2CLA936810A1001
Part Number: 2CLA936810A1001
Product Information
Extended Description
2CLA936810A1001 ABB: Rated voltage: 127-230 Vac ± 15%; 50-60 Hz
Max. consumption: 200 mA
Stand-by consuption: 0,3W
Amplifier power: 6+6 W; <1% distorsion (4 Ω)
Speaker impedance: 4 Ω (2+2 W audio)
FM radio digital tuner with RDS
Alarm clock with buzzer, radio types and snooze function
Bluetooth receiver: Bluetooth® v2.1 2.4GHz IEEE 802.15.1
Multiroom function available (1 master device and up to 14 slave devices)
Remote control using code 9368.2 (ZigBee 2.4GHz IEEE 802.15.4)
Optional: auxilary module 9368.3 for I/O (1 mini-jack stereo input & 1 mini-jack stereo output) and USB connection functions
Instructions and Manuals
Instructions for installation and use - FM radio / Bluetooth® multiroom module 9368.1
Ambient Air Temperature
Operation -5 ... +35 °C | Storage -5 ... +50 °C
Degree of Protection
IP20
Data Sheet, Technical Information
Sky Niessen_catalogue 2018 [EN]
Number of Outputs
Analog (0 ... 10 V / 4 ... 20 mA) 0
Number of Batteries
0
Rated Voltage (Ur)
230 V
Frequency (f)
50...60 Hz
Design Range
Zenit
Color
No color
Product Net Width
0.047 m
Product Net Height
0.109 m
Product Net Depth / Length
0.293 m
Product Net Weight
0.078 kg
Replaced Product ID (OLD)
2CLA936810A1002
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
Hit By Niessen
ETIM 9
EC002484 - Sound system for domestic switching devices
UNSPSC
39121311
