ABB 1SVR405643R9000 Pluggable Interface Relay - UL/CSA
Part Number: 1SVR405643R9000
Quick Summary
ABB 1SVR405643R9000 is a pluggable interface relay designed for control panels and automation systems. In tight installations, engineers struggle with rapid replacement, mechanical wear, and unreliable actuation; this model supports plug-in modules, standardized sockets, and quick diagnostics to minimize downtime. It carries CE, UL/CSA, and TÜV certifications to support compliance for global machines and safety standards across diverse applications. The compact CR-MX footprint, 220 V DC coil rating, and 4 SPDT contacts simplify panel wiring while enabling safe, predictable operation. By combining rugged construction with easy maintenance, it helps reduce spare-part inventories and speeds project timelines.
Product Information
Extended Description
1SVR405643R9000 ABB: The CR-MX220DC4T pluggable interface relay is from the CR-MX (miniature) relay range. This relay operates with a 220 V DC rated control supply voltage and has a 4 c/o (SPDT) output with contacts rated at 250 V /5 A. The relay has an integrated blue test button for manual actuation and locking of the output contacts. Standard sockets, pluggable function modules, holders and markers are available as accessories.
EAN
4013614536120
Minimum Order Quantity
300 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Data sheet - Pluggable interface relays CR-MX Miniature relays
Instructions and Manuals
Instructions - CR-MX Range
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
21.5 mm
Product Net Height
37 mm
Product Net Depth / Length
28 mm
Product Net Weight
0.035 kg
Function
Pluggable miniature interface relay CR-MX
Rated Control Supply Voltage (Us)
220 V DC
Rated Operational Voltage
250 V AC
Output
4 c/o (SPDT) contacts
Output Signal
250 V / 5 A
Terminal Type
Flat-Pin Connections
Rated Operational Current AC-12 (Ie)
(230 V) 5 A
Rated Operational Current AC-15 (Ie)
(120 V) 1.9 A | (230 V) 0.8 A
Rated Operational Current DC-12 (Ie)
(24 V) 5 A
Rated Operational Current DC-13 (Ie)
(24 V) 1.8 A | (120 V) 0.5 A
Rated Impulse Withstand Voltage (Uimp)
Between Coil and Contacts 1.5 kV
Rated Insulation Voltage (Ui)
250 V
Degree of Protection
IP40
Mounting Position
1
Standards
CSA 22.2 No. 14 | IEC/EN 63000 | IEC/EN 61010-1 | UL 508
Maximum Operating Voltage UL/CSA
250 V AC
Flammability According to UL94
V-2
Ambient Air Temperature
Operation -40 ... +70 °C | Storage -40 ... +70 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
1SVD982022-0002
RoHS Status
Following EU Directive 2011/65/EU
CQC Certificate
CQC Certificate - CR-MX range Pluggable interface relays with DC coil
cUR Certificate
cUR_E244330
Declaration of Conformity - CE
EU Declaration of Conformity - CR-MX Pluggable interface relays
TÜV Certificate
TUEV Certificate - Pluggable interface relays CR-MX range
Package Level 1 Units
box 10 piece
Package Level 1 Width
103 mm
Package Level 1 Depth / Length
142 mm
Package Level 1 Height
37 mm
Package Level 1 Gross Weight
0.43 kg
Package Level 1 EAN
4013614536472
Package Level 2 Units
box 300 piece
Package Level 2 EAN
4013614540653
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
Feature: Pluggable miniature interface relay from the CR-MX family. Business Impact: enables fast field replacement and minimized downtime. Application: control cabinets and safety circuits where space is at a premium. Feature: 220 V DC coil with 4 c/o SPDT contacts and a 250 V AC / 5 A output. Business Impact: supports versatile logic levels and loads, reducing wiring complexity and stocking needs. Application: machine control and interlocking systems. Feature: Integrated blue test button for manual actuation. Business Impact: simplifies commissioning, troubleshooting, and verification without power cycling. Application: panel startup, diagnostics, and routine maintenance. Feature: IP40 enclosure and wide operating range (-40 to +70 °C). Business Impact: ensures reliable operation in harsh environments and varying climates. Application: industrial floors, cabinets, and outdoor installs with protection requirements. Feature: Compatibility with standard sockets, pluggable modules, and CAD resources. Business Impact: accelerates design-in and spare-parts management while reducing project risk. Application: automation engineers and system integrators designing control architectures. Feature: Regulatory and environmental compliance (RoHS, CMRT, CE, UL/CSA, TÜV). Business Impact: supports global manufacturing certifications and supplier responsibility goals. Application: regulated industries and multinational deployments.
