2CLA828350A1101
Part Number: 2CLA828350A1101
Product Information
Extended Description
2CLA828350A1101 ABB: Supply: 230 V~ ; 50/60 Hz.
Secondary: 15 V~ ; 150 mA~.
Neccesaru to use a transformer in all the installations requering the use of Alarm and Signalling Systems.
Instructions and Manuals
Manual - Nurse call - 8282 / 8283 / 8284
Ambient Air Temperature
Operation -5 ... +35 °C | Storage -5 ... +50 °C
Degree of Protection
IP20
Rated Secondary Current (Isn)
0.15 A
Number of Phases
1
Number of Batteries
0
Primary Voltage
230 V
Secondary Voltage
Maximum 15 V
Design Range
Arco
Product Net Width
0.076 m
Product Net Height
0.064 m
Product Net Depth / Length
0.076 m
Product Net Weight
0.157 kg
Replaced Product ID (OLD)
2CL0828351
RoHS Information
2CLA828350A1101_RoHS Declaration
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
REACH Declaration
9AKK108467A7464-B REACH-2023 Declaration ABB Niessen
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20230816
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
Niessen SAS 8283.5
ETIM 9
EC002037 - Variable-voltage transformer
UNSPSC
39121311
