2CKA008399A0003
Part Number: 2CKA008399A0003
Product Information
Extended Description
2CKA008399A0003 ABB: Supply device and controller of the ABB-Welcome system. For connecting the indoor and outdoor busline. With output for electrical door opener for 12V~, 1,6A or potential-free output 30V, 3A. With output to control hall light directly or via relais (230V, 3A). Switching time duration of the door opener and the light is adjustable. For up to 65 consumer units.
Installation Instruction
2-wire
Mounting Type
Mounted Din Rail Component
Ambient Air Temperature
Operation -5...45 °C
Degree of Protection
IP20
Function
Controlling
Compatible Bus Systems
Welcome
Number of Batteries
0
Rated Voltage (Ur)
230 V
Auxiliary Voltage AC/DC
230 V AC/DC
Rated Frequency (f)
50...60 Hz
Width in Number of Modular Spacings
12
Product Net Width
21.6 cm
Product Net Height
9 cm
Product Net Depth / Length
6.5 cm
Product Net Weight
0.86 kg
Replaced Product ID (OLD)
8399-0-0003
RoHS Information
Declaration REACH and ElektroG
RoHS Status
Following EU Directive 2002/95/EC August 18, 2005 and amendment
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
Product Declaration.PDF [EN] 83300-500ECONOMY
