ABB 1SVR405621R6000 Pluggable interface relay - IP40
Part Number: 1SVR405621R6000
Quick Summary
ABB CR-U048DC2 pluggable interface relay enables compact control of multiple circuits in DIN-rail panels. Engineers often struggle with space constraints, wiring complexity, and challenging commissioning. Certified to IP40 protection with UL/CSA listings and CE/UKCA declarations, this relay combines rugged design with regulatory readiness. For vendors and integrators, the modular, plug-in approach reduces downtime and simplifies spare-part handling, while maintaining strong performance in electrical protection and circuit control applications.
Product Information
Extended Description
1SVR405621R6000 ABB: The CR-U048DC2 pluggable interface relay is a univeral relay and is also commonly referred to as an ice cube relay. CR-U relays may be plugged into CR-U sockets and this combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail. CR-U relays have robust circular pin terminals, designed and manufactured to handle tough, repetitive-use applications and are more durable than standard relays.This relay operates with a 48 V DC rated control supply voltage and has a 2 c/o (SPDT) output with contacts rated at 250 V / 10 A, enabling the possibility of switching multiple circuits with a single input signal. The relay has an integrated test button which is used for the manual actuation of the relay by locking it's output contacts. The test button facilitates easy testing and commissioning. The relay also has an integrated LED, which provides the visual indication of the energization of the relay coil. Standard sockets, logic sockets, pluggable function modules, holders and markers are available as accessories. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
EAN
4013614498473
Minimum Order Quantity
10 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Interface relays and optocouplers
Instructions and Manuals
Instructions - CR-M, CR-P, CR-U range
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
35 mm
Product Net Height
54.4 mm
Product Net Depth / Length
35 mm
Product Net Weight
0.083 kg
Function
Pluggable universal interface relay CR-U
Sub-Function
Relay w/o built in LED
Rated Control Supply Voltage (Us)
48 V DC
Rated Operational Voltage
250 V AC
Output
2 c/o (SPDT) contacts
Output Signal
250 V / 10 A
Terminal Type
Pin
Rated Operational Current AC-12 (Ie)
(230 V) 10 A
Rated Operational Current AC-15 (Ie)
(120 V) 3 A | (230 V) 1.5 A
Rated Operational Current DC-12 (Ie)
(24 V) 10 A
Rated Operational Current DC-13 (Ie)
(24 V) 2 A | (250 V) 0.1 A
Rated Insulation Voltage (Ui)
250 V
Degree of Protection
IP40
Mounting Position
1
Standards
CAN/CSA C22.2 No.14 | IEC/EN 63000 | IEC/EN 61810-1 | UL 508
Maximum Operating Voltage UL/CSA
300 V AC
Pilot Duty UL/CSA
B300
Flammability According to UL94
HB
Ambient Air Temperature
Operation -40 ... +70 °C | Storage -40 ... +85 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
RoHS Status
Following EU Directive 2011/65/EU
CCC Certificate
CCC Certificate - Pluggable interface relays CR-U range
CQC Certificate
CQC Certificate, Interface Relays, CR-U, Made in Poland
CSA Certificate
CSA Certificate - Pluggable interface relays CR-P and CR-U
Declaration of Conformity - CCC
CCC Declaration of Conformity, Interface Relays, CR-U, Made in Poland
Declaration of Conformity - CE
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
Declaration of Conformity - UKCA
UK Declaration of Conformity - CR-M, CR-U Pluggable interface-relays and accessories
EAC Certificate
EAC_RU_C-DE.ME77.B.00446-19
LR Certificate
LR Certificate - Pluggable interface relays CR-M and CR-U range
RMRS Certificate
RMRS Certificate - Pluggable interface relays CR range, except 60 V and 125 V versions
UR Certificate
UR (ANSI/UL 508) Certificate - Pluggable interface relays / optocouplers CR-M, CR-MX, CR-P, CR-S, CR-U range
VDE Certificate
VDE Certificate - Pluggable interface relays CR-U range
Package Level 1 Units
box 10 piece
Package Level 1 Width
182 mm
Package Level 1 Depth / Length
77 mm
Package Level 1 Height
76 mm
Package Level 1 Gross Weight
0.87 kg
Package Level 1 EAN
4013614374036
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
E-Number (Finland)
2712775
E-Number (Norway)
4187456
Feature → Business Impact → Application: The CR-U pluggable interface relay integrates into CR-U sockets, enabling quick replacements and modular upgrades; this minimizes downtime and simplifies maintenance in control panels. Application: DIN-rail mounted, with plug-in convenience ideal for panel builders and machine builders seeking scalable I/O. Feature → Business Impact → Application: 48 V DC rated control supply (A1–A2) powers reliable coil operation; combined with 250 V AC, 10 A SPDT outputs, it supports multi-circuit switching with a single input; Application: centralized control in automation cells. Feature → Business Impact → Application: Integrated test button and LED provide straightforward testing and status indication, shortening commissioning time and improving fault diagnosis in practice. Feature → Business Impact → Application: Robust circular pin terminals and IP40 protection deliver durable, secure wiring in harsh environments, reducing signal integrity issues in automotive and industrial machinery. Feature → Business Impact → Application: Broad standards and certifications (UL/CSA, CE, UKCA, RoHS, EAC, VDE) assure compliance across global projects, lowering procurement risk and accelerating approvals for industrial control systems. Feature → Business Impact → Application: ACCESSORY ecosystem including standard sockets, logic sockets, pluggable modules, holders, and markers supports scalable solutions without reengineering control panels.
Get a Quick Quote for a ABB 1SVR405621R6000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR405621R6000?
Enquire Now
FAQs
Installing the CR-U048DC2 is straightforward: it plugs into a compatible CR-U socket and mounts on a standard DIN rail for snap-on installation. Ensure the coil is powered at 48 V DC (A1-A2) and connect the two SPDT outputs to the load. The device features robust circular pin terminals for secure wiring.
Electrical ratings include a 48 V DC control supply, 250 V AC maximum operating voltage, and 10 A output per SPDT contact. The DC-12 rating shows 24 V loads up to 10 A, while DC-13 limits are 2 A at 24 V or 0.1 A at 250 V. The relay supports IP40 protection and UL/CSA and CE compliance.
Commonly used in machine control and automated panels, the CR-U048DC2 enables safe, modular switching of multiple circuits from a single control input. Its plug-in architecture simplifies field upgrades and spare-part replacement, minimizing downtime. For testing and commissioning, the integrated test button and LED indicator speed validation and provide immediate feedback during startup.
Certification coverage includes UL 508, CAN/CSA C22.2 No. 14, CE, UKCA, RoHS compliance, CCC, CQC, EAC, UR, and VDE recognition. This broad compliance supports safe procurement for global automation projects, ensures traceability of components, and reduces supplier risk when specifying relays for safety and control circuits in industrial environments. Compatibility with international standards helps verify conformity across regions.
From a maintenance and ROI perspective, the CR-U series reduces downtime with modular, plug-in design and an integrated test button. Availability of compatible sockets and markers simplifies expansion and spare parts stocking. In practice, simple field replacement lowers service costs, while clear status indication supports faster fault isolation and reduced mean time to repair.
