ABB 1SFA619502R1076 Machine Stop - Front IP66
Part Number: 1SFA619502R1076
Quick Summary
Machine Stop is a compact, maintained mushroom-stop device designed for quick, safe shutdown in control panels and machinery. It addresses common panel-wiring bottlenecks by delivering an all-in-one solution that reduces installation time and field wiring. The unit carries CE and UKCA declarations and UL/CSA approvals, with IP-rated front protection (IP66) to withstand dust and wash-down environments in harsh factories. It operates from 24 to 300 V and uses a 1NO+1NC contact configuration for flexible interlock and reset behavior. With a compact footprint and weight under 0.068 kg, it supports faster commissioning and lower total cost of ownership while meeting industry safety expectations. Designed for engineers tasked with scalable automation, it helps future-proof equipment without compromising safety.
Product Information
Extended Description
1SFA619502R1076 ABB: The CE3K1-10B-11 Machine Stop is: Compact - Machine Stop - Key release - Maintained - Mushroom 30mm - Black - Non-illuminated - 1NO+1NC - 1 NO - 1 NC - 24 ... 300 V
This Machine Stop is part of ABB's compact range, the most efficient all-in-one solution available, reducing installation time and cost.
The compact range has a high level of dust and water resistance.
Minimum Order Quantity
10 piece
Customs Tariff Number
8536508090
Data Sheet, Technical Information
1SFC151007C0201 Pilot Devices the complete offering, Main Catalogue
Instructions and Manuals
Safety instructions & Installation instructions - Pilot Devices
Product Net Width
0.03 m
Product Net Height
0.03 m
Product Net Depth / Length
0.103 m
Product Net Weight
0.068 kg
Ambient Air Temperature
Operation -25 ... +70 °C | Storage -40 ... +85 °C
Color
Black
Actuator Type
Mushroom 30mm
Bezel Material
n/a
Illumination
Non-illuminated
Function
Maintained
Sub-Function
Key release
Key Code
Key code 71
Number of Auxiliary Contacts NC
1
Number of Auxiliary Contacts NO
1
Enclosure Type NEMA
Type1 | Type12 | Type13 | Type3R | Type4 | Type4X
Pollution Degree
3
Rated Insulation Voltage (Ui)
300 V
Rated Impulse Withstand Voltage (Uimp)
6 kV
Rated Frequency (f)
50 / 60 Hz
Rated Operational Voltage
24 ... 300 V
Rated Operational Current DC-13 (Ie)
(24 V) 0.3 A | (125 V) 0.2 A
Rated Operational Current AC-15 (Ie)
(240 V) 2 A | (220 / 240 V) 2 A
Power Loss
Maximum 5 W
Connecting Capacity
Flexible with Ferrule 1 x 0.5...1.5 mm² | Flexible with Ferrule 2 x 0.5...1.5 mm² | Flexible with Insulated Ferrule 1 x 0.5...1.5 mm² | Flexible with Insulated Ferrule 2 x 0.5...1.5 mm² | Flexible 1 x 0.5 ...1.5 mm² | Flexible 2 x 0.5 ...1.5 mm² | Solid 1 x 0.5...1.5 mm² | Solid 2 x 0.5...1.5 mm²
Connection Type
Screw Clamp
Terminal Type
Screw Terminals
Tightening Torque
0.8 N·m
Wire Stripping Length
6 mm
Connecting Capacity UL/CSA
1x 22...14 AWG | 2x 22...14 AWG
Degree of Protection
Front IP66 | Front IP67 | Front IP69K | Terminals IP20
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
REACH Declaration
REACh - Pilot Devices
RoHS Information
RoHS - Pilot Devices
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration for Pilot Devices
WEEE B2C / B2B
Business To Business
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
CB Certificate
CB-Certificate-CE,CEP
CQC Certificate
CQC Certificate, Pilot Device, TYPE C(CP, C2SS, C3SS, CL, CE, CB, CEP), Made in China
cULus Certificate
CULus Cerrtificate-C-series Pilot Device Compact C
cURus Certificate
CULus Cerrtificate-C-series Pilot Device Compact C
Declaration of Conformity - CCC
CCC Self-Declaration,Pilot Device,Compact C
Declaration of Conformity - CE
CE Declaration of Conformity - Emergency Stop-CE,CEPY
Declaration of Conformity - UKCA
UKCA Declaration of Conformity - Pilot Devices
DNV GL Certificate
DNV/GL Certificate, Pilot Device,Compact C
EAC Certificate
EAC-certificate, Pilot devices, CE, CEPY, MEPY
Package Level 1 Units
bag 1 piece
Package Level 1 Width
0.165 m
Package Level 1 Depth / Length
0.09 m
Package Level 1 Height
0.035 m
Package Level 1 Gross Weight
0.07 kg
Package Level 1 EAN
7320500355961
Object Classification Code
S
ETIM 6
EC002034 - Emergency stop complete
ETIM 7
EC001028 - Push button, complete
ETIM 8
EC001028 - Push button, complete
eClass
V11.0 : 27371228
UNSPSC
39122216
IDEA Granular Category Code (IGCC)
5212 >> Push button for distribution board
E-Number (Finland)
2312173
E-Number (Sweden)
3711554
