ABB 1SVR405510R3050 Pluggable Optocoupler - UR/CE Certified
Part Number: 1SVR405510R3050
Quick Summary
ABB 1SVR405510R3050 is a pluggable optocoupler for compact control panels and PCB mounting. Engineers often struggle with space constraints and the need for flexible, modular interfaces in modern automation. It carries CE declaration, UR/UL 508 certification, and IEC 61000-6-2/3 immunity standards to support regulatory compliance in challenging environments. With socket compatibility and a compact footprint, this device helps reduce panel depth and simplify maintenance, while its 24 V DC input and 48 V DC/100 mA output align with standard industrial control circuits in manufacturing and process industries.
Product Information
Extended Description
1SVR405510R3050 ABB: The CR-S024VDC1TRA slim pluggable optcoupler with Transistor output is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's CR-S sockets. This relay operates with a 24 V DC rated control supply voltage and has a maximum switching voltage of 48 V DC and maximum switching current of 100 mA. Coupled with a socket, the compact size of this relay offers possibilities to save space within a control panel. CR-S screw and spring sockets, separator, jumper bars and marker are available as accessories.
EAN
4013614486531
Minimum Order Quantity
10 piece
Customs Tariff Number
85369095
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Interface relays and optocouplers
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
15 mm
Product Net Height
5 mm
Product Net Depth / Length
28 mm
Product Net Weight
0.004 kg
Function
Pluggable slim optocoupler CR-S
Rated Control Supply Voltage (Us)
24 V DC
Output Signal
48VDC / 100mA
Degree of Protection
IP00
Standards
IEC/EN 61000-6-2 | IEC/EN 61000-6-3
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
1SVD981001-4400
RoHS Status
Following EU Directive 2011/65/EU
cUR Certificate
cUR_E244330
Declaration of Conformity - CE
EU Declaration of Conformity - CR-P, CR-S range optocouplers
UR Certificate
UR (ANSI/UL 508) Certificate - Pluggable interface relays / optocouplers CR-M, CR-MX, CR-P, CR-S, CR-U range
Package Level 1 Units
box 10 piece
Package Level 1 Width
23.7 mm
Package Level 1 Depth / Length
7.4 mm
Package Level 1 Height
300 mm
Package Level 1 Gross Weight
0.05 kg
Package Level 1 EAN
4013614509179
ETIM 7
EC001504 - Optocoupler
ETIM 8
EC001504 - Optocoupler
ETIM 9
EC001504 - Optocoupler
eClass
V11.0 : 27371604
UNSPSC
32111705
Feature: Slim pluggable design with a footprint of 15 mm width, 5 mm height and 28 mm depth reduces panel footprint. Benefit: frees cabinet space for wiring and labeling, enabling denser layouts. Application: ideal for compact control panels and PCB mounting in automation lines. Feature: 24 V DC control input and 48 V DC / 100 mA output. Benefit: straightforward interfacing with standard PLC logic and DC loads, lowering wiring complexity and heat in the panel. Application: direct use with typical 24 V control circuits in machines and conveyors. Feature: Direct PCB mounting or optional use with ABB CR-S sockets. Benefit: installation flexibility accelerates assembly and simplifies field replacements. Application: scalable from single-board prototypes to production hardware using CR-S sockets. Feature: IEC/EN 61000-6-2/6-3 compliance, CE and UR/UL 508 certifications. Benefit: robust EMI immunity and regulatory alignment across global sites. Application: suitable for harsh industrial environments, including manufacturing and process automation. Feature: RoHS and CMRT compliance with documented packaging and MOQ. Benefit: sustainable procurement and traceable supply chain. Application: compliant sourcing for international projects with strict environmental and sourcing requirements.
Get a Quick Quote for a ABB 1SVR405510R3050
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR405510R3050?
Enquire Now
FAQs
The device is designed for easy PCB mounting or direct insertion into ABB CR-S sockets. Its compact 15 mm width and 28 mm length fit typical CR-S socket housings, and accessories such as sockets, separators, and jumpers are available to streamline assembly and future maintenance.
It operates with a rated control supply of 24 V DC and provides an output of 48 V DC up to 100 mA. The unit supports direct switching within these limits and features IP00 protection, suitable for controlled environments when housed in an appropriate enclosure.
Yes, it meets IEC/EN 61000-6-2/3 immunity standards and carries CE DoC along with UR/UL 508 certification, making it appropriate for automation panels where EMI resilience and regulatory compliance are required.
The CR-S optocoupler carries CE declaration of conformity, UR and cUR certificates for UL 508, RoHS compliance, and CMRT documentation. These certifications support regulatory acceptance across global customers and procurement specifications.
Minimum order quantity is 10 pieces, with packaging configured as box sets of 10 pieces. The product ships under the EAN 4013614486531, and additional packaging data includes dimensions and carton details to assist with procurement planning.
