2CKA006500A0792
Part Number: 2CKA006500A0792
Product Information
Extended Description
2CKA006500A0792 ABB: With labelling field. Labelling field 57.8 x 9.8 mm Switch-on/switch-off delay: approx. 3-6 min non-adjustable.
Instructions and Manuals
Installation and Operating Instructions (.PDF) [EN] 2240 W-53 2240 W-54
Mounting Type
Surface Mounted
Modular Components Included
Complete Device
Ambient Air Temperature
Operation -35 ... +55 °C
Degree of Protection
IP44
Contacts Configuration
1 NO, 0 NC
Delay Time (τ)
Off 360 second [unit of time] | On 180 second [unit of time]
Sensor Type
Built-in light sensor
Illuminance
3 ... 500 lx
Rated Voltage (Ur)
230 V
Maximum Switching Current
Resistive Load 16 A
Rated Frequency (f)
50 Hz
Maximum Switching Power
1320 W
Design Range
ocean
Surface Finishing
Untreated | Glossy
Material
Thermoplastic
Label Space Provided
Yes
Label Space Size
57.8 x 9.8 mm
RAL Number
Similar to RAL 9010
Color
alpine white
Product Net Width
74 mm
Product Net Height
83 mm
Product Net Depth / Length
55 mm
Product Net Weight
133 g
RoHS Information
Product Declaration.PDF [EN] 2240 W-54
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
REACH Declaration
All Articles_REACH_EN_24-2_2CKA309999E9999
REACH Information
True - contains substances > 0.1 mass percentage
REACH Date
20240705
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
SCIP
7ee3ee04-75ed-4531-9124-73d070c29fae Germany (DE)
Simplified SCIP
7ee3ee04-75ed-4531-9124-73d070c29fae Germany (DE)
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
EU-Declaration of conformity (.PDF) [EN] 2240 W-54
ETIM 9
EC000189 - Twilight switch
