ABB 1SVR405613R7000 Pluggable Interface Relay - IP40
Part Number: 1SVR405613R7000
Quick Summary
ABB 1SVR405613R7000 pluggable interface relay delivers fast, reliable control for automation panels on DIN rails. Engineers often contend with downtime during relay replacement and compatibility gaps when upgrading modular control solutions. This device carries CE, UL/CSA, and UKCA certifications with RoHS compliance, plus IP40 protection for crowded industrial environments. With its compact form and plug-in design, it supports quick field swaps and scalable panel building, while continuing to align with existing sockets and markers. The result is a lower total cost of ownership and smoother commissioning for modern automation systems.
Product Information
Extended Description
1SVR405613R7000 ABB: The CR-M110AC4 pluggable interface relay is a miniature relay, which is to be plugged into a suitable ABB CR-M socket. Plugged into a socket, the combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail.This relay operates with a 110 V AC rated control supply voltage and has a 4 c/o (SPDT) output with contacts rated at 250 V / 6A, enabling the possibility of switching multiple circuits with a single input signal. The relay has an integrated test button which is used for the manual actuation of the relay by locking it's output contacts. The test button facilitates easy testing and commissioning. The relay also has an integrated LED, which provides the visual indication of the energization of the relay coil. Standard sockets, logic sockets, pluggable function modules, holders and markers are available as accessories. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
AETAD009EXPU
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
BRABB008EXPU
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
CHSEC006EXPU
Lead Time
35 day
Warranty Return
Product under warranty must be returned
Stocked At Warehouses
CZABB004EXPU
Country of Origin
Germany (DE)
Made To Order
No
Product Sales Status
Active
Quote Only
No
Lead Time
28 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USSVCEXPU
Warranty Return
Product under warranty must be returned
EAN
4013614497858
Minimum Order Quantity
10 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Interface relays and optocouplers
Instructions and Manuals
Instructions - CR-M, CR-P, CR-U range
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
21.2 mm
Product Net Height
35.6 mm
Product Net Depth / Length
27.5 mm
Product Net Weight
0.033 kg
Function
Pluggable miniature interface relay CR-M
Sub-Function
Relay w/o built in LED
Rated Control Supply Voltage (Us)
110 V AC
Rated Operational Voltage
250 V AC
Rated Frequency (f)
50 / 60 Hz
Output
4 c/o (SPDT) contacts
Output Signal
250 V / 6 A
Terminal Type
Flat-Pin Connections
Rated Operational Current AC-12 (Ie)
(230 V) 6 A
Rated Operational Current AC-15 (Ie)
(120 V) 1.5 A | (230 V) 1 A
Rated Operational Current DC-12 (Ie)
(24 V) 6 A
Rated Operational Current DC-13 (Ie)
(24 V) 2 A | (250 V) 0.1 A
Rated Insulation Voltage (Ui)
250 V
Degree of Protection
IP40
Mounting Position
1
Standards
CAN/CSA C22.2 No.14 | IEC/EN 63000 | IEC/EN 61810-1 | UL 508
Maximum Operating Voltage UL/CSA
300 V AC
Pilot Duty UL/CSA
B300
Flammability According to UL94
HB
Ambient Air Temperature
Operation -40 ... +55 °C | Storage -40 ... +85 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
RoHS Status
Following EU Directive 2011/65/EU
CCC Certificate
CCC Certificate - Pluggable interface relays CR-M range
CQC Certificate
CQC Certificate, Interface Relays, CR-M, Made in Poland
CSA Certificate
CSA Certificate - Pluggable interface relays CR-M
cUR Certificate
cUR_E244330
Declaration of Conformity - CCC
CCC Declaration of Conformity, Interface Relays, CR-M, Made in Poland
Declaration of Conformity - CE
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
Declaration of Conformity - UKCA
UK Declaration of Conformity - CR-M, CR-U Pluggable interface-relays and accessories
EAC Certificate
EAC_RU_C-DE.ME77.B.00446-19
LR Certificate
LR Certificate - Pluggable interface relays CR-M and CR-U range
RMRS Certificate
RMRS Certificate - Pluggable interface relays CR range, except 60 V and 125 V versions
UR Certificate
UR (ANSI/UL 508) Certificate - Pluggable interface relays / optocouplers CR-M, CR-MX, CR-P, CR-S, CR-U range
VDE Certificate
VDE Certificate - Pluggable interface relays CR-M range, except 125 V versions
Package Level 1 Units
box 10 piece
Package Level 1 Width
114 mm
Package Level 1 Depth / Length
50 mm
Package Level 1 Height
61 mm
Package Level 1 Gross Weight
0.35 kg
Package Level 1 EAN
4013614373534
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
E-Number (Finland)
2712681
E-Number (Norway)
4187381
Plug-in compatibility with ABB CR-M sockets enables rapid maintenance, reducing downtime and wiring disturbances in modular control cabinets. This fosters faster line changeovers and simpler spare-part strategy, particularly in scalable automation architectures. The 110 V AC control supply aligns with standard plant power, simplifying wiring diagrams and reducing the need for additional power conversion. The 4 c/o SPDT outputs (250 V, 6 A) allow a single input to govern multiple loads, improving I/O efficiency and enabling compact signal distribution within machine controls. Integrated test button and LED indicator accelerate commissioning, troubleshooting, and live diagnostics, cutting startup time and preventing mis-wiring during setup. DIN-rail snap-on mounting and flat-pin connections deliver a low-profile footprint, easing installation in crowded panels while ensuring reliable, vibration-resistant connections in harsh environments. IP40 protection with a wide operating temperature range ensures robust performance in typical factory floors, control panels, and automation racks while remaining compatible with ABB sockets and accessories, providing consistent performance and predictable maintenance planning.
Get a Quick Quote for a ABB 1SVR405613R7000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR405613R7000?
Enquire Now
FAQs
The 1SVR405613R7000 is designed for plug-in installation into ABB CR-M sockets, then snap-on mounted onto a standard DIN rail. Align the flat-pin terminals with the socket, press firmly to engage, and use the integrated test button during commissioning to verify the relay actuates correctly. This minimizes wiring disruption and streamlines panel upgrades.
The relay is controlled by a 110 V AC supply and provides 4 c/o SPDT contacts with a rated output of 250 V at up to 6 A. It supports both AC-12 (230 V, 6 A) and DC-12 (24 V, 6 A) operating currents, with AC-15 and other ratings documented for safe, versatile switching in control circuits.
Ideal for automation panels, machine control, and signal distribution, this relay supports compact, modular designs on DIN rails. Its pluggable architecture enables scalable expansions, quick replacements, and straightforward maintenance in control cabinets, distributors, and process automation racks, especially where space is constrained or frequent field servicing is expected.
The 1SVR405613R7000 carries CE, UL/CSA (UR) certifications, and UKCA labeling, along with RoHS compliance. It adheres to standards including UL 508, IEC/EN 61810-1, and CAN/CSA, ensuring safe integration into global control systems and compliance with regional regulatory requirements.
Pluggable design shortens downtime during maintenance by allowing field replacement without rewiring. The built-in test button, LED indicator, and compatibility with standard ABB sockets streamline commissioning and troubleshooting, reducing labor costs and accelerating time-to-value in production lines and retrofit projects.
