ABB 1SVR405611R1100 Pluggable Interface Relay - IP40
Part Number: 1SVR405611R1100
Quick Summary
ABB 1SVR405611R1100 is a pluggable interface relay designed for compact control panels and machinery automation. It addresses installation complexity and space constraints by snapping into an ABB CR-M socket on a DIN rail, enabling seamless mounting in crowded enclosures. This solution carries CE, UL/CSA, and VDE certifications to support global deployments, along with RoHS compliance for responsible manufacturing. With a 24 V DC coil, integrated LED indicator, and an optical test button, it delivers clear energization feedback and easy commissioning. For integrators and maintenance teams, the relay offers reliable operation with standard sockets and accessories, delivering scalable, cost-efficient control in modern automation architectures.
Product Information
Extended Description
1SVR405611R1100 ABB: The CR-M024DC2L pluggable interface relay is a miniature relay, which is to be plugged into a suitable ABB CR-M socket. Plugged into a socket, the combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail.This relay operates with a 24 V DC rated control supply voltage and has a 2 c/o (SPDT) output with contacts rated at 250 V / 12 A, enabling the possibility of switching multiple circuits with a single input signal. The relay has an integrated test button which is used for the manual actuation of the relay by locking it's output contacts. The test button facilitates easy testing and commissioning. The relay also has an integrated LED, which provides the visual indication of the energization of the relay coil. Standard sockets, logic sockets, pluggable function modules, holders and markers are available as accessories. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
AETAD009EXPU
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
BRABB008EXPU
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
CHSEC006EXPU
Lead Time
160 day
Warranty Return
Product under warranty must be returned
Stocked At Warehouses
CZABB004EXPU
Country of Origin
Germany (DE)
Made To Order
No
Product Sales Status
Active
Quote Only
No
EAN
4013614497230
Minimum Order Quantity
10 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Interface relays and optocouplers
Instructions and Manuals
Instructions - CR-M, CR-P, CR-U range
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
21.2 mm
Product Net Height
35.6 mm
Product Net Depth / Length
27.5 mm
Product Net Weight
0.033 kg
Function
Pluggable miniature interface relay CR-M
Sub-Function
Relay with built in LED
Rated Control Supply Voltage (Us)
24 V DC
Rated Operational Voltage
250 V AC
Output
2 c/o (SPDT) contacts
Output Signal
250 V / 12 A
Terminal Type
Flat-Pin Connections
Rated Operational Current AC-12 (Ie)
(230 V) 12 A
Rated Operational Current AC-15 (Ie)
(120 V) 3 A | (230 V) 1.5 A
Rated Operational Current DC-12 (Ie)
(24 V) 12 A
Rated Operational Current DC-13 (Ie)
(24 V) 2.5 A | (250 V) 0.1 A
Rated Insulation Voltage (Ui)
250 V
Degree of Protection
IP40
Mounting Position
1
Standards
CAN/CSA C22.2 No.14 | IEC/EN 63000 | IEC/EN 61810-1 | UL 508
Maximum Operating Voltage UL/CSA
300 V AC
Pilot Duty UL/CSA
B300
Flammability According to UL94
HB
Ambient Air Temperature
Operation -40 ... +70 °C | Storage -40 ... +85 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
RoHS Status
Following EU Directive 2011/65/EU
CCC Certificate
CCC Certificate - Pluggable interface relays CR-M range
CQC Certificate
CQC Certificate, Interface Relays, CR-M, Made in Poland
CSA Certificate
CSA Certificate - Pluggable interface relays CR-M
cUR Certificate
cUR_E244330
Declaration of Conformity - CCC
CCC Declaration of Conformity, Interface Relays, CR-M, Made in Poland
Declaration of Conformity - CE
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
Declaration of Conformity - UKCA
UK Declaration of Conformity - CR-M, CR-U Pluggable interface-relays and accessories
EAC Certificate
EAC_RU_C-DE.ME77.B.00446-19
RMRS Certificate
RMRS Certificate - Pluggable interface relays CR range, except 60 V and 125 V versions
UR Certificate
UR (ANSI/UL 508) Certificate - Pluggable interface relays / optocouplers CR-M, CR-MX, CR-P, CR-S, CR-U range
VDE Certificate
VDE Certificate - Pluggable interface relays CR-M range, except 125 V versions
Package Level 1 Units
box 10 piece
Package Level 1 Width
114 mm
Package Level 1 Depth / Length
50 mm
Package Level 1 Height
61 mm
Package Level 1 Gross Weight
0.35 kg
Package Level 1 EAN
4013614373237
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
E-Number (Finland)
2712657
E-Number (Norway)
4187385
E-Number (Sweden)
4005333
Feature → Business Impact → Application: Pluggable CR-M design streamlines replacement and reduces wiring time, enabling faster maintenance cycles and lower downtime in control panels and machines. This directly improves overall equipment effectiveness (OEE) and reduces service costs. Application: Suitable for ABB CR-M socket ecosystems in factory automation where space is at a premium and quick swaps are essential. Feature → 24 V DC control coil with integrated LED and test button improves reliability and testability, enabling engineers to verify coil energization on-site without additional tooling. Business Impact: Accelerates commissioning, minimizes startup delays, and lowers commissioning labor costs. Application: Machine control and signaling applications where rapid verification is critical. Feature → 2 c/o (SPDT) contacts rated at 250 V AC / 12 A supports switching multiple circuits from a single input, reducing hardware count and wiring complexity. Business Impact: Higher circuit density, simplified wiring, and improved fault isolation. Application: Control relays for conveyor zones, interlocks, and signaling in automated lines. Feature → DIN rail snap-on mounting and socket compatibility with ABB CR-M accessories lowers installation risk and stock variety. Business Impact: Standardized mounting reduces install time and warehouse footprint. Application: Panel builders seeking scalable, plug-and-play relays in standardized automation cabinets. Feature → Environmental and compliance profile including IP40, -40 to +70 °C operation, RoHS, UL/CSA, CE, and VDE certifications. Business Impact: Ensures reliable operation in harsh environments and across global markets, reducing regulatory issues and warranty costs. Application: Industrial environments requiring robust performance and compliance across multiple regions.
Get a Quick Quote for a ABB 1SVR405611R1100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR405611R1100?
Enquire Now
FAQs
Yes. The 1SVR405611R1100 is a CR-M pluggable interface relay designed to plug into ABB CR-M sockets and snap onto a DIN rail, ensuring straightforward installation and secure retention. Ensure you select the correct socket variant compatible with your CR-M range and accessories.
The relay operates with a 24 V DC coil and provides 2 c/o SPDT contacts rated for 250 V AC at up to 12 A. It supports switching multiple circuits from a single input, with a robust load capability suitable for typical automation and signaling tasks.
Yes. It supports operation from -40 to +70 °C and carries an IP40 rating, making it suitable for indoor industrial environments. RoHS compliance further ensures materials meet modern eco-design requirements.
The relay features CE, UL/CSA (UR), and VDE certifications, along with UKCA and RoHS compliance. These certifications support compliance in European, North American, and selected international markets, reducing regulatory risk for global deployments.
Pluggable relays simplify replacement, testing, and commissioning, minimizing downtime. The built-in LED and test button aid rapid diagnostics, while compatibility with standard sockets and accessories reduces spare-part inventory and supports scalable, cost-efficient maintenance strategies.
