ABB 1SDA112967R1 Accessory - 4P 400A XT5, IEC60947-2
Part Number: 1SDA112967R1
Quick Summary
ABB 1SDA112967R1 is an XT5 fixed-part accessory for Tmax XT circuit-breakers. It addresses maintenance downtime and safety challenges by enabling safe withdrawal and modular expansion in high-current systems. Built to IEC60947-2 standards and supported by RoHS, CMRT, and TSCA declarations, it ensures regulatory compliance while aligning with ABB EcoSolutions. Designed for XT5 configurations, this fixed-part supports scalable switchgear assemblies and simplifies procurement for engineering projects requiring reliable high-current distribution. With order code KXT5EWFPVR4-4 and EAN 8056221030212, it integrates smoothly into existing XT5 inventories and downstream maintenance workflows, delivering strong business value through predictable performance and traceable environmental data.
Product Information
Extended Description
1SDA112967R1 ABB: XT5 W FP 400A 4p VR VR IEC
Environmental Product Declaration - EPD
EPD Fixed parts Tmax XT XT5 (IT)
REACH Declaration
REACh Declaration ABB Sace circuit breakers
RoHS Information
RoHS Declaration ABB Sace circuit breakers
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration
Environmental Information
Breakers - Packaging disposal information
Order Code US and Canada
KXT5EWFPVR4-4
E-Number (Norway)
4380504
EAN
8056221030212
Minimum Order Quantity
1 piece
Customs Tariff Number
85389099
Product Net Weight
21.7 kg
Package Level 1 Units
box 1 piece
Package Level 1 Width
360 mm
Package Level 1 Height
340 mm
Package Level 1 Depth / Length
380 mm
Package Level 1 Gross Weight
21.7 kg
Package Level 1 EAN
8056221030212
Product Main Type
Accessories for Tmax XT
Product Name
Accessory
Product Type
Fixed Part
Suitable For
XT5
Suitable for Product Class
SACE Tmax XT
Version
W
Configuration Type
Loose or configurable
Number of Poles
4P
Order Multiple
1 piece
Rated Uninterrupted Current (Iu)
400 A
Standards
IEC60947-2
Sub-type
XT5
Terminal Connection Type
Withdrawable Circuit-Breakers
Data Sheet, Technical Information
1SDC210100D0205 | 1SDC210200D0205
Declaration of Conformity - CE
Refer to the EU Declaration of the relative Circuit Breaker
Instructions and Manuals
Fixed part for withdrawable circuit-breakers - XT5
ETIM 8
EC002043 - Chassis part power circuit breaker
ETIM 9
EC002043 - Chassis part power circuit breaker
IDEA Granular Category Code (IGCC)
4932 >> 3 Pole Non-Interchangeable Trip Electronic Circuit Breakers
UNSPSC
39121616
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
eClass
V11.1 : 27370422
Feature → Business Impact → Application: The 4P configuration supports a robust 400 A rated current, enabling Tmax XT switchgear to handle demanding loads with reduced risk of overheating or contact wear; this translates to longer service intervals and lower maintenance cost in motor control centers and distribution boards. In practice, the XT5 fixed-part ensures reliable withdrawal and modularity for high-current feeders, improving uptime in critical processes across manufacturing lines and data centers. Feature → Business Impact → Application: IEC60947-2 compliance and RoHS/CMRT/TSCA declarations mitigate regulatory risk and support sustainability reporting; this helps compliance teams avoid penalties while enabling green procurement programs. Feature → Business Impact → Application: Loose or configurable configuration and Withdrawable Circuit-Breaker terminals simplify installation, reduce field wiring errors, and speed up panel assembly, benefiting project timelines in OEM builds and retrofit projects. Feature → Business Impact → Application: Environmental and documentation data (EPD, Dossiers, and CE declarations) provide traceability for audits and customer requests, aiding tenders and long-term maintenance planning. Feature → Business Impact → Application: Compact packaging and clear MOP (Minimum Order Quantity 1 piece) simplify stock management and spare-part planning for large installations, improving total cost of ownership across the asset lifecycle.
Get a Quick Quote for a ABB 1SDA112967R1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SDA112967R1?
Enquire Now
FAQs
This fixed-part accessory is designed for Tmax XT XT5 systems with four-pole withdrawable breakers and uses standard XT5 mounting interfaces, ensuring a seamless fit and reliable operation.
The part is rated for 400 A with 4 poles (4P) and complies with IEC60947-2, supporting high-current safety in Tmax XT switchgear configurations.
Yes. The product carries RoHS declaration, REACH information, CMRT, and TSCA declarations, ensuring regulatory and environmental compliance across global markets.
Key documents include Data Sheet numbers 1SDC210100D0205 and 1SDC210200D0205, plus CE declaration references. The fixed-part documentation is accessible through ABB’s technical portal and supplier catalogs.
It reduces maintenance downtime, enhances safety during withdrawal operations, simplifies procurement with a clear order code (KXT5EWFPVR4-4), and supports regulatory compliance and traceability across asset lifecycle management.
