2CLA214400N1101
Part Number: 2CLA214400N1101
Product Information
Extended Description
2CLA214400N1101 ABB: Color: White.
Rated voltage: 110 - 250 Vac.
Rated current: 10 A.
Direct control.
Size: 1 module.
Instructions and Manuals
Manual - Zenit range
Mounting Type
Flush Mounted
Type of Fastening
Engage (Snap)
Ambient Air Temperature
Operation -5 ... +35 °C | Storage -5 ... +50 °C
Degree of Protection
IP20
Data Sheet, Technical Information
9AKK10103A5108
Number of Poles
1P
Number of Buttons
1
Number of Rocker Switches
1
Wiring Configuration
Off switch 1-pole
Actuator Type
Rocker
Connection Type
Plug Clamp
Number of Batteries
0
Rated Voltage (Ur)
250 V
Rated Current (In)
16 A
Design Range
Zenit
Surface Finishing
Untreated | Glossy
Material
Plastic | Thermoplastic
Label Space Provided
No
RAL Number
RAL 9010 - Pure White
Color
White
Product Net Width
22 mm
Product Net Height
44 mm
Product Net Depth / Length
73 mm
Product Net Weight
30 g
Replaced Product ID (OLD)
2CLA214400N1102 | 2CLA214400N1103
RoHS Information
2CLA214400N1101_RoHS Declaration
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
REACH Declaration
9AKK108467A7464-B REACH-2023 Declaration ABB Niessen
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20230816
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
SCIP
1720371e-e908-4b8a-88cf-7b3311a08ac7 Spain (ES)
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
Zenit screwless terminal CE DoC 9AKK106930A5900-D
ETIM 9
EC001590 - Installation switch
