ABB 1SFL597001R7000 Contactor - UL/CSA 650 A
Part Number: 1SFL597001R7000
Quick Summary
AF460-30-00-70 Contactor provides reliable motor control for heavy-duty drives in manufacturing and automation. Users struggle with voltage variations that cause unnecessary energy waste and inconsistent starts. CE, UKCA, and UL/CSA certifications, with RoHS and REACH declarations, support global deployment. Built-in surge protection, AF technology, and easy add-on blocks reduce panel energy use, downtime, and wiring effort. This block contactor also supports a wide coil voltage range and compact footprint for flexible installation. With a 3-pole main circuit and 1000 V insulation, it handles UL and EN motor control standards across varied environments. Designed for motors up to 250 kW at 400 V AC (AC-3) and 700 A in general use, it scales with your system.
Product Information
Extended Description
1SFL597001R7000 ABB: The AF460-30-00-70 is a 3 pole - 1000 V IEC or 600 V UL contactor with Main Circuit Bars, controlling motors up to 250 kW / 400 V AC (AC-3) or 400 hp / 480 V UL and switching power circuits up to 700 A (AC-1) or 650 A UL general use. Thanks to the AF technology, the contactor has a wide control voltage range (100-250 V 50/60 Hz and DC), managing large control voltage variations, reducing panel energy consumptions and ensuring distinct operations in unstable networks. Furthermore, surge protection is built-in, offering a compact solution. AF contactors have a block type design, can be easily extended with add-on auxiliary contact blocks and an additional wide range of accessories.
Minimum Order Quantity
1 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
1SBC100214C0202 - Main catalog Motor protection and control Manual motor starters, contactors and overload relays (PDF) - Edition 2024
Data Sheet, Technical Information (Part 2)
Contactors and Overload relays guide
Instructions and Manuals
1SFC380023-en
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
186 mm
Product Net Depth / Length
216 mm
Product Net Height
278 mm
Product Net Weight
10.6 kg
Number of Main Contacts NO
3
Number of Main Contacts NC
0
Number of Auxiliary Contacts NO
0
Number of Auxiliary Contacts NC
0
Number of Poles
3P
Rated Operational Voltage
Main Circuit 1000 V
Rated Operational Current AC-1 (Ie)
(1000 V) 40 °C 700 A | (1000 V) 55 °C 600 A | (1000 V) 60 °C 600 A | (1000 V) 70 °C 480 A | (690 V) 40 °C 700 A | (690 V) 60 °C 600 A | (690 V) 70 °C 480 A
Rated Operational Current AC-3 (Ie)
(415 V) 55 °C 460 A | (440 V) 55 °C 460 A | (500 V) 55 °C 460 A | (690 V) 55 °C 400 A | (1000 V) 55 °C 200 A | (380 / 400 V) 55 °C 460 A | (220 / 230 / 240 V) 55 °C 460 A
Rated Operational Power AC-3 (Pe)
(415 V) 250 kW | (440 V) 250 kW | (500 V) 315 kW | (690 V) 355 kW | (1000 V) 280 kW | (380 / 400 V) 250 kW | (220 / 230 / 240 V) 132 kW
Rated Short-time Withstand Current Low Voltage (Icw)
at 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 4400 A | at 40 °C Ambient Temp, in Free Air, from a Cold State 15 min 840 A | at 40 °C Ambient Temp, in Free Air, from a Cold State 1 min 2500 A | at 40 °C Ambient Temp, in Free Air, from a Cold State 1 s 4600 A | at 40 °C Ambient Temp, in Free Air, from a Cold State 30 s 3100 A
Rated Insulation Voltage (Ui)
acc. to IEC 60947-4-1 and VDE 0110 (Gr. C) 1000 V | acc. to UL/CSA 600 V
Maximum Electrical Switching Frequency
300 cycles per hour
Mechanical Durability
3 million
Maximum Mechanical Switching Frequency
300 cycles per hour
Rated Control Circuit Voltage (Uc)
50 Hz 100 ... 250 V
Coil Consumption
