2CKA006133A0151
Part Number: 2CKA006133A0151
Product Information
Extended Description
2CKA006133A0151 ABB: Interface with 4 channels as inputs or outputs parameterisable. Connecting cables max. 10 m. Inputs for potential free contacts. Outputs: 5 V max. 2 mA (e.g. LED) For flush-mounted sockets with a depth of 60 mm or also suitable for hollow-wall sockets. Dimensions: 39 x 40 x 12 mm
Instructions and Manuals
Installation and Operating Instructions (.PDF) [EN] 6119/40
Wiring Diagram
Connection diagramm [EN] 6119-40
Mounting Type
Flush Mounted
Modular Components Included
Complete Device
Degree of Protection
IP20
Data Sheet, Technical Information
Product manual (.PDF) [DE] 6119/40
Sub-Function
LED controlling
Number of Inputs
4 | Analog (0 ... 10 V / 4 ... 20 mA) 4
Compatible Bus Systems
KNX (TP)
Product Range
KNX
Manual Operation
No
Number of Batteries
0
Input Voltage Type
Pulsed
Power Loss
0.25 W
Color
white
Product Net Width
12 mm
Product Net Height
39 mm
Product Net Depth / Length
40 mm
Product Net Weight
0.044 kg
Dimension Diagram
Dimension drawing [EN] m_6119_40
Replacement Product ID (NEW)
GHQ6310070R0111
RoHS Information
Declaration REACH and ElektroG
RoHS Status
Following EU Directive 2002/95/EC August 18, 2005 and amendment
REACH Declaration
Declaration regarding the REACH-Regulation
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20231212
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
EU-Declaration of conformity (.PDF) [EN] 6119/40
ETIM 9
EC001584 - I/O device for bus system
eClass
V11.0 : 27143145
