ABB 1SVR730840R0600 Current Monitoring Relay - CE/UL
Part Number: 1SVR730840R0600
Quick Summary
Current monitoring relay CM-SRS.M1S enables precise current supervision for single-phase electrical circuits in machine control. Engineers frequently struggle with nuisance trips and inaccurate threshold settings that drive unexpected downtime. With CE conformity, UL/CSA listings, and IP50 enclosure protection, the device meets global safety and installation standards. Designed for ABB's CM-SRS family, it integrates seamlessly with DIN rail mounting in Automation & Control Systems, delivering scalable protection for industrial automation applications while offering configurable thresholds, delays, and latching options to match complex control logic.
Product Information
Extended Description
1SVR730840R0600 ABB: The CM-SRS.M1S is a multifunctional current monitoring relay from the CM single-phase monitors range. This monitoring relay operates with a rated control supply voltage of 24 - 240 V AC / DC and has a 2 c/o (SPDT) output with contacts rated at 250 V / 4 A. It provides a RMS measuring principle for DC and AC currents with 3 measuring ranges: 3-30 mA, 10-100 mA and 0.1-1 A. The CM-SRS.M1S offers selection of over- or undercurrent monitoring, open- or closed-circuit operating principle, with or without latching function. The hysteresis is adjustable within a range of 3 to 30 % of the threshold value. The tripping delay and the start-up delay are adjustable over a range of instantaneous to 30 s (0, 0.1-30 s). A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers screw connection technology with double-chamber cage connection terminals.
Country of Origin
Switzerland (CH)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
CHABB001EXPU
Warranty Return
Product under warranty must be returned
EAN
4016779852265
Minimum Order Quantity
1 piece
Customs Tariff Number
85364900
Data Sheet, Technical Information
Data sheet - CM-SRS.M1P; CM-SRS.M1S Multifunctional current monitoring relays, single-phase AC/DC
Instructions and Manuals
Instruction Sheet / Manual - CM-SxS Single-phase current monitoring relays | Installation instructions - CM-SxS Single-phase current monitoring relays
CAD Dimensional Drawing
Information - 2D and 3D files for CAD systems
Product Net Width
22.5 mm
Product Net Height
85.6 mm
Product Net Depth / Length
103.7 mm
Product Net Weight
0.153 kg
Function
Over- or undercurrent monitoring
Measuring Range
3 ... 30 mA | 10 ... 100 mA | 0.1 ... 1 A
Time Range
0 s or 0.1 ... 30 s start-up delay | 0 s or 0.1 ... 30 s tripping delay (ON)
Rated Control Supply Voltage (Us)
24 ... 240 V AC/DC
Output
2 c/o (SPDT) contacts; operating principle selectable
Terminal Type
Screw Terminals
Rated Operational Current AC-12 (Ie)
(230 V) 4 A
Rated Operational Current AC-15 (Ie)
(230 V) 3 A
Rated Operational Current DC-12 (Ie)
(24 V) 4 A
Rated Operational Current DC-13 (Ie)
(24 V) 2 A
Minimum Switching Capacity
24 V | 10 mA
Rated Impulse Withstand Voltage (Uimp)
Measuring Circuit / Output Circuit 6 kV | Output Circuit 1 / Output Circuit 2 4 kV | Supply Circuit / Measuring Circuit 6 kV | Supply Circuit / Output Circuit 4 kV
Rated Insulation Voltage (Ui)
Measuring Circuit / Output Circuit 600 V | Output Circuit 1 / Output Circuit 2 250 V | Supply Circuit / Measuring Circuit 600 V | Supply Circuit / Output Circuit 250 V
Degree of Protection
Housing IP50 | Terminals IP20
Overvoltage Category
III
Pollution Degree
3
Short-Circuit Protective Devices
Output Circuit NC - F Type Fuses 10 A | Output Circuit NO - F Type Fuses 10 A
Electrical Durability
AC-12 100000 cycle
Mechanical Durability
Nr. Operations 30000000 cycle
Connecting Capacity
Flexible with Ferrule 1x 0.5 ... 2.5 mm² | Flexible with Ferrule 2x 0.5 ... 1.5 mm² | Flexible with Insulated Ferrule 1x 0.5 ... 2.5 mm² | Flexible with Insulated Ferrule 2x 0.5 ... 1.5 mm² | Flexible 1x 0.5 ... 2.5 mm² | Flexible 2x 0.5 ... 1.5 mm² | Rigid 1x 0.5 ... 4 mm² | Rigid 2x 0.5 ... 2.5 mm²
Tightening Torque
0.6 ... 0.8 N·m
Wire Stripping Length
8 mm
Recommended Screw Driver
0.8 x 4 | 4.5 | Pozidriv 1
Mounting Position
1 ... 6
Mounting on DIN Rail
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 | TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Standards
CAN/CSA C22.2 No.14 | IEC/EN 63000 | IEC/EN 60255-27 | IEC/EN 61000-6-2 | IEC/EN 61000-6-3 | UL 508
Maximum Operating Voltage UL/CSA
Output Circuit 300 V AC
Contact Rating UL/CSA
B300
Connecting Capacity UL/CSA
Flexible 1x 18-14 AWG | Flexible 2x 18-16 AWG | Rigid 1x 20-12 AWG | Rigid 2x 20-14 AWG
Tightening Torque UL/CSA
7.08 in·lb
Pilot Duty UL/CSA
B300
Flammability According to UL94
V-0
Ambient Air Temperature
Operation -20 ... +60 °C | Storage -40 ... +85 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Conflict Minerals Reporting Template (CMRT)
CMRT - Conflict Minerals Reporting Template
