ABB CR-S012VDC1RG Pluggable Interface Relay - UL 508
Part Number: 1SVR405501R2020
Quick Summary
The ABB CR-S012VDC1RG pluggable interface relay provides reliable isolation for signal amplification in control panels. Designers often struggle with mounting footprint, contact wear, and reliability in compact automation cabinets. UL 508, CSA, and VDE certifications underpin safe, compliant installations across North American and European markets. With DIN‑rail compatibility, gold-plated contacts, and a 12 V DC control supply, this relay supports efficient, scalable control architectures. In short, it helps reduce panel size, boost reliability, and streamline service with plug‑in convenience. Its compact 5x15x28 mm footprint and IP20 enclosure make it ideal for machine builders needing fast deployment and easier spare parts management.
Product Information
Extended Description
1SVR405501R2020 ABB: The CR-S012VDC1RG is a slim pluggable interface relay, with gold-plated output contacts, which is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. Plugged into a socket, the combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail. This relay operates with a 12 V DC rated control supply voltage and has a 1 c/o (SPDT) output with contacts rated at 250 V / 6 A.This slim pluggable interface relays may be used for electrical isolation, amplification and signal matching. Its gold-plated contacts ensure contact reliability particularly necessary in applications where small currents and loads are to be switched. The CR-S relays are 6.2 mm wide and therefore allow for the switching of high currents on a small footprint. Moreover, CR-S relays are UL 94-V0 certified, improving safety by providing high levels flame retardation. Screw and spring sockets, jumper bars and markers are available as accessories.
EAN
4013614499111
Minimum Order Quantity
10 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Interface relays and optocouplers
Instructions and Manuals
2CDC117022D0201
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
5 mm
Product Net Height
15 mm
Product Net Depth / Length
28 mm
Product Net Weight
0.005 kg
Function
Pluggable slim interface relay CR-S
Sub-Function
Relay with gold-plated contacts
Rated Control Supply Voltage (Us)
12 V DC
Output
1 c/o (SPDT) contact
Output Signal
250 V / 6 A
Rated Operational Current AC-12 (Ie)
(230 V) 6 A
Rated Operational Current DC-12 (Ie)
(24 V) 6 A
Rated Operational Current DC-13 (Ie)
(24 V) 1 A
Degree of Protection
IP20
Overvoltage Category
III
Pollution Degree
2
Standards
CAN/CSA C22.2 No.14 | IEC/EN 61810-1 | UL 508
Ambient Air Temperature
Operation -40 ... +85 °C | Storage 0 ... +40 °C
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
1SVD981001-4400
RoHS Status
Following EU Directive 2011/65/EU
CQC Certificate
CQC Certificate - CR-S range pluggable interface relays
CSA Certificate
CSA Certificate – CR-S range pluggable interface relays
cUR Certificate
cUR_E244330
UR Certificate
UR (ANSI/UL 508) Certificate - Pluggable interface relays / optocouplers CR-M, CR-MX, CR-P, CR-S, CR-U range
VDE Certificate
VDE Certificate - CR-S range pluggable interface relays and sockets with screw terminals
Package Level 1 Units
box 10 piece
Package Level 1 Width
300 mm
Package Level 1 Depth / Length
7.4 mm
Package Level 1 Height
23.7 mm
Package Level 1 Gross Weight
0.06 kg
Package Level 1 EAN
4013614486449
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
E-Number (Finland)
2712353
E-Number (Sweden)
4001383
Feature: Slim, pluggable interface design with a 6.2 mm width and compact 5 mm net width footprint. Business impact: Enables high-density installation on DIN rails or direct PCB mounting, reducing panel footprint and wiring complexity. Application: Perfect for space-constrained control cabinets and multi-channel automation where quick plug-in replacement minimizes downtime. Feature: Gold-plated contacts for enhanced reliability. Business impact: Ensures signal integrity and long-term contact performance, especially for small currents. Application: Signal isolation and amplification tasks in automation panels where repeatable switching is critical. Feature: 12 V DC control, SPDT output rated at 250 VAC and 6 A. Business impact: Direct compatibility with common control circuits and safe load switching. Application: Wiring logic signals to actuators, sensors, and auxiliary relays in machine controls. Feature: IP20 protection and established certifications (UL 508, CSA, VDE). Business impact: Regulatory compliance and safe operation across regions, reducing certification time for global deployments. Application: Factory automation and machinery that must meet cross-border safety standards. Feature: Compatibility with ABB sockets and available accessories (screw/spring sockets, markers). Business impact: Ease of installation and maintenance; flexible configuration for scalable architectures. Application: Quick field upgrades and adaptable control panels across generations of equipment. Feature: Robust operating range (-40 to +85°C) and UL 94‑V0 flame retardant construction. Business impact: Reliable performance in harsh environments and safer design margins. Application: Industrial environments with temperature extremes and strict safety requirements.
Get a Quick Quote for a ABB 1SVR405501R2020
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR405501R2020?
Enquire Now
FAQs
The CR-S012VDC1RG supports direct PCB mounting or use with ABB sockets and optional screw or spring sockets. It is designed for DIN rail snap-on mounting, enabling fast, tool-free installation in compact control panels. Its 6.2 mm width ensures high-density layouts without compromising clearance for adjacent components.
Key specs include a 12 V DC rated control voltage, SPDT output, and a 250 VAC / 6 A contact rating. It also supports AC-12 (230 V, 6 A) and DC-12 (24 V, 6 A) operation, with DC-13 (24 V, 1 A) limits. This makes it suitable for signal isolation, amplification, and control tasks in typical industrial circuits.
Yes. It operates from -40 to +85°C (with storage 0 to +40°C) and has IP20 protection. It carries UL 508, CSA, UR, and VDE certifications, plus cUR_E244330, ensuring compliance across North American and European installations and improving safety margins in industrial settings.
The CR-S012VDC1RG holds UL 508, CAN/CSA, UR, and VDE certifications, among others. These approvals validate safe electrical behavior, flame retardancy (UL 94‑V0), and adherence to international standards, reducing qualification time for global machinery and easing supplier qualification in multi-region deployments.
Its plug-in design and socket compatibility simplify field replacements, minimizing machine downtime. Gold-plated contacts improve long-term reliability and signal integrity, while the compact footprint enables quicker diagnostics and easier spare-part stocking. The combination supports continuous operation and easier servicing in high-mix, low-volume manufacturing environments.
