ABB 1SFA619811R2001 Enclosure - IP69K front & NEMA Type4X
Part Number: 1SFA619811R2001
Quick Summary
ABB 1SFA619811R2001 Enclosure protects control components in industrial automation panels. In harsh environments, reliable sealing, compact footprint, and simple serviceability are essential to minimize downtime. This product carries CE and UKCA declarations with IP66, IP67, and IP69K front protection plus housing protection, supporting global compliance for panel builders. Its lightweight plastic housing aids installation in tight spaces, while the 1NO+1NC configuration and horizontally mounted design streamline wiring and maintenance. Designed for CEP1 pilot-device applications, it helps OEMs and integrators deliver rugged, scalable control solutions with lower total cost of ownership.
Product Information
Extended Description
1SFA619811R2001 ABB: Assembled Enclosure with Shroud - 40mm Machine Stop - Twist Release - 1NO+1NC - Horisontally mounted
Minimum Order Quantity
1 piece
Customs Tariff Number
85369001
Product Main Type
CEP1
Data Sheet, Technical Information
1SFC151007C0201 Pilot Devices the complete offering, Main Catalogue
Instructions and Manuals
Safety instructions & Installation instructions - Pilot Devices
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
0.065 m
Product Net Depth / Length
0.065 m
Product Net Height
0.048 m
Product Net Weight
0.124 kg
Accessory Type
Enclosure
Color
Dark grey/Light grey
Enclosure Type NEMA
Type1 | Type12 | Type13 | Type3R | Type4 | Type4X
Housing Material
Plastic
Number of Auxiliary Contacts NC
1
Number of Auxiliary Contacts NO
1
Rated Operational Voltage
24 ... 300 V
Ambient Air Temperature
Operation -25 ... +70 °C | Storage -40 ... +85 °C
Degree of Protection
Front IP66 | Front IP67 | Front IP69K | Housing IP69K | Housing IP66 | Housing IP67 | Terminals IP20
Material
Plastic
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
REACH Declaration
REACh - Pilot Devices
RoHS Information
RoHS - Pilot Devices
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
SCIP
d247b7d7-1b5a-4400-8a7b-b6fc968f8135 Sweden (SE)
Simplified SCIP
168f4c4c-f760-4bf4-81a9-7e864e260405 Germany (DE) | 31de3f7e-be84-4685-a20b-573ce448fc7b Czech Republic (CZ) | a0658b55-3b4e-47e0-9536-4e63914543d5 Germany (DE) | 9e81958b-3cd3-48bc-9f33-0ce6a9066d03 Croatia (HR) | 7205e672-4237-4170-b79f-177fd473ef2c Germany (DE) | 8a9a7183-a9bd-4a05-9ffd-9a231b232309 Finland (FI) | b75e4617-693a-49a3-8071-86c404e08104 Italy (IT) | d5452a4e-8218-4fd4-9490-6aac9d1e2619 Belgium (BE) | ef0e87fb-4128-46ef-a8b9-104efc477b58 Denmark (DK) | 6038b405-14e4-426f-8c71-ec4c0c722975 Norway (NO) | 9f830f29-a8a2-4c18-874a-7b7a84a50e74 Poland (PL) | af767949-a10b-4395-9729-aee3950f3388 Germany (DE) | 0e229573-8671-48bc-845b-10159520d1a5 Hungary (HU) | f8750cde-16d9-4754-b795-9dfa97c784e4 Germany (DE) | c5561d0e-2bcc-4985-9ccf-68e2c1657e7f France (FR) | 25338a15-c703-4fb2-a102-86f7d20d4635 Spain (ES) | 44ef6704-9fb1-4dd3-aa30-fb06d6647b99 Belgium (BE) | e864295a-db61-4e34-9e40-f39896783b63 France (FR) | 49604ac4-5eee-4c72-a9f6-6614e6c79122 Sweden (SE) | bd38560e-0338-46f1-ad5f-3f582561e886 Poland (PL) | f2944641-179b-4a9f-bab3-b376e49385d8 Bulgaria (BG) | afe19c39-eeae-4be2-8106-ffe77f491142 Portugal (PT) | 802b6686-e790-4011-baa4-1379f6de1914 Hungary (HU) | 18fa14dc-7dd7-43e2-82f3-5b350c94251d Greece (GR) | 2cc13716-dbce-42c0-a330-58bce5b98bd4 Poland (PL) | d72fead3-fb84-4b92-ab6d-1c6d1bdfacc7 Netherlands (NL) | 265d2788-07eb-41b4-9fa3-2ae989fc1422 Estonia (EE)
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration for Pilot Devices
WEEE Category
Product Not in WEEE Scope
CB Certificate
CB-Certificate-CE,CEP
CQC Certificate
CQC Certificate, Pilot Device, TYPE C(CP, C2SS, C3SS, CL, CE, CB, CEP), Made in China
cURus Certificate
CULus Cerrtificate-C-series Pilot Device Compact C
Declaration of Conformity - CCC
CCC Self-Declaration,Pilot Device,Compact C
Declaration of Conformity - CE
CE Declaration of Conformity - Emergency Stop-CE,CEPY
Declaration of Conformity - UKCA
UKCA Declaration of Conformity - Pilot Devices
DNV GL Certificate
DNV/GL Certificate, Pilot Device,Compact C
EAC Certificate
EAC-certificate, Pilot devices, CEP, MEP
Package Level 1 Units
