ABB CR-M110AC4L Pluggable Interface Relay - IP40
Part Number: 1SVR405613R7100
Quick Summary
ABB CR-M110AC4L pluggable interface relay provides compact control for field I/O in machine automation. Engineers often wrestle with bulky, hard-to-reach relays and complex wiring, which drives commissioning time and increases downtime. It carries CE and UKCA conformity, UL/CSA certification, and RoHS compliance, supporting global deployments and regulator-ready panels. Designed for DIN rail snap-on mounting and easy plug-in replacement, it enables higher panel density, faster maintenance, and scalable automation projects. The integrated LED and test button further simplify testing during start-up and routine diagnostics, reducing risk and accelerating validation. Coupled with standard sockets, logic sockets, and accessories, it offers flexible configuration for diverse control schemes.
Product Information
Extended Description
1SVR405613R7100 ABB: The CR-M110AC4L pluggable interface relay is a miniature relay, which is to be plugged into a suitable ABB CR-M socket. Plugged into a socket, the combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail.This relay operates with a 110 V AC rated control supply voltage and has a 4 c/o (SPDT) output with contacts rated at 250 V / 6A, enabling the possibility of switching multiple circuits with a single input signal. The relay has an integrated test button which is used for the manual actuation of the relay by locking it's output contacts. The test button facilitates easy testing and commissioning. The relay also has an integrated LED, which provides the visual indication of the energization of the relay coil. Standard sockets, logic sockets, pluggable function modules, holders and markers are available as accessories. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
EAN
4013614497865
Minimum Order Quantity
10 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Interface relays and optocouplers
Instructions and Manuals
Instructions - CR-M, CR-P, CR-U range
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
21.2 mm
Product Net Height
35.6 mm
Product Net Depth / Length
27.5 mm
Product Net Weight
0.033 kg
Function
Pluggable miniature interface relay CR-M
Sub-Function
Relay with built in LED
Rated Control Supply Voltage (Us)
110 V AC
Rated Operational Voltage
250 V AC
Rated Frequency (f)
50 / 60 Hz
Output
4 c/o (SPDT) contacts
Output Signal
250 V / 6 A
Terminal Type
Flat-Pin Connections
Rated Operational Current AC-12 (Ie)
(230 V) 6 A
Rated Operational Current AC-15 (Ie)
(120 V) 1.5 A | (230 V) 1 A
Rated Operational Current DC-12 (Ie)
(24 V) 6 A
Rated Operational Current DC-13 (Ie)
(24 V) 2 A | (250 V) 0.1 A
Rated Insulation Voltage (Ui)
250 V
Degree of Protection
IP40
Mounting Position
1
Standards
CAN/CSA C22.2 No.14 | IEC/EN 63000 | IEC/EN 61810-1 | UL 508
Maximum Operating Voltage UL/CSA
300 V AC
Pilot Duty UL/CSA
B300
Flammability According to UL94
HB
Ambient Air Temperature
Operation -40 ... +55 °C | Storage -40 ... +85 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
RoHS Status
Following EU Directive 2011/65/EU
CCC Certificate
CCC Certificate - Pluggable interface relays CR-M range
CQC Certificate
CQC Certificate, Interface Relays, CR-M, Made in Poland
CSA Certificate
CSA Certificate - Pluggable interface relays CR-M
cUR Certificate
cUR_E244330
Declaration of Conformity - CCC
CCC Declaration of Conformity, Interface Relays, CR-M, Made in Poland
Declaration of Conformity - CE
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
Declaration of Conformity - UKCA
UK Declaration of Conformity - CR-M, CR-U Pluggable interface-relays and accessories
EAC Certificate
EAC_RU_C-DE.ME77.B.00446-19
LR Certificate
LR Certificate - Pluggable interface relays CR-M and CR-U range
RMRS Certificate
RMRS Certificate - Pluggable interface relays CR range, except 60 V and 125 V versions
UR Certificate
UR (ANSI/UL 508) Certificate - Pluggable interface relays / optocouplers CR-M, CR-MX, CR-P, CR-S, CR-U range
VDE Certificate
VDE Certificate - Pluggable interface relays CR-M range, except 125 V versions
Package Level 1 Units
box 10 piece
Package Level 1 Width
114 mm
Package Level 1 Depth / Length
50 mm
Package Level 1 Height
61 mm
Package Level 1 Gross Weight
0.35 kg
Package Level 1 EAN
4013614373626
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
E-Number (Finland)
2712682
E-Number (Norway)
4187414
Feature: 110 V AC control supply and 250 V AC output with 4 c/o SPDT contacts. Benefit: Enables reliable multi-circuit switching from a single input, reducing device count and wiring complexity in control panels. Application: Machine control sites needing compact, versatile relays. Feature: Integrated test button and LED indicator. Benefit: Streamlines commissioning and ongoing diagnostics by providing immediate visual feedback and a manual actuation option. Application: Start-up verification and fault isolation in panel assemblies. Feature: Pluggable into ABB CR-M sockets with DIN rail snap-on mounting. Benefit: Quick serviceability, easy replacement, and reduced downtime during maintenance or upgrades. Application: Modular control panels and scalable automation infrastructures. Feature: Robust environmental and electrical ratings: IP40, -40 to +55 °C, up to 2,000 m altitude. Benefit: Reliable operation in harsh industrial environments with minimal derating. Application: Factory floors, conveyors, and outdoor-constrained enclosures. Feature: Broad standards and compliance footprint: CE, UKCA, UL/CSA, RoHS. Benefit: Regulator-ready, globally deployable solution that simplifies certification and reduces risk. Application: Global machine builders and integrators seeking compliant components.
Get a Quick Quote for a ABB 1SVR405613R7100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR405613R7100?
Enquire Now
FAQs
Yes. The CR-M110AC4L is a pluggable miniature interface relay designed to plug into compatible ABB CR-M sockets and snap onto a standard DIN rail. This modular approach simplifies installation, reduces wiring, and allows rapid field replacements without rewiring entire control circuits. Ensure the socket and rail are clean and free from debris before mating parts.
The unit provides 110 V AC rated control voltage with 250 V AC rated operating voltage and 4 c/o SPDT contacts. Output current is up to 6 A at 250 V, with AC-12 ratings of 6 A at 230 V, and AC-15 ratings of 1 A at 230 V. The device uses flat-pin terminals and is rated for IP40 protection, suitable for many panel-level switching tasks.
This relay is ideal for machine control panels, signaling circuits, and I/O interface tasks in DIN rail installations. Its compact form and pluggable design support scalable automation projects, where multiple signal lines must be switched from a single input. It is particularly advantageous for panel builders seeking modular, serviceable relay solutions with clear status indication via the built-in LED.
The CR-M110AC4L carries CE and UKCA declarations, UL/CSA certification, and RoHS compliance, ensuring regulatory alignment for European and North American markets. It supports CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61810-1, and UL 508, providing confidence for safety, environmental, and electrical integration in control panels.
The integrated test button offers quick manual actuation for commissioning and troubleshooting, while the LED provides immediate operational status, reducing commissioning time and maintenance hunts. The modular, plug-in design minimizes downtime during swaps or upgrades, lowering total cost of ownership and improving panel uptime in high-availability automation environments.