The compact all-in-one design reduces installation time and panel space, lowering labor costs and expediting project timelines in new builds or panel refurbishments. Business impact: faster commissioning and fewer mounting attempts translate into measurable productivity gains on high-mix production lines. Application: control panels and small enclosures where space is at a premium. The maintained 1NO+1NC mushroom-30 mm actuator with key release delivers deliberate, fail-safe stopping behavior, ensuring the machine remains stopped until a reset is performed. This improves operator safety and reduces risk of unintended restarts on conveyors or tooling lines. Impact: enhanced risk management and compliant shutdown sequences. Application: packaging, machine tools, and material handling. The device supports a broad operating range of 24–300 V and 50/60 Hz, enabling seamless integration with mixed PLCs and drive systems. Impact: universal compatibility reduces inventory variety and simplifies wiring architecture. Application: mixed-control environments and retrofits. Front IP66 protection provides robust resistance to dust and wash-down processes, while the compact form factor minimizes enclosure footprint. Impact: lower maintenance costs and higher uptime in harsh environments such as manufacturing floors and automotive workshops. Application: wash-down zones and dusty production areas. Screw clamp terminals with 0.8 N·m tightening torque ensure reliable, vibration-resistant connections and straightforward field wiring. Impact: fewer call-backs for loose wires and re-terminations. Application: panel installations with tight space constraints. The array of certifications—CE, UKCA, UL/CSA, CB—supports global deployment and reduces vendor risk. Impact: streamlined multimarket compliance and faster procurement cycles. Application: international projects and regulated industries. Overall, this device delivers a compact, rugged, and compliant solution with a footprint that fits tight spaces while delivering predictable, safe stop functionality.
Get a Quick Quote for a ABB 1SFA619502R1076
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SFA619502R1076?
Enquire Now
FAQs
This Machine Stop uses screw clamp terminals and a compact 30 mm mushroom actuator, designed for direct mounting in standard control panels. Compatible with typical ABB pilot devices through uniform 1NO+1NC configuration, it simplifies panel upgrades. When wiring, follow the 0.8 N·m tightening torque specification and 6 mm wire stripping length to ensure reliable terminations and minimize contact resistance. Its small footprint (0.03 m x 0.03 m) helps conserve panel space in tight installations and retrofits.
Key specs include a rated operational voltage range of 24–300 V, both AC and DC support at 50/60 Hz, and a 1NO+1NC contact arrangement for interlocking and reset logic. The device withholds a rated insulation voltage of 300 V and a rated impulse withstand voltage of 6 kV, providing safe operation in standard control circuits while meeting international safety standards. Power loss is limited to a maximum of 5 W, supporting energy-efficient panel designs.
Yes. The front protection is IP66, with additional variants offering IP67/IP69K compatibility for harsher wash-down environments. This makes the unit well-suited for food and beverage, automotive, and metalworking sectors where dust, water, or high-pressure cleaning are common. The durable enclosure, together with RoHS/REACH compliance, helps ensure long-term reliability and minimal maintenance in challenging production floors.
The product carries CE and UKCA declarations, plus UL/CSA and CB certifications, indicating broad regulatory compliance across Europe, North America, and other markets. This reduces the need for re-certification during regional deployments, accelerates procurement cycles, and supports multi-market rollout plans for tooling, packaging, and automation projects.
Maintenance benefits stem from a robust IP-rated front, screw clamp terminations that resist loosening under vibration, and a compact footprint that minimizes enclosure wear. ROI comes from faster commissioning, reduced wiring complexity, lower spare-part diversity (single 1NO+1NC device), and lower risk of unintended stops due to key-release mechanisms. For projects with frequent line changeovers or line expansions, these factors translate into shorter downtime and improved overall equipment effectiveness.
