2CDG120092R0011
Part Number: 2CDG120092R0011
Product Information
Extended Description
2CDG120092R0011 ABB: The Electromotor Valve Drive KNX ST/K1.2 provides precise control for heating and cooling valves, ensuring secure communication through KNX Data Secure. It is equipped with an integrated temperature sensor and an integrated room temperature controller. It delivers a high actuating force of up to 220 N and a maximum valve stroke of 8 mm. It features 2 universal binary inputs, supporting connection options such as window contacts, presence detectors, and push-buttons. The second input also supports external temperature sensors. Additionally, the drive includes automatic valve adaptation and is compatible with a wide range of valve adapters, making it universally applicable. 2 adapters for the most common valves (M30x1.5 and Danfoss RA -VA 10 & VA 100-) are supplied. The Bus Coupler is integrated. The device can be used in the heating circuit distributor. The actual valve position can be indicated by 5 LEDs.
Instructions and Manuals
Installation and Operating Instructions (.PDF) [XX] ST/K 1.2
Wiring Diagram
Connection diagram (.svg) [XX] ST/K 1.2
Mounting Type
Built-in
Modular Components Included
Complete Device
Degree of Protection
IP21
Data Sheet, Technical Information
Technical data (.PDF) [NL] ST/K 1.2
Number of Digital Inputs
2
Number of Inputs
Analog (0 ... 10 V / 4 ... 20 mA) 1
Compatible Bus Systems
KNX (TP)
Product Range
KNX
Manual Operation
No
Number of Batteries
0
Security Standard
KNX Data Secure
Voltage Range
12 ... 30 V DC
Power Loss
0.35 W
Color
white
Product Net Width
50 mm
Product Net Height
64 mm
Product Net Depth / Length
80.3 mm
Product Net Weight
0.02 kg
Dimension Diagram
Dimensional Drawing (.svg) [XX] ST/K 1.2
E-Number (Finland)
2815743
E-Number (Norway)
4544707
E-Number (Switzerland)
405710205
RoHS Information
CE Declaration of Conformity (.PDF) ST/K 1.2
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
REACH Declaration
Declaration regarding the REACH-Regulation
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20240123
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Cyber Security Software Support Period
2 year
Declaration of Conformity - CE
CE Declaration of Conformity (.PDF) ST/K 1.2
ETIM 9
EC000792 - Actuating drive for bus system
eClass
V11.0 : 27143135
Object Classification Code
A