REACH Declaration
REACh Info for Electronic Relays and Controls
RoHS Information
RoHS Declaration of conformity for Electronic Relays and Controls
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA
Toxic Substances Control Act (TSCA) declaration for Electronic Relays and Controls
CB Certificate
CB_DK-28255-UL
CQC Certificate
CQC Certificate, Relays, CM-SRS.., CM-SFS.., CM-ESS..,CM-EFS.., CM-TCS.., Made in Germany
cULus Certificate
cULus508_20120203-E140448
Declaration of Conformity - CCC
CCC Certificate, Relays, CM-SRS.., CM-SFS.., CM-ESS..,CM-EFS.., CM-TCS.., Made in Germany
Declaration of Conformity - CE
EU Declaration of Conformity - CM-ExS.xxx, CM-SxS.xxx Single-phase current and voltage monitoring relays
Declaration of Conformity - UKCA
UK Declaration of Conformity - CM-ExS.xxx, CM-SxS.xxx Single-phase current and voltage monitoring relays
DNV GL Certificate
DNV Certificate - Current monitoring relays CM-SFS.x and CM-SRS.x with screw or push-in terminals
EAC Certificate
EAC Certificate - Measuring and monitoring relays CM-xxS.xxx and CM-xxN.xxx range in the new housing
Package Level 1 Units
box 1 piece
Package Level 1 Width
97 mm
Package Level 1 Depth / Length
30 mm
Package Level 1 Height
109 mm
Package Level 1 Gross Weight
0.175 kg
Package Level 1 EAN
4016779852265
Object Classification Code
B
ETIM 7
EC001440 - Current monitoring relay
ETIM 8
EC001440 - Current monitoring relay
ETIM 9
EC001440 - Current monitoring relay
eClass
V11.0 : 27371802
UNSPSC
39122332
E-Number (Finland)
2712319
E-Number (Norway)
4188070
E-Number (Sweden)
3860629
The CM-SRS.M1S is a multifunctional current monitoring relay that operates from 24 to 240 V AC or DC, enabling versatile deployment across global panels and control schemes. This feature supports easier design-in and reduces inventory complexity for system integrators, while delivering reliable monitoring for single-phase circuits in automation projects. Business impact includes lower commissioning time and fewer field adjustments thanks to screw-terminal wiring that speeds installation and minimizes wiring errors. In practical terms, this means faster panel builds, improved uptime, and better alignment with ISO and IEC documentation requirements in modern factories. The device also supports 2 c/o SPDT outputs, enabling simple interlock or alarm signaling for motor protection and fault notification within standard automation architectures.
Get a Quick Quote for a ABB 1SVR730840R0600
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 1SVR730840R0600?
Enquire Now
FAQs
The CM-SRS.M1S operates from 24 to 240 V AC/DC and uses screw terminals for wiring. It provides two SPDT outputs (2 c/o), rated for 250 V and up to 4 A. For single-phase control, connect the supply lines to the device as per the instruction sheet, route the monitored line through the device’s input, and use the SPDT contacts to drive a control circuit or alarm relay. This setup minimizes wiring errors and supports reliable protection logic in machine panels.
The CM-SRS.M1S offers three measuring ranges: 3-30 mA, 10-100 mA, and 0.1-1 A, enabling precise current monitoring across a range of loads. Start-up and tripping delays are adjustable from instantaneous to 0.1-30 seconds, and hysteresis can be set between 3% and 30% of the threshold value to prevent nuisance trips. Use the device’s adjustment potentiometers or menu (per supplier instructions) to configure the threshold, delay, and hysteresis to match your protection criteria.
Yes, the CM-SRS.M1S is designed for DIN rail mounting (TH35-15 or TH35-7.5) and features screw-terminal wiring for reliable connections. Install the relay in a panel within its operating temperature range of -20 to +60 °C, and ensure adequate clearance for ventilation and wiring. The enclosure provides IP50 protection for the housing and IP20 for terminals, supporting robust operation in standard automation environments.
The CM-SRS.M1S carries multiple certifications and declarations, including CE conformity and UKCA, UL/CSA and cULus listings, CCC and CB certificates, and CQC recognition. It also aligns with relevant standards such as IEC/EN 63000, IEC/EN 60255-27, IEC/EN 61000-6-2, and IEC/EN 61000-6-3, ensuring compliance for safety, reliability, and EMI/EMC performance in industrial environments.
Deploying the CM-SRS.M1S reduces downtime by accurately detecting over- or under-current conditions with stable hysteresis, minimizing nuisance trips. Its 24-240 V supply, DIN rail mounting, and screw-terminal wiring simplify installation and maintenance, lowering field service time. With proven electrical durability (AC-12 cycles) and mechanical durability (millions of operations), operators can expect longer mean times between failures and faster fault diagnosis, improving line productivity and overall return on investment.
