ABB 1SVR405621R3100 Pluggable interface relay - UL/CSA, CE
Part Number: 1SVR405621R3100
Quick Summary
ABB 1SVR405621R3100 is a pluggable interface relay designed for compact DIN-rail control in industrial automation. It helps engineers avoid bulky modules and difficult-to-test assemblies by pairing with CR-U sockets for fast, modular replacements. This family carries UL/CSA and CE marks, with UKCA and VDE accreditation in applicable variants, ensuring regulatory compliance and safe operation across diverse manufacturing environments. The design delivers easy diagnostics via an integrated LED and a built-in test button, while standard sockets, logic sockets, and accessories simplify wiring and installation in control panels. By combining reliable performance with straightforward maintenance, it supports higher line uptime and lower total cost of ownership for automation projects.
Product Information
Extended Description
1SVR405621R3100 ABB: The CR-U230AC2L pluggable interface relay is a univeral relay and is also commonly referred to as an ice cube relay. CR-U relays may be plugged into CR-U sockets and this combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail. CR-U relays have robust circular pin terminals, designed and manufactured to handle tough, repetitive-use applications and are more durable than standard relays.This relay operates with a 230 V AC rated control supply voltage and has a 2 c/o (SPDT) output with contacts rated at 250 V / 10 A, enabling the possibility of switching multiple circuits with a single input signal. The relay has an integrated test button which is used for the manual actuation of the relay by locking it's output contacts. The test button facilitates easy testing and commissioning. The relay also has an integrated LED, which provides the visual indication of the energization of the relay coil. Standard sockets, logic sockets, pluggable function modules, holders and markers are available as accessories.
EAN
4013614498428
Minimum Order Quantity
10 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Interface relays and optocouplers
Instructions and Manuals
Instructions - CR-M, CR-P, CR-U range
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
35 mm
Product Net Height
54.4 mm
Product Net Depth / Length
35 mm
Product Net Weight
0.083 kg
Function
Pluggable universal interface relay CR-U
Sub-Function
Relay with built in LED
Rated Control Supply Voltage (Us)
230 V AC
Rated Operational Voltage
250 V AC
Rated Frequency (f)
50 / 60 Hz
Output
2 c/o (SPDT) contacts
Output Signal
250 V / 10 A
Terminal Type
Pin
Rated Operational Current AC-12 (Ie)
(230 V) 10 A
Rated Operational Current AC-15 (Ie)
(120 V) 3 A | (230 V) 1.5 A
Rated Operational Current DC-12 (Ie)
(24 V) 10 A
Rated Operational Current DC-13 (Ie)
(24 V) 2 A | (250 V) 0.1 A
Rated Insulation Voltage (Ui)
250 V
Degree of Protection
IP40
Mounting Position
1
Standards
CAN/CSA C22.2 No.14 | IEC/EN 63000 | IEC/EN 61810-1 | UL 508
Maximum Operating Voltage UL/CSA
300 V AC
Pilot Duty UL/CSA
B300
Flammability According to UL94
HB
Ambient Air Temperature
Operation -40 ... +55 °C | Storage -40 ... +85 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
RoHS Status
Following EU Directive 2011/65/EU
CCC Certificate
CCC Certificate - Pluggable interface relays CR-U range
CQC Certificate
CQC Certificate, Interface Relays, CR-U, Made in Poland
CSA Certificate
CSA Certificate - Pluggable interface relays CR-P and CR-U
Declaration of Conformity - CCC
CCC Declaration of Conformity, Interface Relays, CR-U, Made in Poland
Declaration of Conformity - CE
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
Declaration of Conformity - UKCA
UK Declaration of Conformity - CR-M, CR-U Pluggable interface-relays and accessories
EAC Certificate
EAC_RU_C-DE.ME77.B.00446-19
LR Certificate
LR Certificate - Pluggable interface relays CR-M and CR-U range
RMRS Certificate
RMRS Certificate - Pluggable interface relays CR range, except 60 V and 125 V versions
UR Certificate
UR (ANSI/UL 508) Certificate - Pluggable interface relays / optocouplers CR-M, CR-MX, CR-P, CR-S, CR-U range
VDE Certificate
VDE Certificate - Pluggable interface relays CR-U range
Package Level 1 Units
box 10 piece
Package Level 1 Width
182 mm
Package Level 1 Depth / Length
77 mm
Package Level 1 Height
76 mm
Package Level 1 Gross Weight
0.87 kg
Package Level 1 EAN
4013614374166
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
E-Number (Finland)
2712796
E-Number (Norway)
4187483
E-Number (Sweden)
4005416
Feature: Pluggable CR-U system with socket compatibility → Business Impact: Fast maintenance, reduced downtime, and easy field replacements → Application: DIN rail mounted control panels with CR-U modules. The ability to snap a relay into a CR-U socket saves commissioning time and minimizes panel disruption. Feature: 230 V AC control supply → Business Impact: Uses a common control voltage, simplifying power distribution and reducing part variety → Application: PLC-based or switchgear control networks where 230 V AC is standard. Feature: 2 c/o SPDT outputs (250 V / 10 A) → Business Impact: Flexible load switching for two circuits from a single input → Application: Interlocking, signaling, and multi-circuit control in automation panels. Feature: Integrated test button and LED indicator → Business Impact: Immediate on-site verification and faster fault isolation → Application: Commissioning, diagnostics, and status monitoring without separate test equipment. Feature: IP40 protection and wide operating temperature ( -40 to +55 °C ) → Business Impact: Reliable performance in harsh factory environments and broad deployment viability → Application: Industrial automation in production floors and assembly lines. Feature: Compact DIN-rail footprint (dimensions and weight) → Business Impact: Space-saving panel design and scalable installations → Application: Dense control panels and modular machine builders. Certification & compliance: UL/CSA, CE, UKCA, and VDE marks across the CR-U range → Business Impact: Regulatory clearance and easier global procurement → Application: Global manufacturing and multi-site deployment.
Get a Quick Quote for a ABB 1SVR405621R3100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR405621R3100?
Enquire Now
FAQs
Install by snapping the CR-U plug-in relay into a matching CR-U socket mounted on a DIN rail. The relay features robust circular pin terminals and a front-facing LED for status indication. Ensure 230 V AC control supply is present and that the output contacts are connected to the intended loads. The integrated test button facilitates commissioning without extra test gear.
The unit operates on a 230 V AC control supply and provides 2 c/o SPDT contacts with an output rating of 250 V / 10 A. Rated operational currents are specified for AC-12 and AC-15 across voltage levels, making it suitable for switching multiple circuits from a single input signal in automation panels.
Yes. It supports operation from -40 to +55 °C and is rated IP40, allowing usage in typical industrial environments. It is designed for DIN-rail mounting with a compact footprint, enabling reliable performance without derating up to 2000 m altitude. Always confirm your specific load types and durations align with the ratings.
The CR-U relays include UL/CSA certification, CE marking, and UKCA where applicable, with additional VDE and UR marks supporting broader regulatory compliance. These certifications help meet global electrical safety and performance requirements, simplifying procurement for multi-region deployments.
The built-in test button allows manual actuation and commissioning without external tools, while the LED provides immediate energization feedback. Together, they reduce commissioning time, speed fault isolation, and lower maintenance costs by improving diagnostic accuracy and minimizing panel downtime.
