2CLA816120A1001
Part Number: 2CLA816120A1001
Product Information
Extended Description
2CLA816120A1001 ABB: Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz
Suitable for blind, roller blind and awning drives with mechanical or electronic limit switch shut-off.
With two 230 V multi-way input terminals (Up/Down) for group control.
With operating mode switch for the following modes: normal, louvre, base station, position.
Wind alarm, cleaning functions can be accommodated via extension input.
For comfort timer control element 8565.31 or 8565.3
Remote control also available with blind switchs / push-buttons code 8144.X
Running time: 3 min
Outputs: 2 Normally open contact
Rated current: 3 A, cos φ0.5
Rated power: 690 VA
Control/Signal outputs: 2,
Temperature range (Device): 0 °C to 35 °C
Included: fixing claws
Mounting Type
Flush Mounted
Type of Fastening
Mounting with Claw | Mounting with Screw
Ambient Air Temperature
Operation -5 ... +35 °C | Storage -5 ... +50 °C
Degree of Protection
IP20
Data Sheet, Technical Information
Sky Niessen_catalogue 2018 [EN]
Number of Batteries
0
Rated Voltage (Ur)
230 V
Frequency (f)
50...50 Hz
Maximum Switching Power
690 W
Design Range
Platform 8100 | Alba | Sky Niessen
Color
No color
Product Net Width
0.062 m
Product Net Height
0.073 m
Product Net Depth / Length
0.073 m
Product Net Weight
0.16 kg
Replaced Product ID (OLD)
2CL0816120
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
ETIM 9
EC000615 - Venetian blind control unit
UNSPSC
39122200
