ABB 1SDA102023R1 Accessory for Tmax XT - IEC60947-2
Part Number: 1SDA102023R1
Quick Summary
ABB 1SDA102023R1 is an accessory for Tmax XT switchgear that enables reliable rating plug configurations for high-current applications up to 1250 A. In fast-moving industrial environments, engineers need quick, safe, and compliant ways to adapt protection settings without long downtime. This rating plug supports XT7 and XT7M families, helping you tailor protection to evolving load profiles while maintaining system integrity. The solution aligns with IEC 60947-2 standards and RoHS and CMRT material declarations, with DoC CE references for traceability. By enabling plug-and-play installation and straightforward field changes, it reduces maintenance windows, minimizes error-prone handoffs, and supports procurement consistency across multiple sites. A smart choice when reliability and compliance drive project ROI.
Product Information
Extended Description
1SDA102023R1 ABB: RATING PLUG RC In=1250 A XT7-XT7M IEC
Environmental Product Declaration - EPD
NoDecNee
REACH Declaration
REACh Declaration ABB Sace circuit breakers
RoHS Information
RoHS Declaration ABB Sace circuit breakers
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration
Environmental Information
Breakers - Packaging disposal information
Order Code US and Canada
KXT7RCRP1250IEC
E-Number (Norway)
4381599
EAN
8056221020671
Minimum Order Quantity
1 piece
Customs Tariff Number
85389099
Product Net Weight
0.025 kg
Package Level 1 Units
box 1 piece
Package Level 1 Width
120 mm
Package Level 1 Height
160 mm
Package Level 1 Depth / Length
190 mm
Package Level 1 Gross Weight
1.7 kg
Package Level 1 EAN
8056221020671
Product Main Type
Accessories for Tmax XT
Product Name
Accessory
Product Type
Accessory
Suitable For
XT7, XT7M
Suitable for Product Class
SACE Tmax XT
Configuration Type
Loose or configurable
Order Multiple
1 piece
Rated Current (In)
1250 A
Standards
IEC60947-2
Data Sheet, Technical Information
SACE Tmax XT IEC Low voltage molded case circuit-breakers Catalog | SACE Tmax XT IEC TECHNICAL CHARACTERISTICS Low voltage molded case circuit-breakers
Declaration of Conformity - CE
Refer to the EU Declaration of the relative Circuit Breaker
Instructions and Manuals
Changing the rating plug for Ekip Touch, Ekip Dip LSI, Ekip Dip LSIG - XT7M - XT7
ETIM 8
EC002498 - Accessories/spare parts for low-voltage switch technology
ETIM 9
EC002498 - Accessories/spare parts for low-voltage switch technology
IDEA Granular Category Code (IGCC)
5219 >> Switch part or accessory
UNSPSC
39122221
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
eClass
V11.1 : 27371390
Feature: Rated current (In) 1250 A. Business impact: Enables protection for high-current circuits without oversizing components. Application: Suitable for Tmax XT line configurations in data centers and manufacturing plants. The benefit is faster, safer switching with predictable thermal performance.Feature: Compatibility with XT7 and XT7M. Business impact: Reduces spare parts and configurability complexity across facilities. Application: Standardizes protection strategy for multiple sites, lowering procurement variance and stockouts.Feature: IEC60947-2 compliance. Business impact: Ensures regulatory alignment and audit readiness for low-voltage switchgear projects. Application: Widely adopted in industrial power distribution; simplifies qualification for critical projects.Feature: RoHS and CMRT declarations. Business impact: Improves supply chain traceability and regulatory compliance, reducing risk of material non-conformities. Application: Essential for multinational deployments with strict supplier requirements.Feature: Easy installation and field replacement. Business impact: Minimizes downtime during upgrades and changes, boosting overall equipment effectiveness (OEE). Application: Field service scenarios where quick reconfiguration is needed without specialized tools.Feature: Packaging and orderability (1 piece MOQ, EAN 8056221020671). Business impact: Streamlines inventory planning and e-commerce fulfillment. Application: Procurement and logistics teams gain predictability and faster replenishment.
