ABB 2CKA006400A0088 Flush Mounted Inserts - CE
Part Number: 2CKA006400A0088
Quick Summary
Flush Mounted Inserts 230 V provide compact control for lighting systems in modern electrical installations. These devices fit 1-gang, 2-way configurations and operate without the neutral conductor, simplifying retrofits. The product is CE marked with RoHS and REACH declarations, and it complies with WEEE requirements, supporting responsible disposal. This ABB insert is designed for seamless compatibility with Busch-Comfort switch elements and presence detectors, enabling scalable control in both replacement and new-build projects. With a built-in depth of 32 mm and an enclosure of 80 x 60 x 95 mm, installation is straightforward in flush-mounted boxes. By leveraging LED retrofit compatibility and universal load handling, it delivers reliable performance while minimizing wiring complexity and ongoing maintenance.
Product Information
Extended Description
2CKA006400A0088 ABB: 2-wire connection (neutral conductor not required) For switching lighting systems. For Busch-Comfort switch control element 6815-to-101. For Busch-Presence detector sensors 6813- to -102. Combinable with Universal slave insert 6440/05 U. Operation in 1gang 2way installations via push switch-unit for combination with flush-mounted units. Operation also possible via conventional push buttons (2020 US, 2021/6 UK).
Mounting Type
Flush Mounted
Ambient Air Temperature
Operation -5 ... +45 °C
Number of Outputs
1
Rated Voltage (Ur)
230 V
Rated Frequency (f)
50 / 60 Hz
Maximum Switching Power
Halogen Low Voltage Lamps with Electronical Transformers (Capacitive Loads) 180 V·A | Halogen Low Voltage Lamps with Magnetic Transformers (Inductive Loads) 180 V·A | Incandescent Lamp or Halogen High Voltage Lamps 180 W | LEDi 80 V·A
Load Type
Universal and LED Retrofit | Incandescent lamp | Halogen lamp, high voltage | Halogen lamp, low voltage
Power Loss
1 W
Product Net Width
80 mm
Product Net Height
60 mm
Product Net Depth / Length
95 mm
Product Net Weight
140 g
Built-In Depth (t2)
32 mm
Replacement Product ID (NEW)
2CKA006800A3048
E-Number (Finland)
2620055
E-Number (Sweden)
1301261
RoHS Information
Declaration REACH and ElektroG
RoHS Status
Following EU Directive 2002/95/EC August 18, 2005 and amendment
REACH Declaration
All Articles_REACH_EN_24-2_2CKA309999E9999
REACH Information
True - contains substances > 0.1 mass percentage
REACH Date
20240705
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
EU-Declaration of conformity (.PDF) [EN] 6440/04 U-500
ETIM 9
EC001588 - Electronic switch
eClass
V11.0 : 27144054
Feature: 2-wire connection (neutral not required) enables simpler wiring and faster installation, reducing on-site labor and risk of miswiring. Business Impact: Lower installation costs and faster time-to-first-lit in commercial lighting projects. Application: Ideal for retrofit and new-build lighting control where neutral runs are limited or undesirable. Feature: Rated Voltage 230 V and Rated Frequency 50/60 Hz ensures compatibility with standard mains, enabling plug-and-play integration with existing electrical networks. Business Impact: Minimizes compatibility issues across facilities and reduces wiring changes. Application: Suitable for offices, retail, and hospitality lighting control. Feature: 1 output supports focused control of a single circuit, simplifying system design and maintenance. Business Impact: Predictable performance with straightforward fault isolation. Application: 1-gang wall box installations. Feature: Load Type supports Universal and LED Retrofit, plus compatibility with Halogen and Incandescent loads, expanding retrofit options. Business Impact: Improves energy efficiency and extends lamp life through LED-ready operation. Application: LED retrofit projects and mixed-load environments. Feature: Built-In Depth 32 mm with dimensions 80 × 60 × 95 mm saves wall space and enables flush mounting. Business Impact: Cleaner aesthetics and easier concealment in flush boxes. Application: Renovations and new builds requiring compact switches. Feature: Regulatory Compliance including CE, RoHS, REACH, and WEEE alignment reduces regulatory risk. Business Impact: Compliance assurance across European markets. Application: Procurement and compliance management for regulated deployments. Feature: Compatibility with Busch-Comfort and presence detectors expands system integration possibilities. Business Impact: Enables scalable lighting control architectures with future-ready expandability. Application: Busch system ecosystems and automation upgrades.
Get a Quick Quote for a ABB 2CKA006400A0088
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 2CKA006400A0088?
Enquire Now
FAQs
Install in a flush-mounted box using the 2-wire method (neutral not required). Connect the line to the 230 V supply and the load to the single output. The unit is designed for use with Busch-Comfort elements and can be paired with flush-mounted slave inserts for expanded control. Ensure ambient temperature stays within -5 to +45 °C and the box supports the 80 × 60 × 95 mm footprint.
The insert operates at 230 V with a 50/60 Hz supply and provides one output. Maximum switching power is 180 VA for capacitive or inductive loads and 180 W for incandescent/halogen high-voltage lamps, with LED compatibility listed as part of the load types. Power loss is 1 W, and the built-in depth is 32 mm for compact integration.
Yes. The device supports universal loads and LED retrofit scenarios, enabling energy-efficient upgrades without needing additional control hardware. Its compatibility with LED loads helps reduce overall energy consumption and extends the life of retrofit investments while maintaining reliable switching performance in 230 V systems.
The product carries CE conformity, with REACH and RoHS compliance declarations. WEEE classification applies for waste handling. A formal EU Declaration of Conformity is available, and the product is listed under ETIM EC001588 and eClass 27144054 for standardization and interoperability in industrial automation contexts.
The insert reduces wiring complexity with its 2-wire design, saves space through flush mounting, and supports LED retrofits for energy efficiency. Its compatibility with Busch system components enables scalable automation and easier maintenance, while regulatory compliance minimizes risk in regulated markets. Overall, it lowers installation time, improves reliability, and supports future-ready lighting control strategies.
