ABB 1SVR405610R4070 Interface Optocoupler - IP67
Part Number: 1SVR405610R4070
Quick Summary
ABB 1SVR405610R4070 Interface Optocoupler is a compact pluggable optocoupler with Triac output designed for PCB mounting or via ABB sockets in control panels. This arrangement helps address crowded enclosures and maintenance downtime by enabling quick replacement without rewiring. The device delivers robust protection and predictable performance in industrial environments, ensuring reliable control of AC loads from a 24 V DC logic signal. With IP67 ingress protection and compliance notes aligned to CE and UR standards, it supports safe operation across harsh conditions. For systems requiring space efficiency and straightforward installation, this optocoupler delivers both, while remaining compatible with ABB sockets and standard mounting practices.
Product Information
Extended Description
1SVR405610R4070 ABB: The CR-P024TRI1 pluggable optocoupler with Triac output is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. This relay operates with a 240 V AC rated control supply voltage and has a maximum switching voltage of 275 V AC and maximum switching current of 3,5 A. Coupled with a socket, the compact size of this relay offers possibilities to save space within a control panel. Furthermore, with an IP degree of 67, this relay offers complete protection against ingress of dust and airborne particles & protection against water and liquids, up to and including immersion in up to one meter of water. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
EAN
4013614509414
Minimum Order Quantity
10 piece
Customs Tariff Number
85369095
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Interface relays and optocouplers
Instructions and Manuals
Instructions - CR-M, CR-P, CR-U range
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
12.7 mm
Product Net Height
15.7 mm
Product Net Depth / Length
29 mm
Product Net Weight
0.011 kg
Function
Pluggable pcb optocoupler CR-P
Rated Control Supply Voltage (Us)
10 ... 32 V DC
Output
TRIAC
Output Signal
275VAC / 3A
Degree of Protection
IP67
Standards
IEC/EN 62314
Ambient Air Temperature
Operation -20 ... +50 °C | Storage -20 ... +70 °C
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
1SVD981001-4400
RoHS Status
Following EU Directive 2011/65/EU
cUR Certificate
cUR_E244330
Declaration of Conformity - CE
EU Declaration of Conformity - CR-P, CR-S range optocouplers
UR Certificate
UR (ANSI/UL 508) Certificate - Pluggable interface relays / optocouplers CR-M, CR-MX, CR-P, CR-S, CR-U range
Package Level 1 Units
box 10 piece
Package Level 1 Width
316.7 mm
Package Level 1 Depth / Length
15.3 mm
Package Level 1 Height
23.4 mm
Package Level 1 Gross Weight
0.13 kg
Package Level 1 EAN
4013614509377
ETIM 7
EC001504 - Optocoupler
ETIM 8
EC001504 - Optocoupler
ETIM 9
EC001504 - Optocoupler
eClass
V11.0 : 27371604
UNSPSC
32111705
Feature: Pluggable optic interface CR-P with Triac output → Business Impact: Reduces panel space usage and maintenance time by enabling rapid replacement without desoldering or rewiring → Application: Direct PCB mounting or use with ABB sockets in compact control panels. Feature: Input logic 24 V DC → Business Impact: Aligns with common industrial control voltages, reducing integration overhead and wiring errors → Application: 24 V control logic from PLCs and automation controllers in machine panels. Feature: Output rating 275 VAC / 3 A → Business Impact: Safe and reliable switching for common AC loads, improving system uptime and reducing component counts → Application: Driving relays, solid-state interfaces, or AC-powered actuators in machinery. Feature: Rated control supply voltage 10–32 V DC → Business Impact: Flexible compatibility with varied control-supply architectures, minimizing inventory needs → Application: Multi-vendor automation systems requiring a universal input range. Feature: IP67 protection → Business Impact: Protection against dust and water ingress, enabling use in field enclosures and wash-down environments → Application: Outdoor or harsh-environment panels, industrial cabinets, and equipment in wet or dusty plants. Feature: Compact dimensions (12.7 mm W × 15.7 mm H × 29 mm D) → Business Impact: Higher packing density in control panels, enabling more channels per enclosure → Application: 1U and compact panel rack installations where space is at a premium. Feature: RoHS compliance and international certifications → Business Impact: Lower compliance risk and easier global deployment across regulated markets → Application: Medical-grade or safety-conscious installations requiring traceable material compliance. Feature: UL/UR and CE declarations → Business Impact: Meets rigorous safety standards, simplifying procurement and customer acceptance → Application: Controls, safety relays, and motor control centers that demand certified components. Feature: Standard data resources and CAD drawings available → Business Impact: Accelerates engineering workflow and CAD integration, reducing design time → Application: System design and integration across engineering teams. Feature: 2D/3D CAD information and dimensional data → Business Impact: Accurate footprint and enclosure planning, minimizing fitment rework → Application: BOM creation and enclosure layout for new machines.
