ABB 2CKA001012A1713 Card Switch Insert - IP20
Part Number: 2CKA001012A1713
Quick Summary
ABB 2CKA001012A1713 Card Switch Insert is a compact 1P+N push-button control designed for flush-mounted panels in industrial applications. It delivers a single normally-open contact rated at 10 A and 250 V, ideal for start/stop or control sequencing in machine enclosures. Engineers often contend with panel-space constraints while needing robust, easy-to-wire components; this insert meets those demands with both claw and screw mounting and a mounting plate for quick installation. It carries IP20 protection and CE/UKCA declarations, while RoHS and REACH compliance support sustainable manufacturing. With illuminable options and screw-terminal wiring, it adds value to OEM builds and Retrofit projects, reducing downtime and simplifying serviceability while maintaining safety and reliability.
Product Information
Extended Description
2CKA001012A1713 ABB: Illuminable. With N terminal.
Mounting Type
Flush Mounted
Type of Fastening
Mounting with Claw | Mounting with Screw
Modular Components Included
Flush Mounted Insert with Mounting Plate
Degree of Protection
IP20
Number of Poles
1P+N
Wiring Configuration
1-pole push button
Actuator Type
Hotel card
Illumination
Optional
Terminal Type
Screw Terminals
Rated Voltage (Ur)
250 V
Rated Current (In)
10 A
Number of Contacts NO
1
Design Range
Platform 63 | Busch-art linear | future linear | Busch-axcent | solo | Pure Stainless Steel | carat | Busch-Dynasty
Design Range Variant
Busch-art linear | Busch-art linear - with Decor Ring | Busch-art linear - pur | future | future linear | Busch-axcent | Busch-axcent pur
Surface Finishing
Untreated
Material
Thermoplastic | Duroplast
Label Space Provided
No
Product Net Width
71 mm
Product Net Height
71 mm
Product Net Depth / Length
40.1 mm
Product Net Weight
56 g
Built-In Depth (t2)
32 mm
RoHS Information
Product Declaration.PDF [EN] 2025 U
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
REACH Declaration
All Articles_REACH_EN_24-2_2CKA309999E9999
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20250218
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
EU-Declaration of conformity (.PDF) [EN] 2025 U
Declaration of Conformity - UKCA
UKCA Declaration of Conformity.PDF [EN] 2025 U
ETIM 9
EC000029 - Push button
eClass
V11.0 : 27144044
Feature → Business Impact → Application: 1P+N wiring configuration simplifies control circuit wiring and minimizes risk of miswiring, delivering more reliable operations in single-phase controllers and machine enclosures. This translates to faster panel assembly and reduced commissioning time in automotive, packaging, and automation lines. Feature → Business Impact → Application: 1 NO contact at 250 V/10 A supports standard start/stop logic for a wide range of industrial actuators, enabling predictable switching performance and lower wear under normal duty cycles. Feature → Business Impact → Application: Flush Mounted mounting with optional illumination provides a clean front face and improved visibility in low-light environments, enhancing operator awareness in control stations and panel interiors. Feature → Business Impact → Application: Mounting with claw or screw options plus a mounting plate accelerates installation across retrofits and new builds, reducing field service time and enabling quick part replacement in control cabinets. Feature → Business Impact → Application: Screw terminals offer secure, vibration-resistant connections for high-density panels, decreasing contact failures and maintenance costs in harsh industrial settings. Feature → Business Impact → Application: IP20 protection and material compliance (RoHS/REACH/WEEE) minimize regulatory risk while supporting sustainable design, suitable for control panels in food & beverage, packaging, and material-handling equipment. Feature → Business Impact → Application: Designed for compact spaces (71x71 mm face, 40.1 mm depth) with a built-in depth of 32 mm, it fits standard modular enclosures and supports scalable panel architectures across OEM and retrofits. Fortified by ETIM and eClass classifications, the device integrates seamlessly into modern MRO workflows and procurement catalogs.
Get a Quick Quote for a ABB 2CKA001012A1713
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 2CKA001012A1713?
Enquire Now
FAQs
The device is designed for flush-mounted installation with two mounting options: claw or screw, plus a mounting plate. Begin by preparing a compatible cutout, connect the 1P+N wiring to the screw terminals (rated 250 V, 10 A), and secure the insert using the chosen mounting method. If illumination is needed, wire the optional LEDs as per the schematic and verify IP20 protection once mounted.
This card switch insert uses a single normally-open contact (NO) in a 1P+N configuration, rated for 250 V and up to 10 A. It provides one NO contact suitable for simple start/stop functions in control circuits and is compatible with screw-terminal wiring for reliable, vibration-resistant connections.
The device offers IP20 protection, which is appropriate for interior panel mounting but not for exposed or harsh extrinsic environments. It should be used inside control cabinets or protected enclosures. CE and UKCA declarations, along with RoHS/REACH compliance, support regulatory requirements in many industries.
ABB provides CE and UKCA declarations of conformity and RoHS/REACH compliance for this product. WEEE classification is also noted, aligning with disposal guidelines. ETIM 9 and eClass codes further assist in cataloging and procurement efforts within industrial buying processes.
Installation benefits include rapid mounting with claw or screws and a mounting plate, plus straightforward wiring via screw terminals, reducing commissioning time and field maintenance. The compact footprint and modular design enable scalable panel architectures, lowering lifecycle costs and downtime in manufacturing lines.
