2CLA621469N1701
Part Number: 2CLA621469N1701
Product Information
Extended Description
2CLA621469N1701 ABB: Rated voltage: 110 ... 230 V AC, ±10 %,
Rated current R loads: 5.2 A (output 1 + output 2)
Rated current motors: 2A
Frequency: 50 / 60Hz
RFID card-only option Yes
4 programming modes ECO, STANDARD, EXTENDED, CUSTOM
Status backlight Yes
Dim-out deactivation Yes
Time relay : 0-240 sec.
Output 2*NO contact
Electronic relay Yes
Load compatibility (min./max load):
LEDi: 2 * 2 … 80 W/VA
LV LEDi with elec. transformer: 4 … 800 W/VA
LV LEDi with mec. transformer: 4 … 1000 W
CFL: 4 … 920 W
Incandescent lamps: 4 … 1200 W
Halogen lamps: 4 … 1200 W
Blind control (Motor) max. 2 A
Cards up to 54 mm width.
RFID operation at 13.56 MHz, according to ISO14443B / Mifare ISO14443A standards.
Frame included
Instructions and Manuals
RFID Key Card Holder Manual
Mounting Type
Flush Mounted
Type of Fastening
Mounting with Screw
Ambient Air Temperature
Storage -5 ... +35 °C | Storage Operation;-5 ... +50 °C
Degree of Protection
IP20
Data Sheet, Technical Information
RFID Key Card Holder Manual
Actuator Type
Hotel card
Connection Type
Screw
Illumination
Non-illuminated
Number of Batteries
0
Rated Voltage (Ur)
250 V
Rated Current (In)
16 A
Design Range
Millenium
Surface Finishing
Decor, Matt
Material
Metal
Label Space Provided
Yes
Color
Matt Gold
Product Net Width
0.102 m
Product Net Height
0.062 m
Product Net Depth / Length
0.102 m
Product Net Weight
0.189 kg
REACH Information
No data - If REACH inform is not yet available for a certain product
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
