ABB 1SFA619132R1056 Pushbtn - IP66 Front, 2NC
Part Number: 1SFA619132R1056
Quick Summary
ABB 1SFA619132R1056 Pushbtn is a compact momentary switch designed for control panels, machine dashboards, and safety interlocks. Engineers often battle lengthy wiring and panel-space constraints, so a compact, all-in-one pilot device speeds installation and reduces cabinet footprint. This pushbutton delivers rugged protection with front IP66/IP67/IP69K equivalents and meets essential certifications including CE, UKCA, CB, and cURus, supporting global compliance. Its 2NC configuration and non-illuminated, black plastic bezel simplify wiring and identification in dense control schemes. In practical terms, you gain faster field upgrades, lower mounting costs, and predictable maintenance cycles, making it a reliable choice for automation projects in manufacturing, packaging, and process industries.
Product Information
Extended Description
1SFA619132R1056 ABB: The CP33-10B-02 Pushbutton is: Compact - Pushbutton - Momentary - Extended - Black - Non-illuminated - Black Plastic - 2NC -- 300 V
This Pushbutton is part of ABB's compact range, the most efficient all-in-one solution available, reducing installation time and cost.
The compact range has a high level of dust and water resistance.
Minimum Order Quantity
10 piece
Customs Tariff Number
8536508090
Data Sheet, Technical Information
1SFC151007C0201 Pilot Devices the complete offering, Main Catalogue
Instructions and Manuals
Safety instructions & Installation instructions - Pilot Devices
Dimension Diagram
Engraved symbol - 901.svg
Product Net Width
0.03 m
Product Net Height
0.03 m
Product Net Depth / Length
0.06 m
Product Net Weight
0.022 kg
Ambient Air Temperature
Operation -25 ... +70 °C | Storage -40 ... +85 °C
Color
Black
Actuator Type
Extended
Bezel Material
Black Plastic
Illumination
Non-illuminated
Function
Momentary
Device Marking
O
Number of Auxiliary Contacts NC
2
Number of Auxiliary Contacts NO
0
Enclosure Type NEMA
Type1 | Type12 | Type13 | Type3R | Type4 | Type4X
Pollution Degree
3
Rated Insulation Voltage (Ui)
300 V
Rated Impulse Withstand Voltage (Uimp)
6 kV
Rated Frequency (f)
50 / 60 Hz
Rated Operational Voltage
Maximum 300 V
Rated Operational Current DC-13 (Ie)
(24 V) 0.3 A | (125 V) 0.2 A
Rated Operational Current AC-15 (Ie)
(240 V) 2 A | (220 / 240 V) 2 A
Power Loss
Maximum 5 W
Mechanical Durability
0.5 million
Connecting Capacity
Flexible with Ferrule 1 x 0.5...1.5 mm² | Flexible with Ferrule 2 x 0.5...1.5 mm² | Flexible with Insulated Ferrule 1 x 0.5...1.5 mm² | Flexible with Insulated Ferrule 2 x 0.5...1.5 mm² | Flexible 1 x 0.5 ...1.5 mm² | Flexible 2 x 0.5 ...1.5 mm² | Solid 1 x 0.5...1.5 mm² | Solid 2 x 0.5...1.5 mm²
Connection Type
Screw Clamp
Terminal Type
Screw Terminals
Tightening Torque
0.8 N·m
Wire Stripping Length
6 mm
Connecting Capacity UL/CSA
1x 22...14 AWG | 2x 22...14 AWG
Degree of Protection
Front IP66 | Front IP67 | Front IP69K | Terminals IP20
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
REACH Declaration
REACh - Pilot Devices
RoHS Information
RoHS - Pilot Devices
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration for Pilot Devices
WEEE B2C / B2B
Business To Business
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
CB Certificate
CB Certificate, Pilot devices, Compact C
CQC Certificate
CQC Certificate, Pilot Device, TYPE C(CP, C2SS, C3SS, CL, CE, CB, CEP), Made in China
cURus Certificate
CULus Cerrtificate-C-series Pilot Device Compact C
Declaration of Conformity - CCC
CCC Self-Declaration,Pilot Device,Compact C
Declaration of Conformity - CE
CE Declaration of Conformity - Pilot Devices - C
Declaration of Conformity - UKCA
UKCA Declaration of Conformity - Pilot Devices
DNV GL Certificate
DNV/GL Certificate, Pilot Device,Compact C
EAC Certificate
EAC-certificate, Pilot devices, C2SS, C3SS, CP, CPM
Package Level 1 Units
bag 10 piece
Package Level 1 Width
0.125 m
Package Level 1 Depth / Length
0.235 m
Package Level 1 Height
