ABB 1SVR440029R0100 ADP.02 Adapter for screw mounting 45mm - CE/UKCA RoHS
Part Number: 1SVR440029R0100
Quick Summary
ABB 1SVR440029R0100 ADP.02 adapter enables screw mounting of an N housing on panels or walls. This solution addresses the common challenge of secure, space-efficient installations in compact electrical enclosures. It carries CE and UKCA declarations, along with RoHS and REACH compliance, ensuring regulatory-ready integration in European and UK projects. The accessory is designed to fit ABB measuring and monitoring relays within the 45 mm panel format, reducing assembly time and potential misalignment. The data sheets, CAD drawings, and manuals are readily available to accelerate engineering workflows and support efficient procurement. Leveraging this adapter can lower field service time and spare parts inventory.
Product Information
Extended Description
1SVR440029R0100 ABB: The ADP.02 adapter for screw mounting is an accessory. The adapter allows the screw mounting of a N housing on panel or wall.
EAN
4016779570442
Minimum Order Quantity
1 piece
Customs Tariff Number
39269097
Data Sheet, Technical Information
Catalog 2024 Electronic Relays and Controls - Chapter Measuring and Monitoring Relays
Instructions and Manuals
2CDC110004C0209
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
45 mm
Product Net Height
70 mm
Product Net Depth / Length
11.5 mm
Product Net Weight
0.037 kg
Function
11 Accessory
Sub-Function
none
Time Range
none
Output
none
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
REACH Declaration
REACh Info for Electronic Relays and Controls
RoHS Information
RoHS Declaration of conformity for Electronic Relays and Controls
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA
REACh Info for Electronic Relays and Controls
Declaration of Conformity - CE
EU Declaration of Conformity - ADP.xx ; MAR.xx ; COV.xx ; OPR.01 Accessory
Declaration of Conformity - UKCA
UK Declaration of Conformity - ADP.xx ; MAR.xx ; COV.xx ; OPR.01 Accessory
Package Level 1 Units
bag 1 piece
Package Level 1 Width
46 mm
Package Level 1 Depth / Length
12 mm
Package Level 1 Height
71 mm
Package Level 1 Gross Weight
0.039 kg
Package Level 1 EAN
4016779570442
ETIM 7
EC002498 - Accessories for low-voltage switch technology
ETIM 8
EC002498 - Accessories/spare parts for low-voltage switch technology
ETIM 9
EC002498 - Accessories/spare parts for low-voltage switch technology
eClass
V11.0 : 27371392
UNSPSC
39122221
E-Number (Norway)
4187719
Feature design and compatibility drive tangible gains. The ADP.02 adapter is a compact, 45 mm wide accessory that integrates with ABB N housings to enable secure screw mounting on panels or walls, delivering space efficiency and stable alignment for critical relays. Business impact: faster installation and reduced risk of misalignment translate to lower commissioning time and fewer field returns. Application: ideal for panel-mounted protection and control relays in electrical installations. The 70 mm height and 11.5 mm depth keep the footprint minimal, while a weight of 0.037 kg simplifies handling during field or factory assembly. Business impact: lighter components reduce handling time and fatigue in tight control cabinets. Application: suited for retrofit projects and new builds requiring streamlined mounting workflows. Regulatory compliance is built in with CE, UKCA, RoHS, and REACH declarations, reducing regulatory risk and simplifying approvals in Europe and the UK. Application: essential for compliant deployments across markets. Documentation and CAD support enable engineering teams to design confidently, minimizing integration errors. Business impact: CAD Dimensional Drawings and Data Sheets speed up BIM/CAD workflows and supplier collaboration. Packaging and logistics data (minimum order quantity 1 piece; EAN 4016779570442; bag packaging) support straightforward procurement and inventory management. Application: easy stocking and consistent order fulfillment. ETIM classifications and UNSPSC codes align with industrial procurement workflows, ensuring accurate category placement and cross-library compatibility. Application: procurement-grade traceability and standardization.
Get a Quick Quote for a ABB 1SVR440029R0100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR440029R0100?
Enquire Now
FAQs
The ADP.02 is a screw-mounting accessory designed to secure an N housing to a panel or wall. Start by aligning the adapter with the panel cutout or mounting surface, insert the screws appropriate for your panel thickness, and tighten to specification to ensure a stable, vibration-resistant fit. Check that the housing sits flush and that cables have sufficient clearance for maintenance access.
The adapter supports a 45 mm width, with a product height of 70 mm and a depth of 11.5 mm. It weighs 0.037 kg, making it a lightweight yet robust mounting accessory suitable for dense electrical panels and compact enclosures.
Yes. The ADP.02 adapter carries CE and UKCA declarations, along with RoHS and REACH compliance, ensuring regulatory suitability for European and UK projects and reducing compliance risk during qualification and installation.
The ADP.02 adapter is used to mount ABB N housings for measuring and monitoring relays in electrical protection and circuit control scenarios. It facilitates secure, space-efficient panel mounting in control cabinets and electrical enclosures, streamlining retrofit and new-install workflows.
ABB provides CAD Dimensional Drawings and Data Sheets for the ADP.02, along with manuals and product catalogs. Access the Information – 2D and 3D CAD files, and the Catalog 2024 Electronic Relays and Controls documentation to support CAD integration and procurement.
