2CKA006151A0215
Part Number: 2CKA006151A0215
Product Information
Extended Description
2CKA006151A0215 ABB: 1gang switching-dimmer actuator for dimming an ECG-group with 1 - 10 V interface In connection with the light sensor 6197/21 also as constant light controller. Installation and contacting is effected exclusively in the room controller
Instructions and Manuals
Installation and Operating Instructions (.PDF) LR/M1.6.2
Mounting Type
Built-in
Degree of Protection
IP54
Data Sheet, Technical Information
Product Information (.PDF) [EN] RC/Ax.1
Number of Outputs
1
Compatible Bus Systems
KNX (TP)
Product Range
KNX
Transmission Standard
Twisted Pair Wiring
Manual Operation
No
Number of Batteries
0
Terminal Type
Bus Connection
Voltage Range
230 V
Output Voltage (Uout)
230 V AC
Maximum Switching Current
6 A
Maximum Control Current DC
30 mA
Color
anthracite
Product Net Width
49 mm
Product Net Height
42 mm
Product Net Depth / Length
93 mm
Product Net Weight
0.1 kg
Replacement Product ID (NEW)
2CDG110108R0011
RoHS Information
Declaration REACH and ElektroG
RoHS Status
Following EU Directive 2002/95/EC August 18, 2005 and amendment
REACH Declaration
Declaration regarding the REACH-Regulation
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20231212
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
EU-Declaration of conformity (.PDF) [EN] 6174/16-101
ETIM 9
EC001095 - Light control unit for bus system
eClass
V11.0 : 27143134
