ABB 1SVR427030R0000 Power Supply - UL 508
Part Number: 1SVR427030R0000
Quick Summary
ABB 1SVR427030R0000 Power Supply is a compact 24 VDC, 0.75 A source designed for industrial automation and control panels. With 90-264 VAC and 120-375 VDC input ranges, 18 W output, and adjustable 21.6-28.8 VDC, it accommodates varied mains and loads. Hiccup-mode protection guards downstream devices, while parallel operation enables a straightforward redundancy strategy for critical processes. Certified to CE, UL 508, and cUL with EMC and safety approvals, it helps you meet regulatory demands across global sites. DIN rail mounting, a compact 22.5 mm width, IP20 housing, and CP‑E family compatibility streamline installation and service in control cabinets.
Product Information
Extended Description
1SVR427030R0000 ABB: The CP-E 24/0.75 is a power supply from the CP-E range. The primary switch mode power supply offers a wide range input of 90-264 V AC and 120-375 V DC, rated input voltage is 100-240 V AC. The rated output power is 18 W, rated output current is 0.75 A at an output voltage of 24 V DC. The output voltage is adjustable within a range of 21.6 to 28.8 V DC. The output characteristic is hiccup-mode. The power supply allows parallel operation to enable redundancy. A redundancy unit is available as accessory.
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
AETAD009EXPU
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
BRABB008EXPU
Country of Origin
China (CN)
Lead Time
74 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
CHABB001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Warranty Return
Product under warranty must be returned
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
CHSEC006EXPU
Lead Time
160 day
Warranty Return
Product under warranty must be returned
Stocked At Warehouses
CZABB004EXPU
Country of Origin
Germany (DE)
Made To Order
No
Product Sales Status
Active
Quote Only
No
Lead Time
55 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USSVCEXPU
Warranty Return
Product under warranty must be returned
Minimum Order Quantity
1 piece
Customs Tariff Number
85044095
Data Sheet, Technical Information
Data sheet - CP-E 24/0.75 Primary switch mode power supply
Instructions and Manuals
Instruction Sheet / Manual - CP-E 5/3.0 and CP-E 24/0.75
Product Net Width
22.5 mm
Product Net Height
90 mm
Product Net Depth / Length
114 mm
Product Net Weight
0.143 kg
Package Level 1 Width
134 mm
Package Level 1 Depth / Length
157 mm
Package Level 1 Height
39 mm
Package Level 1 Gross Weight
0.212 kg
Package Level 1 EAN
4016779656863
Package Level 1 Units
box 1 piece
Function
Switch mode power supply
Number of Phases
1
Rated Input Voltage (UIN)
100 ... 240 V AC
Input Voltage (Uin)
90 ... 264 V AC | 120 ... 375 V DC
Rated Frequency (f)
50 Hz
Rated Frequency Limits
47 ... 63 Hz
Characteristic of Output
Hiccup-mode
Rated Output Power
18 W
Output Power
18 W
Rated Output Voltage
24 V DC
Output Voltage (Uout)
24 V DC
Rated Output Current
0.75 A
Output Current
0.75 A
Rated Impulse Withstand Voltage (Uimp)
Input Circuit / Output Circuit 4 kV | Input Circuit / PE 2.5 kV | Input Circuit / Relay Contact 4 kV | Output Circuit / PE 0.5 kV
Rated Insulation Voltage (Ui)
Input Circuit / Output Circuit 300 V | Input Circuit / PE 300 V | Input Circuit / Relay Contact 300 V | Output Circuit / PE 50 V
Degree of Protection
Housing IP20 | Terminals IP20
Connecting Capacity Input Circuit
Flexible with Ferrule 0.2 ... 2.5 mm² | Rigid 0.2 ... 2.5 mm²
Connecting Capacity Output Circuit
Flexible with Ferrule 0.2 .... 2.5 mm² | Rigid 0.2 ... 2.5 mm²
Tightening Torque
Input Circuit 0.6 N·m | Output Circuit 0.6 N·m
Wire Stripping Length
Input Circuit 6 mm | Output Circuit 6 mm
Recommended Screw Driver
PH1
Minimum Mounting Distance
Electrical Conductive Board, Horizontal 25 mm | Electrical Conductive Board, Vertical 25 mm | Other Device Same Type, Horizontal 25 mm | Other Device Same Type, Vertical 25 mm
Mounting Position
1
Mounting on DIN Rail
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 | TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Standards
ANSI/ISA-12.12 | CAN/CSA C22.2 No.107.1 | CAN/CSA C22.2 No.213 | CAN/CSA C22.2 No.223 | CAN/CSA C22.2 No.60950 | IEC/EN 63000 | IEC 60950-1 | IEC/EN 61000-6-2 | IEC/EN 61000-6-3 | UL 1310 | UL 508 | UL 60950
Connecting Capacity Input Circuit UL/CSA
Rigid 24-14 AWG
Connecting Capacity Output Circuit UL/CSA
Rigid 24-14 AWG
Tightening Torque UL/CSA
Input Circuit 5 in·lb | Output Circuit 5 in·lb
Electrostatic Discharge (ESD Immunity) acc. to IEC 61000-4-2
Level 4 Air Discharge 15 kV | Level 4 Contact Discharge 8 kV
Radiated Electromagnetic Field Immunity acc. to IEC 61000-4-3
Level 3 10 V/m
Electrical Fast Transient (Burst Immunity) acc. to IEC 61000-4-4
