ABB 1SVR405621R9000 Pluggable interface relay - IP40
Part Number: 1SVR405621R9000
Quick Summary
CR-U pluggable interface relay provides a versatile control interface for industrial automation wiring and modular systems. Engineers often face downtime when relays fail or wiring must be reconfigured, making quick replacement and testing essential; this module offers plug-in replacement and straightforward commissioning to minimize disruption. With CE and UKCA conformity, UL/CSA approvals, and RoHS compliance, plus IP40 protection for safe DIN-rail mounting, it supports regulatory and safety requirements in diverse environments. By leveraging a DIN-rail compatible, plug-in design and SPDT output rated up to 250 V AC / 10 A, you gain reliable control, reduced wiring complexity, and lower installation costs for panel builders and OEMs.
Product Information
Extended Description
1SVR405621R9000 ABB: The CR-U220DC2 pluggable interface relay is a univeral relay and is also commonly referred to as an ice cube relay. CR-U relays may be plugged into CR-U sockets and this combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail. CR-U relays have robust circular pin terminals, designed and manufactured to handle tough, repetitive-use applications and are more durable than standard relays.This relay operates with a 220 V DC rated control supply voltage and has a 2 c/o (SPDT) output with contacts rated at 250 V / 10 A, enabling the possibility of switching multiple circuits with a single input signal. The relay has an integrated test button which is used for the manual actuation of the relay by locking it's output contacts. The test button facilitates easy testing and commissioning. The relay also has an integrated LED, which provides the visual indication of the energization of the relay coil. Standard sockets, logic sockets, pluggable function modules, holders and markers are available as accessories.
EAN
4013614498534
Minimum Order Quantity
10 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Interface relays and optocouplers
Instructions and Manuals
Instructions - CR-M, CR-P, CR-U range
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
35 mm
Product Net Height
54.4 mm
Product Net Depth / Length
35 mm
Product Net Weight
0.083 kg
Function
Pluggable universal interface relay CR-U
Sub-Function
Relay w/o built in LED
Rated Control Supply Voltage (Us)
220 V DC
Rated Operational Voltage
250 V AC
Output
2 c/o (SPDT) contacts
Output Signal
250 V / 10 A
Terminal Type
Pin
Rated Operational Current AC-12 (Ie)
(230 V) 10 A
Rated Operational Current AC-15 (Ie)
(120 V) 3 A | (230 V) 1.5 A
Rated Operational Current DC-12 (Ie)
(24 V) 10 A
Rated Operational Current DC-13 (Ie)
(24 V) 2 A | (250 V) 0.1 A
Rated Insulation Voltage (Ui)
250 V
Degree of Protection
IP40
Mounting Position
1
Standards
CAN/CSA C22.2 No.14 | IEC/EN 63000 | IEC/EN 61810-1 | UL 508
Maximum Operating Voltage UL/CSA
300 V AC
Pilot Duty UL/CSA
B300
Flammability According to UL94
HB
Ambient Air Temperature
Operation -40 ... +70 °C | Storage -40 ... +85 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
RoHS Status
Following EU Directive 2011/65/EU
CCC Certificate
CCC Certificate - Pluggable interface relays CR-U range
CQC Certificate
CQC Certificate, Interface Relays, CR-U, Made in Poland
CSA Certificate
CSA Certificate - Pluggable interface relays CR-P and CR-U
Declaration of Conformity - CCC
CCC Declaration of Conformity, Interface Relays, CR-U, Made in Poland
Declaration of Conformity - CE
EU Declaration of Conformity - CR-M, CR-U Pluggable interface relay
Declaration of Conformity - UKCA
UK Declaration of Conformity - CR-M, CR-U Pluggable interface-relays and accessories
EAC Certificate
EAC_RU_C-DE.ME77.B.00446-19
LR Certificate
LR Certificate - Pluggable interface relays CR-M and CR-U range
RMRS Certificate
RMRS Certificate - Pluggable interface relays CR range, except 60 V and 125 V versions
UR Certificate
UR (ANSI/UL 508) Certificate - Pluggable interface relays / optocouplers CR-M, CR-MX, CR-P, CR-S, CR-U range
VDE Certificate
