2CKA002122A0026
Part Number: 2CKA002122A0026
Product Information
Extended Description
2CKA002122A0026 ABB: For wall box 58 mm with screw fixation.
Mounting Type
Flush Mounted
Type of Fastening
Mounting with Screw | Without Claw
Modular Components Included
Cover with Flush Mounted Insert and Mounting Plate
Degree of Protection
IP20
Number of Poles
2P+PE
Number of Phases
1
Number of Gangs
1
Socket Outlet Type
NEMA
Terminal Type
Screw Terminals
Rated Voltage (Ur)
125 V
Rated Current (In)
20 A
Rated Frequency (f)
60 Hz
Design Range
Busch-Duro 2000 SI
Design Range Variant
Busch-Duro 2000 SI | Busch-Duro 2000 SI Linear
Surface Finishing
Untreated | Glossy
Material
Thermoplastic
Label Space Provided
No
RAL Number
Similar to RAL 1013
Color
white
Product Net Width
71 mm
Product Net Height
71 mm
Product Net Depth / Length
33 mm
Product Net Weight
64 g
Built-In Depth (t2)
21 mm
RoHS Information
Product Declaration.PDF [EN] 3016 EUC-212
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
REACH Declaration
All Articles_REACH_EN_24-2_2CKA309999E9999
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20240705
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
EU-Declaration of conformity (.PDF) [EN] 3016 EUC-212
ETIM 9
EC000125 - Socket outlet
eClass
V11.0 : 27144042
