2CLA936840A1001
Part Number: 2CLA936840A1001
Product Information
Extended Description
2CLA936840A1001 ABB: Rated voltage: 110-230 Vac ± 15%; 50-60 Hz
Max. consumption: 7W
Stand-by consuption: 0,2W
Amplifier power: 2+2 W; <1% distorsion (16 Ω)
Speaker impedance: 16 Ω (2+2 W audio)
3 audio inputs: Bluetooth, AUX (front), TV (rear)
Cover plate code: 8568.4, N2268.4
Instructions and Manuals
Installation manual - BT module
Ambient Air Temperature
Operation -5 ... +35 °C | Storage -5 ... +50 °C
Data Sheet, Technical Information
Sky Niessen_catalogue 2018 [EN]
Number of Batteries
0
Design Range
Zenit
Color
No color
Product Net Width
0.044 m
Product Net Height
0.044 m
Product Net Depth / Length
0.037 m
Product Net Weight
0.034 kg
Replaced Product ID (OLD)
2CLA936840A1002 | 2CLA936840A1003
RoHS Information
2CLA936840A1001_RoHS Declaration
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
ETIM 9
EC002484 - Sound system for domestic switching devices
UNSPSC
45111901