Holding at Max. Rated Control Circuit Voltage 50 Hz 12 V·A | Holding at Max. Rated Control Circuit Voltage 60 Hz 12 V·A | Pull-in at Max. Rated Control Circuit Voltage 50 Hz 955 V·A | Pull-in at Max. Rated Control Circuit Voltage 60 Hz 955 V·A | Pull-in at Max. Rated Control Circuit Voltage DC 895 V·A
Power Loss
at Rated Operating Conditions per Pole 21 W
Terminal Type
Main Circuit: Bars
Product Name
Block Contactor
NEMA Size
6
Horsepower Rating NEMA
(200 V AC) Three Phase 150 Hp | (230 V AC) Three Phase 200 Hp | (460 V AC) Three Phase 400 Hp | (575 V AC) Three Phase 400 Hp
Maximum Operating Voltage UL/CSA
Main Circuit 1000 V
General Use Rating UL/CSA
(1000 V AC) 650 A
Horsepower Rating UL/CSA
(200 ... 208 V AC) Three Phase 150 Hp | (220 ... 240 V AC) Three Phase 200 Hp | (440 ... 480 V AC) Three Phase 400 Hp | (550 ... 600 V AC) Three Phase 500 Hp
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
REACH Declaration
REACH - Letter of Confirmation for block contactors, contactor relays, installation contactors, mini contactors, mini contactor relays, thermal overload relays, electronic overload relays and related accessories
RoHS Information
RoHS II declaration for block contactors, installation contactors, mini contactors, mini contactor relays, thermal overload relays, electronic overload relays and related accessories
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration for Contactors
WEEE B2C / B2B
Business To Business
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
ABB EcoSolutions
Yes
ABB Site Meeting Group Waste To Landfill Target
Non-hazardous waste is sent to a landfill, where there is no alternative option available within 100km of a facility
End Of Life Disassembling Instructions
End-of-life instruction - AF(S)400(B)-**;AF(S)460(B)-**;AF460N6
Environmental Product Declaration - EPD
Environmental Product Declaration, Contactors, AF(S)400-AF(S)460 (SE)
Improved Energy Efficiency for Customers
Product Efficiency - Product considered more energy-efficient compared to similar product on market or older products from the same line
Recyclability Rate of the Product acc. to EN45555
Design for Closing Resource Loops - Standard EN45555 - 63.1 %
Sustainable Material Content in Product (wt. %)
Recycled Metal - 37 %
ABS Certificate
ABS Certificate, Contactor, AF400...AF2050 (Sweden)
BV Certificate
BV Certificate, Contactor, AF400 ... AF2850
CB Certificate
SE-82316
CCS Certificate
CCS Certificate, Contactor, AF116 to AF2850 (Sweden)
CQC Certificate
CQC Certificate, AC Contactor, AF400-30-*-*,AF460-30-*-*,AFS400-30-*-*, AFS460-30-*-*, Made in Sweden | CQC Certificate, Contactor, AF400, AF460, Made in China
Declaration of Conformity - CCC
CCC Declaration of Conformity, AC Contactor, AF400-30-*-*,AF460-30-*-*,AFS400-30-*-*, AFS460-30-*-*, Made in Sweden | CCC Declaration of Conformity, Contactor, AF400, AF460, Made in China
Declaration of Conformity - CE
CE Declaration of Conformity - Contactor - AF400...AF2850
Declaration of Conformity - UKCA
UK Declaration of Conformity - Contactors >100A
DNV GL Certificate
DNV Certificate, Contactor, AF400...AF2850
EAC Certificate
9AKK107046A8618
LR Certificate
Lloyds register Certificate, Contactor, AF400...AF2850
PRS Certificate
PRS Certificate - AF116...AF1650
RINA Certificate
RINA Certificate, AF95, AF110, AF145, AF185, AF210, AF260, AF300, AF400, AF460, AF580, AF750, AF1250, AF1350, AF1650, AF2050, AF2650, AF116, AF140, AF146, AF190, AF205, AF265, AF305, AF370
RMRS Certificate
9AKK107045A6978
UL Certificate
cULus Certificate, Contactor, AF400, AF460, AFS400, AFS460
UL Listing Card
UL_E36588
Package Level 1 Units
box 1 piece
Package Level 1 Width
280 mm
Package Level 1 Depth / Length
375 mm
Package Level 1 Height
