7M compatibility guarantees a plug-to-switchgear match, accelerating field replacements and minimizing installation errors in panel assemblies for SACE Tmax XT systems. The 1-piece minimum order quantity, along with clear EAN and order code (KXT7RP800ULB), supports lean logistics and faster job turnaround on site. Users benefit from predictable parts availability and lower total cost of ownership through reduced maintenance intervals and spare-part inventory.
Get a Quick Quote for a ABB 1SDA102012R1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SDA102012R1?
Enquire Now
FAQs
Yes. The 1SDA102012R1 is designed as a rating plug for Tmax XT systems and is compatible with XT7-XT7M assemblies. Use the US/Canada order code KXT7RP800ULB for procurement, and follow the ABB changing instructions to ensure proper fitment with Ekip Touch, Ekip Dip LSI, or Ekip Dip LSIG XT7M modules. The solution supports loose or configurable configurations for flexible field deployments.
The plug is rated for 800 A and is certified to UL489. It also aligns with RoHS and REACH declarations, supporting compliance for EU and global supply chains. This combination ensures suitability for high‑current Tmax XT installations while meeting modern environmental and safety requirements.
Ideal for SACE Tmax XT installations requiring rapid rating changes or upgrades to XT7-XT7M modules. It streamlines commissioning, preventive maintenance, and spare-parts rotation for industrial controls, data centers, and manufacturing lines where high-current protection and quick serviceability are critical.
This ABB accessory carries UL489 certification, a CE declaration, RoHS information, and related compliance notes (REACH, CMRT, TSCA). These certifications help ensure regulatory alignment across North American and European markets, simplifying audits and customer approvals.
With a 1-piece minimum order and clear packaging data (EAN, weight, and dimensions), procurement and logistics are streamlined, reducing downtime during replacements. The compatibility with XT7-XT7M and straightforward installation minimize field service time, delivering faster return-to-operation and lower inventory carrying costs.
