ABB 1SVR405641R3100 Pluggable interface relay - IP40
Part Number: 1SVR405641R3100
Quick Summary
ABB 1SVR405641R3100 pluggable interface relay provides compact SPDT switching for control circuits in industrial automation. When retrofitting panels, downtime and rewiring complexity are major pain points, so quick module swaps matter. Certified for CE with EU Declarations of Conformity, UL/CSA listings, and TÜV certification, it meets safety and regulatory expectations in diverse markets. Powered by a 230 V AC coil and delivering 7 A at 250 V on two SPDT contacts, it supports reliable control while reducing maintenance costs. Designed to work with standard CR-MX sockets and accessories, it streamlines installation and future upgrades. Its rugged temperature range and robust insulation help keep systems running in demanding environments. For procurement teams, standardized coil voltage and documented compliance simplify sourcing and auditing.
Product Information
Extended Description
1SVR405641R3100 ABB: The CR-MX230AC2LT pluggable interface relay is from the CR-MX (miniature) relay range. This relay operates with a 230 V AC rated control supply voltage and has a 2 c/o (SPDT) output with contacts rated at 250 V / 7 A. The relay has an integrated orange test button for manual actuation and locking of the output contacts and an integrated LED. Standard sockets, pluggable function modules, holders and markers are available as accessories.
EAN
4013614535895
Minimum Order Quantity
300 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Data sheet - Pluggable interface relays CR-MX Miniature relays
Instructions and Manuals
Instructions - CR-MX Range
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
21.5 mm
Product Net Height
37 mm
Product Net Depth / Length
28 mm
Product Net Weight
0.034 kg
Function
Pluggable miniature interface relay CR-MX
Sub-Function
Relay with built in LED
Rated Control Supply Voltage (Us)
230 V AC
Rated Operational Voltage
250 V AC
Rated Frequency (f)
50 / 60 Hz
Output
2 c/o (SPDT) contacts
Output Signal
250 V / 7 A
Terminal Type
Flat-Pin Connections
Rated Operational Current AC-12 (Ie)
(230 V) 7 A
Rated Operational Current AC-15 (Ie)
(120 V) 2 A | (230 V) 0.8 A
Rated Operational Current DC-12 (Ie)
(24 V) 7 A
Rated Operational Current DC-13 (Ie)
(24 V) 1.9 A | (120 V) 0.8 A
Rated Impulse Withstand Voltage (Uimp)
Between Coil and Contacts 1.5 kV
Rated Insulation Voltage (Ui)
250 V
Degree of Protection
IP40
Mounting Position
1
Standards
CSA 22.2 No. 14 | IEC/EN 63000 | IEC/EN 61010-1 | UL 508
Maximum Operating Voltage UL/CSA
250 V AC
Flammability According to UL94
V-2
Ambient Air Temperature
Operation -40 ... +70 °C | Storage -40 ... +70 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
1SVD982022-0002
RoHS Status
Following EU Directive 2011/65/EU
CQC Certificate
CQC Certificate - CR-MX range Pluggable interface relays with AC coil
cUR Certificate
cUR_E244330
Declaration of Conformity - CE
EU Declaration of Conformity - CR-MX Pluggable interface relays
TÜV Certificate
TUEV Certificate - Pluggable interface relays CR-MX range
Package Level 1 Units
box 10 piece
Package Level 1 Width
103 mm
Package Level 1 Depth / Length
142 mm
Package Level 1 Height
37 mm
Package Level 1 Gross Weight
0.42 kg
Package Level 1 EAN
4013614536243
Package Level 2 Units
box 300 piece
Package Level 2 EAN
4013614540400
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
Feature: 230 V AC coil with 2 c/o SPDT outputs. Benefit: simplifies wiring and ensures reliable signaling in standard control circuits. Application: machine control panels, interlocking circuits, and discrete signaling within automation systems. Feature: Integrated LED indicator and orange test button. Benefit: provides immediate status feedback and manual actuation without enclosure access, reducing fault isolation time. Application: commissioning and field testing in control cabinets. Feature: Compact footprint with flat-pin terminals (21.5 mm width, 37 mm height, 28 mm depth). Benefit: enables dense panel layouts and straightforward substitutions of existing relays. Application: space-constrained control panels and CR-MX range installations. Feature: IP40 protection and wide ambient operating range (-40 to +70 °C). Benefit: reliable performance in harsh factory environments and on-site installations. Application: electrical protection and circuit control in industrial environments. Feature: RoHS compliant with CE, UL/CSA, and TÜV certifications. Benefit: regulatory compliance across global supply chains reduces audit risk and accelerates procurement. Application: global deployment in electrical protection & circuit control. Feature: Compatibility with standard sockets, pluggable function modules, holders, and markers. Benefit: faster installation, easier upgrades, and streamlined maintenance. Application: modular control architectures with scalable automation design.
Get a Quick Quote for a ABB 1SVR405641R3100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR405641R3100?
Enquire Now
FAQs
Install the CR-MX230AC2LT in standard CR-MX sockets using flat-pin connections. The unit fits a compact footprint (21.5 mm wide, 37 mm high, 28 mm deep) and supports a 230 V AC coil with two SPDT outputs. Ensure proper orientation, verify IP40 protection in the enclosure, and use the appropriate pluggable module or holder for easy maintenance swaps.
Key specs include a 230 V AC coil, 250 V operational voltage, and a 7 A rating for AC-12 at 230 V. It provides 2 c/o SPDT contacts, a 50/60 Hz operating frequency, and an isolation of coil to contacts up to 1.5 kV impulse withstand. Ensure UL/CSA compliance and RoHS conformity for regulatory readiness.
Yes. It supports AC-12 at 230 V with up to 7 A, and AC-15 ratings of up to 0.8 A at 230 V. For DC operations, ratings include DC-12 at 24 V up to 7 A and DC-13 at 24 V up to 1.9 A, with appropriate de-rating at higher voltages. This makes it versatile for mixed control circuits in automation panels.
The relay carries CE DoC, UL/CSA listings (cUR_E244330), TÜV certification, and UL 508 compatibility. It is RoHS compliant and meets applicable CSA and IEC/EN standards. These certifications support safe operation, regulatory compliance, and global sourcing for electrical protection and circuit control.
Expect reduced downtime through rapid field replacement with pluggable modules, straightforward maintenance, and predictable lifecycle costs. The device’s modularity enables scalable automation architectures, easier spare-parts management, and faster commissioning thanks to standardized coil voltage and documented compliance across regions.