bag 1 piece
Package Level 1 Width
0.1 m
Package Level 1 Depth / Length
0.1 m
Package Level 1 Height
0.048 m
Package Level 1 Gross Weight
0.124 kg
Package Level 1 EAN
7320500358160
eClass
V11.0 : 27371216
E-Number (Finland)
2312187
E-Number (Norway)
4373379
E-Number (Sweden)
3705521
ETIM 6
EC000225 - Control circuit devices combination in enclosure
ETIM 7
EC000225 - Control circuit devices combination in enclosure
ETIM 8
EC000225 - Control circuit devices combination in enclosure
ETIM 9
EC000225 - Control circuit devices combination in enclosure
IDEA Granular Category Code (IGCC)
4478 >> Electrical pushbutton enclosure
Object Classification Code
S
UNSPSC
39121326
Feature: Robust IP-rated protection with front IP66, IP67, IP69K and housing IP69K/IP66/IP67; Business Impact: Reduces ingress risk in wash-downs, dust-prone environments, and vibratory panels, lowering preventive maintenance needs; Application: Ideal for outdoor machines and food & beverage lines where frequent washdowns occur. Feature: NEMA compatibility Type1, Type12, Type13, Type3R, Type4, Type4X; Business Impact: Enables flexible panel mounting across diverse standards, reducing customization time; Application: Global installations with varied enclosure coding requirements. Feature: Lightweight plastic housing (0.124 kg) with compact footprint (0.065 m W × 0.065 m D × 0.048 m H); Business Impact: Easier handling, faster assemblies, and smaller control cabinets, cutting labor and cabinet costs; Application: Space-constrained automation booths and compact control stations. Feature: 40 mm machine stop and twist-release mechanism with 1NO+1NC auxiliary contacts; Business Impact: Quick access for maintenance and safe, reliable operation; Application: CEP1 pilot-device configurations in compact control enclosures. Feature: Rated operational voltage 24–300 V and wide ambient range (-25 to +70 °C operating, -40 to +85 °C storage); Business Impact: Supports diverse control networks and resilient performance in varying climates; Application: Industrial automation, machine controls, and remote installations. Feature: Comprehensive certifications and compliance (CE, UKCA, CB, cURus, CCC, EAC) plus RoHS/REACH and SCIP declarations; Business Impact: Simplifies global procurement and regulatory acceptance; Application: International panel builds with strict compliance needs. Feature: Availability of data resources (Data Sheet, CAD drawings, installation instructions); Business Impact: Speeds up design verification, reduces errors, and accelerates time-to-market; Application: Engineering design and procurement workflows for pilot devices and control enclosures.
Get a Quick Quote for a ABB 1SFA619811R2001
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SFA619811R2001?
Enquire Now
FAQs
Installation starts with mounting the enclosure horizontally, then securing it with the 40 mm machine stop for precise positioning. Use the twist-release access for quick wiring and install the 1NO+1NC auxiliary contacts to integrate with your control circuit. Refer to the CAD drawings and installation instructions for exact screw layouts and cable entry guidelines.
The enclosure is CE and UKCA certified, with CB, cURus, and EAC declarations, and RoHS/REACH compliance. It features front protection IP66, IP67, IP69K and housing protection IP69K/IP66/IP67, making it suitable for harsh industrial environments and wash-downs.
Yes, it is designed for CEP1 pilot-device configurations, including a 1NO+1NC auxiliary contact setup. The enclosure supports a compact footprint and a shrouded assembly suitable for horizontal mounting, enabling reliable operation with CEP1 accessories and related pilot-device components.
Operation from -25 to +70 °C and storage from -40 to +85 °C cover typical factory to outdoor climates. It tolerates up to 2000 m altitude without derating and provides multiple IP ratings to withstand dust, water jets, and high-pressure spray in demanding facilities.
Data sheets, installation instructions, and CAD dimensional drawings (2D/3D) are available to assist integration. Look for datasheets like 1SFC151007C0201 and CAD files to streamline design validation and accelerate panel fabrication.
