ABB CP-PX-A-LBR.04 L Bracket Accessory - IEC63000
Part Number: 1SVR427091R9130
Quick Summary
ABB CP-PX-A-LBR.04 is an L bracket accessory that enables DIN rail mounting of CP-PX 24 V DC/3.2 A power supplies. This simple mounting solution addresses misalignment and free-space challenges that can cause panel wiring delays and service interruptions. It carries CE conformity, RoHS compliance, and CMRT documentation, backed by IEC/EN 63000, EN 55024, EN 55032, and IEC 60950-1 standards. This enables faster installation, reduces warranty-risk costs, and supports scalable control-panel designs for industrial automation. Designed for CP-PX 24/3.2 A systems, the kit improves EMI performance by providing a robust DIN-rail mount that keeps cables organized and minimizes mechanical strain. Its compact footprint and standardized dimensions simplify inventory and replacement planning across multiple lines.
Product Information
Extended Description
1SVR427091R9130 ABB: The CP-PX-A-LBR.04 is a fixing kit, which allows to mount a power supply CP-PX 24/3.2 on to a DIN rail.
Minimum Order Quantity
1 piece
Customs Tariff Number
73269098
Data Sheet, Technical Information
1SXF110013C2001 Rev C 05-2019
Instructions and Manuals
1SXF110013C2001 Rev C 05-2019
Product Net Width
103 mm
Product Net Height
48 mm
Product Net Depth / Length
146 mm
Product Net Weight
0.132 kg
Package Level 1 Width
146 mm
Package Level 1 Depth / Length
103 mm
Package Level 1 Height
48 mm
Package Level 1 Gross Weight
0.132 kg
Package Level 1 EAN
4016779011013
Package Level 1 Units
bag 1 piece
Standards
IEC/EN 63000 | EN 55024 | EN 55032 | IEC 60950-1
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
RoHS Information
EU Declaration of conformity - CP-PX Power supply units
RoHS Status
Following EU Directive 2011/65/EU
WEEE Category
Product Not in WEEE Scope
Declaration of Conformity - CE
EU Declaration of conformity - CP-PX Power supply units
Object Classification Code
T
Feature: DIN rail mounting compatibility provides a secure attachment for the CP-PX 24/3.2 A power supply, reducing vibration and connector fatigue in dynamic automation environments. Business impact: longer service life, fewer field-rework calls, and lower post-installation support costs. Application: ideal for machine builders and panel integrators deploying CP-PX powered control systems in packaging, robotics, and process lines. Feature: Exact dimensions—103 mm width, 48 mm height, and 146 mm depth—enable compact layouts and standardized spacing in crowded control cabinets. Business impact: improved air flow, easier cable management, and faster inventory planning. Application: retrofit projects and new builds where DIN rail mounting of CP-PX is required. Feature: Certifications and declarations align with industry expectations—IEC/EN 63000, EN 55024, EN 55032, IEC 60950-1—with RoHS and CE marking and CMRT documentation. Business impact: simplifies procurement and risk management across regulated sectors. Application: automotive, food & beverage, and general automation where supplier qualification matters. Feature: Installation ease—pre-aligned mounting holes and standardized footprint support quick installation and maintenance. Business impact: faster changeouts, reduced labor hours, and improved uptime. Application: OEMs installing multiple CP-PX units on existing control panels. Feature: Robust mechanical design improves EMI integrity and safety margins, helping maintain performance in noisy electrical environments. Application: stringent industrial environments where reliability and safety are critical.
Get a Quick Quote for a ABB 1SVR427091R9130
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR427091R9130?
Enquire Now
FAQs
Install the L bracket accessory by aligning the CP-PX unit to the DIN rail and sliding it into the bracket’s mounting slots. Ensure the power supply is securely snapped and that cabling exits are organized to prevent strain. Use standard DIN-rail mounting practices and verify electrical connections follow CP-PX installation guidelines.
The accessory adds a compact footprint with a product net width of 103 mm, height of 48 mm, and depth of 146 mm, with a net weight of 0.132 kg. These dimensions enable predictable spacing in crowded control cabinets and simplify layout planning for CP-PX 24/3.2 A supplies.
Yes. The L bracket supports EMI-conscious installations by providing a stable, mechanically robust mounting method for the CP-PX power supply, contributing to improved EMI performance in panels that require EN 55024 and EN 55032 compliance.
The accessory aligns with IEC/EN 63000, EN 55024, EN 55032, and IEC 60950-1 standards, with RoHS compliance and CE declaration. CMRT documentation is available for supply chain transparency, aiding audits and regulatory compliance.
The kit enables faster installation, reduces panel-space conflicts, improves cable management, and lowers maintenance costs by minimizing mechanical stress on terminations. It also supports scalable, modular control-panel designs across multiple lines and installations.