Level 4 Power Supply Port Signal 4 kV
Surge Immunity acc. to IEC 61000-4-5
Level 3 Line-to-Line 2 kV | Level 4 Line-to-Ground 4 kV
Conducted Disturbances Immunity acc. to IEC 61000-4-6
Level 3 10 V
Electromagnetic Compatibility (EMC)
Immunity - Class B | Emission - Class B
Ambient Air Temperature
Operation -20 ... +70 °C | Storage -25 ... +85 °C
Maximum Operating Altitude Permissible
5000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
REACH Declaration
REACh Info for Power Supplies
RoHS Information
RoHS Declaration of conformity for Power Supplies
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration for Power Supplies
WEEE B2C / B2B
Business To Business
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
cUL Certificate
cUL508_E174460
cUR Certificate
cUR60950_E196145 | cUR1310_E313203 | cUR_ANSI_E317914
Declaration of Conformity - CE
EU Declaration of conformity - CP-E 24/0.75 and CP-E 5/3.0 Power supply units
Declaration of Conformity - UKCA
1SVD982034-10
UL Certificate
UL Certificate (UL 508) - CP-C, CP-D, CP-E, CP-S, and CP-T range power supply units, CP-ASI power supply units and DC/DC converter, CP-B range buffer modules and extension module, CC-E and CC-U range analog signal converters
UR Certificate
UR Certificate (UL 60950) - CP-C, CP-D, CP-E, CP-S, CP-T range power supply units, CP-A range accessories, and CP-ASI power supply units and DC/DC converter | UR Certificate (UL 1310) - CP-D, CP-E range power supply units | UR Certificate (ANSI/ISA-12.12) - CP-D, CP-T range power supply units
Object Classification Code
T
ETIM 7
EC002540 - DC-power supply
ETIM 8
EC002540 - DC-power supply
ETIM 9
EC002540 - DC-power supply
eClass
V11.0 : 27040701
UNSPSC
39121004
E-Number (Finland)
2712836
E-Number (Norway)
6609442
E-Number (Sweden)
5218700
Feature: Wide input range and stable output. Business Impact: Allows global deployment with fewer power design compromises and reduced inventory. Application: Control panels and automation cabinets where mains voltage varies. Feature: Adjustable output within 21.6–28.8 VDC. Business Impact: Compensates for voltage drop and load changes, improving PLC and sensor performance. Application: PLC power rails and field devices with tight tolerances. Feature: Output protection via hiccup-mode. Business Impact: Minimizes fault-induced downtime and extends equipment life. Application: Harsh factory environments with transient events. Feature: Redundancy-ready design with parallel operation. Business Impact: Improves system uptime for critical processes and systems. Application: Conveyor controls, robotics, and critical machinery. Feature: DIN rail mounting and compact footprint. Business Impact: Speeds installation and reduces cabinet footprint. Application: Panel builders and retrofit projects. Feature: Comprehensive certifications and EMC compliance. Business Impact: Expedites regulatory approvals and reduces compliance risk. Application: Global deployments across industries requiring safety and EMI protections.
Get a Quick Quote for a ABB 1SVR427030R0000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR427030R0000?
Enquire Now
FAQs
This power supply is designed for DIN rail mounting on TH35 rails (TH35-15 or TH35-7.5). It fits standard control cabinets and can be snap-mounted to the rail. For installation, ensure the minimum mounting distance is observed and use the recommended PH1 screwdriver; connect input and output conductors per the labeled terminals and torque specifications to maintain IP20 integrity.
Key specs include input voltage 90–264 VAC or 120–375 VDC, rated input 100–240 VAC, output 24 VDC at 0.75 A (18 W), and adjustable output 21.6–28.8 VDC. The output is hiccup-mode protected, and the unit supports parallel operation for redundancy, which is critical for PLC power rails and sensor networks.
Yes, it is designed for industrial environments with operation from -20 to +70 °C and storage down to -25 °C. It tolerates up to 5000 m altitude in permissible conditions. The housing is IP20 protected, suitable for indoor control cabinets where dust and incidental contact are managed.
The 1SVR427030R0000 carries CE and UL/cUL certifications, with UR and UL 508 declarations, plus EMC Class B compliance. These certifications streamline global approvals, support compliance in machine safety standards, and reduce the time and cost of regulatory sign-offs for new installations.
Redundancy via parallel operation significantly improves uptime for critical systems, reducing downtime costs. The robust CP‑E design, long-term availability of spares, and 0-day lead times in stock at multiple warehouses support predictable maintenance cycles and a favorable TCO for automation projects.