VDE Certificate - Pluggable interface relays CR-U range
Package Level 1 Units
box 10 piece
Package Level 1 Width
182 mm
Package Level 1 Depth / Length
77 mm
Package Level 1 Height
76 mm
Package Level 1 Gross Weight
0.87 kg
Package Level 1 EAN
4013614375699
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
E-Number (Finland)
2712791
E-Number (Norway)
4187458
Feature: Pluggable CR-U universal interface relay design enables rapid plug-in replacement and modularity. Business Impact: Reduces downtime during maintenance and simplifies spare-part stocking across multi-line automation panels. Application: Ideal for conveyor controls and machine panels where quick swaps are critical. Feature: 2 c/o SPDT output with 250 V / 10 A ratings. Business Impact: Supports switching multiple circuits with a single input, improving control logic density and reducing wiring errors. Application: Suitable for interlocking and interlock-safe control circuits in packaging and processing lines. Feature: 220 V DC rated control supply and integrated actuation test button with LED indicators. Business Impact: Simplifies commissioning, troubleshooting, and status visibility, lowering commissioning time by operators and technicians. Application: Start/stop control and diagnostic testing in control cabinets. Feature: Robust circular pin terminals and DIN-rail snap-on compatibility. Business Impact: Improves durability in harsh environments and enables fast, tool-free installation and replacement. Application: Use in panel builders’ standardized DIN-rail layouts for scalable automation. Feature: Extended environmental and safety ratings including -40 to +70 °C operation, IP40, and up to 2000 m altitude. Business Impact: Ensures reliable performance in dusty, variable-temperature industrial settings with minimal derating. Application: Outdoor or semi-protected industrial enclosures and factory floors. Feature: Compliance and certifications including CE/UKCA, UL/CSA, and RoHS. Business Impact: Supports global market access and regulatory adherence for embedded automation solutions. Application: OEMs and integrators pursuing multi-region deployments and risk mitigation.
Get a Quick Quote for a ABB 1SVR405621R9000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR405621R9000?
Enquire Now
FAQs
The CR-U relay is designed for plug-in installation into compatible CR-U sockets and snap-on mounting onto a standard DIN rail. Simply align the relay’s pin terminals with the socket, press firmly to seat, and snap the assembly onto the DIN rail. This modular approach simplifies replacement, reduces wiring errors, and minimizes cabinet footprint while preserving secure electrical connections for repeated-cycle operation.
Key ratings include a 220 V DC rated control supply, 2 c/o SPDT output with a 250 V / 10 A switching capacity, and rated currents such as AC-12 (230 V) 10 A and AC-15 (230 V) 1.5 A. It also supports DC-12 (24 V) 10 A and DC-13 (24 V) 2 A | (250 V) 0.1 A, with insulation voltage of 250 V. These specs enable safe, versatile control of mixed loads in automation panels.
Yes. The relay operates from -40 to +70 °C and is rated for up to 2000 m altitude without derating, with an IP40 enclosure. These ratings make it suitable for factory floors, control panels in variable climates, and installations where robust reliability is essential, reducing the risk of failures in demanding environments.
The CR-U relay line carries CE and UKCA declarations, UL/CSA certifications, and RoHS compliance. Documentation includes the EU Declaration of Conformity for CR-U products, and related UL/CSA and RoHS attestations, supporting global market access and regulatory alignment for safety-critical control panels.
The modular, plug-in design reduces maintenance downtime and spare-part inventory costs by enabling fast replacement. The built-in test button and LED indicator speed commissioning and diagnostics, while the durable circular pin terminals improve long-term reliability. Overall, this translates to higher line uptime and lower total cost of ownership for automation systems.