0.05 m
Package Level 1 Gross Weight
0.224 kg
Package Level 1 EAN
7320500245248
Object Classification Code
S
ETIM 6
EC001028 - Push button, complete
ETIM 7
EC001028 - Push button, complete
ETIM 8
EC001028 - Push button, complete
eClass
V11.0 : 27371228
UNSPSC
39121500
E-Number (Finland)
2312983
E-Number (Sweden)
3711294
Feature: Compact ABB CP33-10B-02 pushbutton design with an extended actuator and black bezel. Business Impact: Saves panel space and reduces wiring complexity, enabling quicker panel builds and easier maintenance in tight control cabinets. Application: Ideal for small automation stations, machine controls, and where space is at a premium. Feature: 2NC auxiliary contacts and no illuminated function. Business Impact: Simplifies wiring schemes and lowers energy consumption while delivering clear signaling for PLC inputs. Application: Suitable for basic stop/start interlocks and control circuits in conveyors and packaging lines. Feature: Screw clamp terminals with 0.8 N·m tightening torque and 6 mm wire stripping. Business Impact: Secure terminations with repeatable torque improves reliability in vibration-prone environments and reduces rework. Application: Field wiring in harsh factory floors and panel assemblies. Feature: Rated up to 300 V with AC-15 2 A and DC-13 0.3 A (24 V) / 0.2 A (125 V). Business Impact: Supports common automation loads without requiring additional modules, lowering BOMs. Application: Control relays, contactors, and PLC inputs in general automation. Feature: Durable enclosure and protection: IP66 front, NEMA Type 1/2/3R/4/4X variants, and -25 to +70 C operation. Business Impact: Enables reliable operation in dusty, washdown, and temperature-variant environments, reducing unscheduled downtime. Application: Food & beverage lines, automotive assembly, and process equipment. Feature: Mechanical durability rated at 0.5 million cycles. Business Impact: Longer service life reduces maintenance costs and replacement frequency. Application: High-cycle control stations and safety interlocks in production lines. Feature: Global certifications and RoHS/REACH compliance. Business Impact: Streamlines procurement for multi-region installations and ensures regulatory conformity. Application: Global rollouts and OEM integrations requiring CE/UKCA/CB documentation.
Get a Quick Quote for a ABB 1SFA619132R1056
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SFA619132R1056?
Enquire Now
FAQs
This pushbutton uses screw clamp terminals with a tightening torque of 0.8 N·m and 6 mm wire stripping length, supporting flexible conductor sizes up to 1.5 mm². It accepts both ferrule and solid conductors, simplifying field termination and ensuring secure, vibration-resistant connections in panel assemblies.
Rated operational voltage is up to 300 V. DC-13 is 0.3 A at 24 V and 0.2 A at 125 V, while AC-15 is 2 A at 240/220 V. These ratings suit basic control circuits, relays, and PLC input modules, enabling reliable signaling without external interlocks or relays for many standard automation tasks.
Yes. It offers front IP66 protection and is compatible with demanding environments. The enclosure supports NEMA types including Type1, Type12, Type13, Type3R, Type4, and Type4X, with operation from -25 to +70 °C, making it well-suited for manufacturing floors, packaging lines, and food/beverage processing areas.
The device carries CE and UKCA declarations of conformity, CB and cURus certificates, and additional declarations from agencies like EAC and DNV GL. RoHS and REACH compliance are documented, and WEEE guidance indicates B2B disposal responsibilities for this pilot device family.
With a 0.5 million mechanical durability rating and screw-terminal terminations, maintenance intervals are infrequent and simple. Its compact footprint reduces panel redesign costs, and its broad certifications simplify procurement across regions, contributing to a lower total cost of ownership in multi-site automation projects.