310 mm
Package Level 1 Gross Weight
12 kg
Package Level 1 EAN
7320500381151
Object Classification Code
Q
ETIM 7
EC000066 - Power contactor, AC switching
ETIM 8
EC000066 - Power contactor, AC switching
ETIM 9
EC000066 - Power contactor, AC switching
eClass
V11.0 : 27371003
UNSPSC
39121529
IDEA Granular Category Code (IGCC)
4758 >> Iec Contactors
Feature: three-pole main contacts with main circuit bars and 1000 V insulation. Benefit: supports high current while simplifying wiring, enabling a smaller cabinet footprint and faster commissioning. Application: ideal for heavy-duty motors up to 250 kW at 400 V AC (AC-3) and 700 A general use in manufacturing lines. Feature: coil voltage range 100–250 V (AC) and DC compatibility under AF technology. Benefit: absorbs voltage variations and reduces control circuit energy consumption, improving overall panel efficiency. Application: well suited for installations with fluctuating supply or remote drives, such as packaging lines or process equipment. Feature: built-in surge protection and AF technology for robust operation. Benefit: enhances reliability in unstable networks and reduces replacement costs due to arcing or nuisance trips. Application: ensures steady motor starts in conveyors, pumps, and machine tools with variable loads. Feature: extendable with add-on auxiliary contact blocks; compatible with 2D/3D CAD drawings. Benefit: flexible control logic expansion and streamlined engineering, saving time during integration. Application: ideal for projects requiring future expansion or integration with PLCs and safety circuits. Feature: energy efficiency and lifecycle performance. Benefit: 21 W per pole power loss and 3 million mechanical cycles deliver long-term cost savings and lower total cost of ownership. Application: maintenance planning and energy management in large-scale automation cells.
Get a Quick Quote for a ABB 1SFL597001R7000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SFL597001R7000?
Enquire Now
FAQs
The 1SFL597001R7000 is a 3-pole block contactor designed with main circuit bars for easy integration. It supports add-on auxiliary contact blocks, allowing you to expand control circuits without replacing the base unit. This simplifies PLC interfacing and safety circuit wiring, reducing commissioning time and enabling scalable control logic as your system evolves.
For AC-3 duty, the contactor can carry up to about 460 A at 415–690 V depending on temperature. For AC-1 general use, it can reach around 700 A at 380–400 V and up to 700 A at 690 V in the cold state, with lower ratings at higher ambient temperatures. These values enable motor starting and running for common industrial loads while maintaining a comfortable safety margin.
Yes. With three main contacts, 1000 V insulation, and AC-3 ratings suitable for motor loads, this device is well suited for conveyors and pumps. The built-in surge protection and AF technology mitigate voltage fluctuations, improving start reliability and reducing panel energy waste in continuous-duty applications.
This contactor carries CE and UL/CSA certifications, plus UKCA where applicable. It also aligns with RoHS and REACH declarations, providing regulatory peace of mind for European and North American deployments and supporting sustainable manufacturing initiatives.
The device offers low power loss (about 21 W per pole) and up to 3 million mechanical cycles, reducing energy use and replacement costs over time. Its compatibility with auxiliary blocks and CAD files speeds installation and future expansion, lowering maintenance time and enabling easier upgrades as production needs change.
