ABB 1SVR405621R3000 Interface Relay - IP40, 230 V AC
Part Number: 1SVR405621R3000
Quick Summary
CR-U Pluggable Interface Relay provides universal switching for DIN-rail automation panels. This model reduces wiring complexity and speeds commissioning by plugging into CR-U sockets, snapping onto a DIN rail, and offering plug-in convenience for service. Key certifications ensure safety and reliability in critical environments, including CE conformity, UL 508, UR, and VDE certifications, with IP40 protection. Coupled with 230 V AC rated control and 2 c/o SPDT contacts, it supports flexible switching for control circuits, sensors, and alarms.
Product Information
Extended Description
1SVR405621R3000 ABB: The CR-U230AC2 pluggable interface relay is a univeral relay and is also commonly referred to as an ice cube relay. CR-U relays may be plugged into CR-U sockets and this combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail. CR-U relays have robust circular pin terminals, designed and manufactured to handle tough, repetitive-use applications and are more durable than standard relays.This relay operates with a 230 V AC rated control supply voltage and has a 2 c/o (SPDT) output with contacts rated at 250 V / 10 A, enabling the possibility of switching multiple circuits with a single input signal. The relay has an integrated test button which is used for the manual actuation of the relay by locking it's output contacts. The test button facilitates easy testing and commissioning. The relay also has an integrated LED, which provides the visual indication of the energization of the relay coil. Standard sockets, logic sockets, pluggable function modules, holders and markers are available as accessories. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
AETAD009EXPU
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
BRABB008EXPU
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
CHSEC006EXPU
Lead Time
160 day
Warranty Return
Product under warranty must be returned
Stocked At Warehouses
CZABB004EXPU
Country of Origin
Germany (DE)
Made To Order
No
Product Sales Status
Active
Quote Only
No
EAN
4013614498411
Minimum Order Quantity
10 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Interface relays and optocouplers
Instructions and Manuals
Instructions - CR-M, CR-P, CR-U range
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
35 mm
Product Net Height
54.4 mm
Product Net Depth / Length
35 mm
Product Net Weight
0.083 kg
Function
Pluggable universal interface relay CR-U
Sub-Function
Relay w/o built in LED
Rated Control Supply Voltage (Us)
230 V AC
Rated Operational Voltage
250 V AC
Rated Frequency (f)
50 / 60 Hz
Output
2 c/o (SPDT) contacts
Output Signal
250 V / 10 A
Terminal Type
Pin
Rated Operational Current AC-12 (Ie)
(230 V) 10 A
Rated Operational Current AC-15 (Ie)
(120 V) 3 A | (230 V) 1.5 A
Rated Operational Current DC-12 (Ie)
(24 V) 10 A
Rated Operational Current DC-13 (Ie)
(24 V) 2 A | (250 V) 0.1 A
Rated Insulation Voltage (Ui)
250 V
Degree of Protection
IP40
Mounting Position
1
Standards
CAN/CSA C22.2 No.14 | IEC/EN 63000 | IEC/EN 61810-1 | UL 508
Maximum Operating Voltage UL/CSA
300 V AC
Pilot Duty UL/CSA
B300
Flammability According to UL94
HB
Ambient Air Temperature
Operation -40 ... +55 °C | Storage -40 ... +85 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
RoHS Status
Following EU Directive 2011/65/EU
CCC Certificate
CCC Certificate - Pluggable interface relays CR-U range
CQC Certificate
CQC Certificate, Interface Relays, CR-U, Made in Poland
CSA Certificate
CSA Certificate - Pluggable interface relays CR-P and CR-U
Declaration of Conformity - CCC
CCC Declaration of Conformity, Interface Relays, CR-U, Made in Poland
Declaration of Conformity - CE
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
Declaration of Conformity - UKCA
UK Declaration of Conformity - CR-M, CR-U Pluggable interface-relays and accessories
EAC Certificate
EAC_RU_C-DE.ME77.B.00446-19
LR Certificate
LR Certificate - Pluggable interface relays CR-M and CR-U range
RMRS Certificate
RMRS Certificate - Pluggable interface relays CR range, except 60 V and 125 V versions
UR Certificate
UR (ANSI/UL 508) Certificate - Pluggable interface relays / optocouplers CR-M, CR-MX, CR-P, CR-S, CR-U range
VDE Certificate
VDE Certificate - Pluggable interface relays CR-U range
Package Level 1 Units
box 10 piece
Package Level 1 Width
182 mm
Package Level 1 Depth / Length
77 mm
Package Level 1 Height
76 mm
Package Level 1 Gross Weight
0.87 kg
Package Level 1 EAN
4013614374074
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
E-Number (Finland)
2712795
E-Number (Norway)
4187463
E-Number (Sweden)
4005415
Pluggable CR-U concept keeps maintenance minimal and downtime predictable by letting the relay slide into CR-U sockets and snap onto a DIN rail, forming a compact ice cube relay package. The design supports modular expansion without rewiring, enabling quick swaps in busy cabinets. With 230 V AC control and two SPDT (c/o) contacts rated up to 250 V / 10 A, the unit can switch multiple circuits from a single input, reducing panel complexity. This capability supports machine control, protection schemes, and signaling in modern automation architectures. An integrated test button plus a coil-energized LED indicator accelerate commissioning and troubleshooting, letting technicians verify actuation without external instrumentation. This reduces debugging time and supports reliable start-up in regulated environments. Robust circular pin terminals and a durable housing are designed for high-cycle operation and vibration commonly found in industrial plants. The IP40 rating with operation from -40 to +55 °C and up to 2000 m altitude ensures dependable performance across a wide range of facilities. ABB provides a broad accessory ecosystem—standard sockets, logic sockets, pluggable function modules, holders and markers—so you can tailor the relay to your control scheme. Standardization reduces spare parts and simplifies procurement across projects. Compliance with major standards such as CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61810-1, UL 508, CE, UL/CSA, UR, UKCA, VDE and RoHS ensures global applicability and risk mitigation. This supports procurement in regulated industries and multinational deployments.
Get a Quick Quote for a ABB 1SVR405621R3000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR405621R3000?
Enquire Now
FAQs
Install by snapping the CR-U relay into compatible CR-U sockets and mounting onto a standard DIN rail. Use standard sockets, logic sockets, pluggable function modules, holders and markers to tailor the relay to your control scheme. The assembly supports quick replacement and minimizes wiring changes during commissioning or maintenance.
The unit uses 230 V AC control voltage and provides 2 c/o SPDT contacts with a rated signal of up to 250 V / 10 A. Rated operational current AC-12 at 230 V is 10 A, with other values for AC-15 and DC ratings listed in the datasheet. Terminal type is pin for secure, vibration-resistant connections.
Yes, it is designed for industrial use with UL 508 listed performance, UR and UL/CSA certifications, and CE/UKCA conformity. The pilot duty rating (UL/CSA B300) and IP40 enclosure support safe operation in many control scenarios, while the test button and LED aid verification during commissioning.
Key certifications include CE conformity, UL 508, UL/CSA, UR, UKCA, VDE, CCC, CQC, and RoHS compliance. The device also carries EU and UK conformity declarations, and it originates from Germany, which supports global procurement and regulatory alignment for multinational deployments.
Benefits include reduced downtime due to easy plug-in replacements, simplified spare parts management with standard sockets and modules, and faster commissioning with an integrated test button and LED. The modular design supports scalable control architectures and lifecycle efficiency, delivering measurable improvements in maintenance overhead and project timelines.
